Power Measurement Solution – HIOKI 2001-1321A500 AC Board | 3196 Series
Where This Product Is Used
The HIOKI 2001-1321A500 AC Board is a precision internal replacement module designed for HIOKI power analyzers and power quality analyzers, primarily the HIOKI 3196 Power Quality Analyzer series. It is deployed in environments where accurate AC signal conditioning and measurement integrity are critical, including:
- Industrial Energy Auditing – Factory power monitoring stations requiring certified measurement accuracy
- Electrical Panel Testing – MV/LV switchgear commissioning and maintenance verification
- Renewable Energy Systems – Solar inverter output analysis and grid-tie compliance testing
- Building Management Systems (BMS) – Power quality monitoring for HVAC, elevators, and critical loads
- R&D Laboratories – Motor drive characterization and harmonic distortion analysis
- Utility & Substation Maintenance – Periodic calibration and board-level repair of field instruments
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 2001-1321A500 |
| Manufacturer | HIOKI E.E. Corporation |
| Module Type | AC Input / Signal Conditioning Board |
| Compatible Instrument | HIOKI 3196 Power Quality Analyzer (and compatible series) |
| Function | AC voltage/current signal acquisition and conditioning |
| Form Factor | Internal PCB replacement module |
| Weight | Approx. 1,100 g (packaged) |
| Origin | Japan |
| Condition | Genuine OEM / Sourced from authorized supply chain |
Why Engineers Specify This Model
- OEM Precision – Maintains factory-calibrated measurement accuracy; no re-characterization required after swap
- Direct Drop-In Replacement – Matches original connector pinout and PCB footprint for the 3196 platform
- Extends Instrument Life – Cost-effective alternative to full instrument replacement; preserves existing calibration records
- Traceable Supply Chain – Sourced through verified industrial channels with documentation available on request
- Reduced Downtime – Board-level repair restores instrument to service faster than OEM depot turnaround
Complete System Bill of Materials
For a complete HIOKI 3196 repair or calibration kit, engineers typically specify:
- HIOKI 2001-1321A500 – AC Board (this item)
- HIOKI 3196 – Power Quality Analyzer main unit
- HIOKI 9322 / 9323 – Clamp-on current sensors
- HIOKI L9438 – Voltage measurement leads
- HIOKI Z1003 – Carrying case (optional)
- Calibration certificate (available upon request from Konmask)
Compliance & Industry Standards
- Designed for use in instruments compliant with IEC 61000-4-30 Class A power quality measurement
- Compatible with instruments meeting IEC 61010-1 safety requirements
- Suitable for installations governed by IEEE 1159 (Power Quality Monitoring) guidelines
- RoHS-compliant PCB materials
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation and precision measurement components sourced through verified supply networks. Every HIOKI module we supply undergoes:
- Visual and dimensional inspection against OEM reference
- Packaging integrity check prior to dispatch
- Traceability documentation retained for 3 years
We do not supply counterfeit, refurbished-as-new, or grey-market parts. If you require a Certificate of Conformance (CoC) or test report, please contact us before ordering.
How to Source This Part
- Confirm compatibility – Verify your HIOKI instrument model and serial number against the 2001-1321A500 BOM
- Request a quote – Contact support@konmask.com for volume pricing or expedited shipping options
- Place order – Add to cart and complete checkout; we accept T/T, PayPal, and major credit cards
- Receive & install – Module ships with basic installation reference; HIOKI service manual recommended for PCB swap procedures
Application-Specific FAQ
Q: Is the 2001-1321A500 compatible with the HIOKI 3197 or 3198?
A: The 2001-1321A500 is documented for the 3196 platform. Compatibility with 3197/3198 variants should be confirmed against the instrument’s service manual or by contacting Konmask before ordering.
Q: Does replacing this board require factory recalibration?
A: HIOKI recommends post-repair calibration verification. Konmask can assist in connecting you with accredited calibration labs if required.
Q: What is the lead time?
A: Standard lead time is 3–7 business days for in-stock units. Contact us for urgent requirements.
Q: Can I return the board if it does not resolve my instrument fault?
A: Please contact support@konmask.com within 7 days of receipt. We will work with you to diagnose the issue and arrange a resolution.
