Honeywell 51304476-100 Analog Output Termination Board – TDC 3000 Distributed Control System
When an analog output termination board fails in a live process plant, the consequences are immediate and severe: field devices lose their 4–20 mA command signals, control loops fall open, and operators are forced into manual override—risking product quality, safety interlocks, and unplanned downtime that can cost tens of thousands of dollars per hour. The Honeywell 51304476-100 is the precision-engineered interface that keeps your analog output channels reliably connected between the controller backplane and field wiring, making it an irreplaceable component in any TDC 3000 installation.
Within the Honeywell TDC 3000 ecosystem—one of the most widely deployed distributed control systems in refining, petrochemical, and power generation industries—the 51304476-100 occupies a critical signal-conditioning and termination role. Its robust design reflects Honeywell’s decades of process automation engineering, and its continued demand in the global MRO market underscores the long operational life of TDC 3000 installations worldwide.
Technical Specifications
- Part Number: 51304476-100
- Manufacturer: Honeywell Process Solutions
- Series / Platform: TDC 3000 Distributed Control System
- Module Type: Analog Output Termination Board
- Signal Type: Analog Output (4–20 mA standard)
- Form Factor: DIN-rail / backplane-mount termination assembly
- Weight: 500 g (approx.)
- Condition Available: New surplus / Refurbished / Used tested
Note: All specifications are based on Honeywell published documentation. Konmask does not modify or fabricate technical parameters.
Key Features & Benefits
- Drop-in Replacement: Direct OEM-compatible fit for TDC 3000 analog output modules—no rewiring or reconfiguration required.
- Signal Integrity: Maintains clean 4–20 mA loop continuity between the controller and field instrumentation.
- Robust Construction: Designed to Honeywell’s industrial-grade standards for long-term reliability in harsh process environments.
- Fast Restoration: Stocking this board as a critical spare eliminates extended lead times during emergency shutdowns.
- Broad Compatibility: Interfaces with standard Honeywell TDC 3000 analog output modules and associated field wiring assemblies.
Industry & Equipment Applications
- Oil & Gas Refining – crude distillation, hydrocracking, and utilities control loops
- Petrochemical Plants – reactor temperature and flow control systems
- Power Generation – boiler and turbine analog output control
- Pulp & Paper – process variable output to final control elements
- Pharmaceutical Manufacturing – batch process analog output management
- Chemical Processing – continuous process DCS analog output termination
System Integration & Compatible Parts
The 51304476-100 is designed to work within the Honeywell TDC 3000 control architecture. Compatible and related components include:
- Honeywell TDC 3000 Analog Output Modules (AO)
- Honeywell MC-TAOY22 / MC-TAOY12 series output modules
- Honeywell FTA (Field Termination Assembly) wiring panels
- Honeywell 51304453-100 / 51304453-150 series termination boards
- Honeywell TDC 3000 HPM (High-Performance Process Manager) subsystems
Always verify revision compatibility with your existing backplane and firmware version before installation.
Our Quality Assurance Process
- Visual Inspection: All boards are inspected for physical damage, corrosion, and component integrity upon receipt.
- Functional Testing: Where applicable, units are bench-tested to verify signal path continuity and basic electrical function.
- Authenticity Verification: We source only from traceable supply chains; counterfeit parts are rejected at intake.
- Secure Packaging: ESD-safe packaging with moisture barrier bags and foam cushioning for international shipment.
- Documentation: Test reports and condition certificates available upon request for critical applications.
How to Order
- Submit an RFQ (Request for Quotation) via our website contact form or email [email protected].
- Provide your required quantity, acceptable condition (new / refurbished / used), and any urgency timeline.
- Receive a formal quotation with lead time, condition report, and shipping options within 24 business hours.
- Confirm the order and receive proforma invoice for payment processing.
- Shipment dispatched with full tracking; EXW, FOB, and DDP terms available.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on DCS, PLC, and process control components—not a generalist marketplace.
- Global Sourcing Network: Access to new surplus, OEM-refurbished, and tested-used inventory across major automation brands.
- Fast Quotation Response: Dedicated B2B inquiry handling with technical staff who understand your urgency.
- Flexible Trade Terms: T/T, L/C, and other payment methods; EXW/FOB/DDP shipping from China.
- Long-Term Partnership: We support MRO procurement teams with ongoing supply agreements and obsolescence management.
Frequently Asked Questions
- Q: Is the Honeywell 51304476-100 still in production?
- A: This part is associated with the legacy TDC 3000 platform. Availability is primarily through new surplus and refurbished channels. Contact us to confirm current stock status.
- Q: What condition options are available?
- A: We offer new surplus (unused OEM stock), factory-refurbished, and used-tested units. Condition is clearly stated in each quotation.
- Q: Can you ship internationally?
- A: Yes. We ship worldwide from China with DHL, FedEx, UPS, and freight forwarding options. Export documentation is provided.
- Q: How long does it take to receive a quote?
- A: Standard RFQ response is within 24 business hours. Urgent requests are prioritized—please indicate urgency in your inquiry.
- Q: Do you provide a warranty?
- A: Yes. Refurbished and tested units carry a 90-day functional warranty. Terms are detailed in the sales agreement.
