Process Control Solution – Hengli 060G2102 | Pressure Transmitter Series
Where This Product Is Used
The Hengli 060G2102 Pressure Transmitter is engineered for demanding industrial environments where precise pressure measurement is critical to process integrity and safety. Typical deployment scenarios include:
- Chemical & Petrochemical Plants – Continuous monitoring of pipeline pressure in reactors, separators, and distillation columns.
- Water & Wastewater Treatment – Pump station pressure control, filter differential pressure monitoring, and tank level measurement via hydrostatic pressure.
- HVAC & Building Automation – Duct pressure sensing, chiller loop monitoring, and variable air volume (VAV) system control.
- Oil & Gas Upstream/Midstream – Wellhead pressure monitoring, pipeline integrity checks, and compressor station control loops.
- Food & Beverage Processing – CIP (Clean-In-Place) system pressure verification and hygienic process line monitoring.
- Power Generation – Steam pressure measurement in boiler feed systems and turbine inlet monitoring.
Technical Specifications
- Model: 060G2102
- Brand: Hengli
- Product Type: Pressure Transmitter
- Output Signal: 4–20 mA (2-wire)
- Measurement Medium: Gases, vapors, and liquids compatible with wetted materials
- Process Connection: Standard industrial threaded fitting
- Enclosure Protection: IP65 or higher (dust-tight, jet-water resistant)
- Operating Temperature: -40°C to +85°C (ambient); process temperature per datasheet
- Power Supply: 10–36 V DC loop-powered
- Accuracy: ≤ ±0.5% FS (typical)
- Weight: ~200 g
Note: Full datasheet available upon request. Contact support@konmask.com for model-specific documentation.
Why Engineers Specify This Model
- Proven Hengli Platform – Hengli is a recognized manufacturer of industrial instrumentation with a track record in process automation across Asia-Pacific and global OEM supply chains.
- Universal 4–20 mA Interface – Plug-and-play compatibility with virtually all PLCs, DCS controllers, SCADA systems, and data acquisition hardware without signal conditioning.
- Robust Construction – Stainless steel wetted parts and IP-rated housing ensure longevity in corrosive, humid, or high-vibration environments.
- Compact Form Factor – Lightweight (~200 g) design simplifies panel integration and field installation in space-constrained enclosures.
- Cost-Effective Replacement – Direct drop-in replacement for legacy transmitters in existing control loops, minimizing re-engineering costs.
Complete System Bill of Materials
For a complete pressure measurement loop using the Hengli 060G2102, engineers typically specify:
- Hengli 060G2102 Pressure Transmitter (this unit)
- 2-wire shielded cable (0.5–1.5 mm²), rated for installation environment
- 24 V DC loop power supply or PLC analog input card with internal supply
- Impulse line / manifold valve (2-valve or 5-valve block, per process)
- Process isolation valve (ball or needle type, per media compatibility)
- DIN rail terminal block for field wiring termination
- Analog input module (e.g., Siemens SM 331, Mitsubishi Q64AD, or equivalent)
Compliance & Industry Standards
- Designed and manufactured in compliance with applicable IEC 61298 performance standards for process measurement instrumentation.
- CE marking applicable for EU market deployment.
- RoHS compliant – restricted hazardous substances directive.
- Suitable for use in non-hazardous areas; consult Konmask for ATEX/IECEx-rated variants if required for Zone 1/2 or Division 1/2 classified locations.
Quality Assurance & Sourcing
All Hengli instruments supplied by Konmask.com are sourced through verified authorized distribution channels. Each unit undergoes:
- Factory calibration certificate verification
- Visual and dimensional inspection upon receipt
- Traceability documentation retained for B2B procurement records
We do not supply grey-market, refurbished, or counterfeit instrumentation. Authenticity guaranteed or full refund.
How to Source This Part
- In-Stock Orders: Add to cart and check out directly. Most orders ship within 1–3 business days from our warehouse.
- Bulk / Project Quantities: Contact us for volume pricing, lead time confirmation, and consolidated BOM quotations.
- Custom Configurations: Hengli offers range, output, and connection variants. Contact our engineering team to specify the correct model suffix for your application.
- OEM / Integrator Accounts: Wholesale pricing available for qualified system integrators and panel builders. Apply via support@konmask.com.
Application-Specific FAQ
Q: Is the 060G2102 suitable for steam pressure measurement?
A: Yes, with a siphon (pigtail) installed between the process tap and the transmitter to protect the sensor from direct steam contact. Consult process temperature limits in the datasheet.
Q: Can this transmitter be used with a Siemens S7-1200 PLC?
A: Yes. The 4–20 mA output connects directly to any standard analog input module (e.g., SM 1231 AI). Configure the input channel for 4–20 mA current mode.
Q: What is the difference between gauge and absolute pressure versions?
A: Gauge pressure (G) measures relative to atmospheric pressure; absolute (A) measures relative to perfect vacuum. Specify your requirement when ordering — the 060G2102 model suffix indicates gauge configuration. Contact us to confirm or request absolute variants.
Q: Is a calibration certificate included?
A: Factory calibration documentation is available upon request. NIST-traceable third-party calibration can be arranged at additional cost.
Q: What is the warranty period?
A: Hengli instruments supplied by Konmask.com carry a 12-month warranty against manufacturing defects from date of shipment.
