Hirschmann RS20-1600T1T1SDAEHH09.0.00 Managed Rail Switch | Replacement, Equivalent & Selection Guide
The Hirschmann RS20-1600T1T1SDAEHH09.0.00 is a compact, DIN-rail-mounted managed industrial Ethernet switch from Hirschmann’s RS20 series. Engineered for harsh industrial environments, it delivers reliable Layer 2 switching with advanced redundancy protocols — making it a preferred choice for process automation, power utilities, and transportation networks. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: RS20-1600T1T1SDAEHH09.0.00
- Brand: Hirschmann (Belden)
- Series: RS20
- Device Type: Managed Industrial Ethernet Switch
- Port Configuration: 16 × 10/100BASE-TX (RJ45) + 2 × combo uplink ports
- Switching Capacity: Store-and-forward Layer 2
- Redundancy Protocols: RSTP, MRP (Media Redundancy Protocol), HIPER-Ring
- Management: Web GUI, SNMP v1/v2c/v3, CLI (Telnet/SSH)
- Power Supply: 12–24 VDC / 24 VAC (dual redundant input)
- Operating Temperature: −10 °C to +60 °C
- Protection Rating: IP30
- Mounting: DIN rail (35 mm)
- Dimensions (W × H × D): ~60 × 125 × 75 mm
- Weight: ~600 g
- Certifications: CE, UL, cUL, GL, DNV
- Firmware: HiOS / Classic OS compatible
Compatible Replacement & Equivalent Models
When the RS20-1600T1T1SDAEHH09.0.00 is discontinued or lead times are extended, the following models offer functional equivalence or direct drop-in replacement potential:
- Hirschmann RS20-1600M2M2SDAEHH09.0.00 — Same RS20 platform, fiber uplink variant; suitable when fiber backbone is required.
- Hirschmann RSP20-1600T1T1SDAEHH09.0.00 — RSP20 series with enhanced power input range; backward-compatible form factor.
- Hirschmann MICE MS20-1600T1T1SDAEHH09.0.00 — Next-generation MS20 platform; expanded VLAN and QoS features, same DIN rail footprint.
- Siemens SCALANCE X208 — 8-port managed alternative; suitable for smaller topologies with PROFINET requirements.
- Moxa EDS-516A-SS-SC — 16-port managed switch with similar redundancy support; compatible in non-Hirschmann ecosystems.
Note: Always verify firmware compatibility, port count, and redundancy protocol support before substituting. Contact Konmask for pre-sales compatibility assessment.
Why Choose the Original Model
- Proven HIPER-Ring redundancy — sub-300 ms failover ensures continuous process operation in ring topologies.
- Hirschmann HiOS ecosystem — seamless integration with existing Hirschmann network management infrastructure (HiVision, Industrial HiVision).
- Wide power input range — dual redundant 12–24 VDC inputs eliminate single points of failure in power supply design.
- Compact DIN rail form factor — fits standard control cabinet layouts without additional mounting hardware.
- Long-term availability — Konmask maintains stock of legacy Hirschmann RS20 series to support installed base maintenance.
Typical Applications
- Process Automation: Backbone switch in PLC/DCS communication rings within chemical, oil & gas, and water treatment plants.
- Power Utilities: Substation automation networks compliant with IEC 61850 communication architecture.
- Transportation & Rail: Trackside and wayside Ethernet networks requiring MRP ring redundancy.
- Factory Automation: Machine-level Ethernet switch connecting PROFINET/EtherNet/IP devices to plant network.
- Building Automation: BACnet/IP and Modbus TCP device aggregation in HVAC and energy management systems.
- Marine & Offshore: DNV/GL-certified switch for vessel automation and offshore platform control networks.
System Compatibility
- Protocols: PROFINET, EtherNet/IP, Modbus TCP, IEC 61850, BACnet/IP
- Management Platforms: Hirschmann Industrial HiVision, HiVision NMS, third-party SNMP managers
- Redundancy Standards: IEC 62439-2 (MRP), IEEE 802.1w (RSTP), Hirschmann HIPER-Ring
- Control Systems: ABB System 800xA, Siemens PCS 7, Emerson DeltaV, Yokogawa CENTUM VP
- Upstream Switches: Compatible with Hirschmann MACH, OCTOPUS, and PowerMICE series as uplink aggregation switches
Selection Guide
Use the following criteria to confirm the RS20-1600T1T1SDAEHH09.0.00 is the right model — or to identify the best alternative:
- Port count needed: 16 copper RJ45 ports → RS20-1600 series ✓ | Fewer ports → consider RS20-0800 series
- Uplink media: Copper uplink → T1T1 suffix ✓ | Fiber uplink → select M2M2 or SS-SC suffix variant
- Redundancy protocol: MRP/HIPER-Ring required → RS20 ✓ | PROFINET MRP only → consider SCALANCE X series
- Power supply: 24 VDC standard panel → RS20 ✓ | 110/230 VAC only → add external PSU or select RSP20 with AC input
- Temperature range: 0–60 °C standard → RS20 ✓ | −40 °C extended → select RS20-HV or MICE MS20 extended-temp variant
- Certifications required: CE + UL → RS20 ✓ | DNV/GL marine → confirm suffix code with Konmask
Quality Assurance & Sourcing
- Authentic Parts: All Hirschmann RS20 units sourced through verified industrial distribution channels with full traceability.
- Inspection Protocol: Each unit undergoes visual inspection, label verification, and power-on functional test prior to shipment.
- Warranty: 12-month Konmask warranty covering manufacturing defects; original Hirschmann warranty documentation provided where available.
- Packaging: Anti-static ESD packaging with original accessories (mounting clips, documentation) included.
- Lead Time: In-stock units ship within 2 business days; sourced units typically 7–15 business days.
How to Order
- Step 1: Confirm part number: RS20-1600T1T1SDAEHH09.0.00
- Step 2: Add to cart or contact support@konmask.com for bulk/project pricing.
- Step 3: Provide project details (quantity, delivery location, required certifications) for expedited quotation.
- Step 4: Receive order confirmation with lead time, tracking, and inspection report.
- Payment: T/T bank transfer, PayPal, and major credit cards accepted.
- Shipping: DHL Express, FedEx International, and sea freight options available worldwide.
Replacement & Compatibility FAQ
Q: Is the RS20-1600T1T1SDAEHH09.0.00 still in production?
A: Hirschmann has transitioned newer projects to the MS20/RSP20 platform. The RS20 series remains available as a spare/replacement part. Konmask maintains stock to support installed-base maintenance.
Q: Can I replace an RS20 with an MS20 without reconfiguring the network?
A: The MS20 shares the same DIN rail footprint and HiOS firmware base, but configuration migration is required. Konmask can provide migration support documentation upon request.
Q: Does this switch support PROFINET?
A: The RS20 supports PROFINET-compatible Ethernet transport. For full PROFINET IO device certification, verify the specific firmware version with Hirschmann or contact Konmask.
Q: What is the difference between T1T1 and M2M2 suffix?
A: T1T1 denotes copper (10/100BASE-TX) uplink ports; M2M2 denotes multimode fiber (100BASE-FX) uplink ports. Choose based on your backbone cabling infrastructure.
Q: Can Konmask provide a test report before shipment?
A: Yes. Power-on test reports and inspection photos are available upon request for all RS20 units.
