Safety Relay & Output Isolation Solution – HIMA F3430 | F3400 Series
Where This Product Is Used
The HIMA F3430 is a 4-channel relay output module engineered for safety-critical industrial environments where reliable signal isolation and actuator control are non-negotiable. Typical deployment sites include:
- Oil & Gas Processing Plants — Emergency Shutdown (ESD) systems, burner management, and wellhead control panels requiring SIL 2/3-rated output stages.
- Chemical & Petrochemical Facilities — Process shutdown loops, valve actuator control, and interlock systems under IEC 61511 compliance.
- Power Generation & Utilities — Turbine trip circuits, generator protection relays, and grid-tie interlock logic.
- Offshore Platforms — HIPPS (High Integrity Pressure Protection Systems) and fire & gas detection output stages.
- Pharmaceutical & Fine Chemical — Batch process safety interlocks and clean-room HVAC shutdown control.
- Railway & Transportation Infrastructure — Signaling output modules and track circuit control in EN 50129-compliant architectures.
Technical Specifications
| Part Number | F3430 |
| Manufacturer | HIMA Paul Hildebrandt GmbH |
| Series | F3400 / HIMax / HIMatrix Compatible |
| Module Type | 4-Channel Relay Output Module |
| Output Channels | 4 × Relay (potential-free contacts) |
| Contact Type | Normally Open (NO) / Changeover (CO) |
| Rated Switching Voltage | Up to 250 V AC / 30 V DC |
| Rated Switching Current | Up to 5 A per channel |
| Safety Integrity Level | SIL 2 (IEC 61508) |
| Diagnostic Coverage | High DC with internal self-test |
| Backplane Interface | HIMA F3400 series backplane bus |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −25 °C to +85 °C |
| Humidity | 5–95 % RH, non-condensing |
| Protection Class | IP20 (module), IP54 (cabinet-mounted) |
| Power Consumption | Refer to HIMA F3430 datasheet |
| Dimensions (W × H × D) | Standard F3400 module form factor |
| Weight | Contact us for certified datasheet |
| Certifications | TÜV, IEC 61508, IEC 61511, ATEX (zone-dependent) |
Why Engineers Specify This Model
- Proven SIL 2 Architecture — The F3430 is TÜV-certified for use in safety instrumented functions up to SIL 2, making it a drop-in fit for IEC 61511 process safety loops without additional external voting logic.
- Galvanic Isolation per Channel — Each of the 4 relay channels provides full galvanic isolation between the safety controller backplane and field actuators, eliminating ground-loop interference in noisy industrial environments.
- Integrated Diagnostics — On-board self-test routines continuously verify relay coil integrity and contact state, feeding diagnostic data back to the HIMax/HIMatrix CPU for real-time fault annunciation.
- Hot-Swap Capable — Designed for online replacement within the F3400 chassis, minimizing planned downtime during maintenance windows in continuous-process plants.
- Compact 4-Channel Density — Maximizes I/O density in space-constrained marshalling cabinets typical of offshore and modular skid applications.
- Long-Term OEM Support — HIMA maintains long product lifecycle commitments, ensuring spare parts availability for 10+ year plant lifecycles.
Complete System Bill of Materials
For a fully operational HIMA safety relay output subsystem, engineers typically specify the following alongside the F3430:
- HIMA F3400 Base Unit / Backplane Rack
- HIMA HIMax or HIMatrix CPU Module (e.g., F60 CPU series)
- HIMA F7553 / F7554 Power Supply Module
- HIMA F3330 / F3332 Digital Input Module (for paired input channels)
- HIMA F8650E / F8651E Communication Module (Profibus / Modbus / Ethernet)
- HIMA SILworX Engineering Software License
- Marshalling terminal blocks (Phoenix Contact or Weidmüller, DIN rail)
- Shielded field wiring cable (per HIMA installation guidelines)
Contact Konmask for complete BOM pricing and availability on multi-module orders.
Compliance & Industry Standards
- IEC 61508 — Functional Safety of E/E/PE Safety-Related Systems (SIL 2 certified)
- IEC 61511 — Functional Safety for the Process Industry Sector
- IEC 62061 — Safety of Machinery (applicable for machine-guarding integrations)
- ATEX Directive 2014/34/EU — Zone classification compatibility (verify with HIMA certificate for specific zone rating)
- EN 50129 — Railway applications safety integrity (where applicable)
- TÜV Rheinland Certification — Independent third-party safety assessment
- RoHS Compliant — Restriction of Hazardous Substances
Quality Assurance & Sourcing
Konmask.com sources the HIMA F3430 exclusively through verified industrial distribution channels and authorized surplus networks. Every unit offered undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and firmware revision marking
- Functional power-on test where test bench infrastructure permits
- Anti-static packaging with humidity indicator card
- Traceability documentation (lot number, origin, inspection record) provided on request
- 30-day return window for DOA (Dead on Arrival) units with full replacement or refund
We do not source from unverified grey-market channels. All HIMA modules are supplied with original manufacturer labeling intact.
How to Source This Part
- Confirm your system compatibility — Verify your existing HIMA backplane revision and CPU firmware version against the F3430 compatibility matrix in the HIMA F3400 system manual.
- Request a quote — Email [email protected] with your required quantity, delivery timeline, and destination country for a firm price and lead-time confirmation.
- Place your order — Orders accepted via T/T bank transfer, PayPal (for verified business accounts), and trade credit (approved accounts only).
- Shipping & Export — We ship worldwide via DHL Express, FedEx International Priority, and sea freight for bulk orders. Export documentation (commercial invoice, packing list, COO) provided as standard.
- After-sales support — Our engineering team is available to assist with module commissioning questions, HIMA SILworX configuration guidance, and replacement scheduling.
Application-Specific FAQ
Q: Can the F3430 be used in a 1oo2 (1-out-of-2) voting architecture?
A: Yes. When paired with a redundant HIMA CPU and appropriate input modules, the F3430 relay outputs can be configured in 1oo2 or 2oo3 voting logic within SILworX to meet SIL 2 or SIL 3 system-level requirements.
Q: Is the F3430 compatible with HIMax and HIMatrix platforms?
A: The F3430 is designed for the F3400 backplane series. Compatibility with HIMax or HIMatrix depends on the specific chassis revision — please share your system configuration with us for confirmation before ordering.
Q: What is the typical lead time for the F3430?
A: Lead time varies by stock availability. In-stock units ship within 3–5 business days. For out-of-stock situations, sourcing lead time is typically 4–8 weeks. Contact us for real-time availability.
Q: Do you provide HIMA F3430 repair or refurbishment services?
A: We do not offer in-house repair. We recommend contacting HIMA directly or an authorized HIMA service center for module repair. We can assist with sourcing a replacement unit while your module is under repair.
Q: Can I use the F3430 in an ATEX Zone 1 hazardous area?
A: The F3430 itself is typically installed in a safe-area control room cabinet. For Zone 1 field devices, appropriate ATEX-certified barriers or isolators must be installed between the F3430 output and the field actuator. Consult the HIMA ATEX certificate for your specific installation.
Q: What documentation can Konmask provide with the order?
A: We provide commercial invoice, packing list, certificate of origin, and inspection report. HIMA original datasheets and manuals are publicly available from HIMA’s website; we can provide links upon request.
