HONEYWELL 51405038-175 CC-PAIH01 Analog Input Module | Replacement, Equivalent & Selection Guide
The HONEYWELL 51405038-175 (CC-PAIH01) is a high-density analog input module designed for use in Honeywell’s C300 Controller-based Experion PKS distributed control systems. It provides reliable, high-accuracy analog signal acquisition for process industries including oil & gas, petrochemical, power generation, and advanced manufacturing. This page serves as a comprehensive selection, replacement, and compatibility reference for procurement engineers and automation specialists.
Technical Specifications
- Part Number: 51405038-175
- Model: CC-PAIH01
- Manufacturer: Honeywell Process Solutions
- Module Type: Analog Input (AI)
- Channel Count: 8 channels (differential)
- Input Signal Range: 4–20 mA / 1–5 V (configurable per channel)
- Resolution: 16-bit A/D conversion
- Isolation: Channel-to-channel and channel-to-bus isolation
- Communication Bus: C-Bus (Experion PKS Series C)
- Power Supply: Supplied via Series C I/O carrier
- Operating Temperature: 0°C to 60°C
- Humidity: 5% to 95% RH (non-condensing)
- Certifications: CE, UL, FM (Class I, Div 2)
- Dimensions: Standard Series C I/O module form factor
- Weight: Approx. 400 g
- Compatible Carrier: CC-TAIX11, CC-TAIX51 (Series C I/O Termination Assemblies)
Compatible Replacement & Equivalent Models
The following modules are verified compatible replacements or functional equivalents for the CC-PAIH01 in Experion PKS Series C architectures. Always verify firmware revision and carrier compatibility before substitution.
- 51405038-175 — OEM part number (this listing)
- CC-PAIH01 — Honeywell catalog model designation
- 51405038-150 / -160 / -175 — Revision variants; confirm firmware compatibility with your C300 controller version
- CC-PAIH02 — Higher-density variant (16-channel); drop-in carrier compatible but requires configuration update
- 51304485-100 (MC-PAIH03) — Legacy TDC/PlantScape equivalent for migration projects (requires I/O link adapter)
Note: Third-party or aftermarket equivalents are not recommended for SIL-rated loops. Contact Konmask for OEM-sourced stock verification.
Why Choose the Original Model
- Guaranteed Compatibility: Factory-matched to Experion PKS C300 controller firmware and C-Bus protocol — no re-engineering required.
- SIL Compliance: Supports SIL 2 capable loops when used with appropriate safety instrumented system (SIS) configuration.
- Hot-Swap Capable: Supports online replacement without process shutdown when used with redundant carrier configurations.
- Long-Term Support: Honeywell provides extended lifecycle support and firmware updates for Series C I/O.
- Traceability: OEM-sourced units include full manufacturing traceability, certificates of conformance, and warranty coverage.
Typical Applications
- Oil & gas upstream/downstream process control (flow, pressure, temperature measurement)
- Petrochemical plant DCS analog signal acquisition
- Power generation boiler and turbine control loops
- Pharmaceutical batch process monitoring
- Pulp & paper mill process automation
- Water treatment and utility SCADA integration
System Compatibility
- DCS Platform: Honeywell Experion PKS (Series C architecture)
- Controller: C300 Process Controller
- I/O Carrier: CC-TAIX11 / CC-TAIX51 Termination Assemblies
- Redundancy: Supported via redundant carrier pair (CC-TAIX51)
- Engineering Tool: Honeywell Control Builder (R400 and above recommended)
- Not Compatible With: Series A/B I/O carriers; TDC 3000 FTA without adapter; Experion LX (different I/O bus)
Selection Guide
Use the following criteria to confirm the CC-PAIH01 / 51405038-175 is the correct module for your application:
- Signal Type: Requires 4–20 mA or 1–5 V analog inputs → ✅ CC-PAIH01
- Channel Count: Need 8 differential AI channels per slot → ✅ CC-PAIH01 | Need 16 channels → Consider CC-PAIH02
- Platform: Experion PKS Series C with C300 controller → ✅ CC-PAIH01
- Safety Loop: SIL 2 requirement → ✅ CC-PAIH01 (with SIS configuration) | SIL 3 → Consult Honeywell Safety Systems
- Redundancy: Required → Use with CC-TAIX51 redundant carrier
- Legacy Migration: Migrating from TDC 3000 → Evaluate MC-PAIH03 with I/O link adapter or full Series C migration
Quality Assurance & Sourcing
- Source: OEM-authorized and surplus-market verified stock
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-check before shipment
- Documentation: Certificate of Conformance (CoC) available upon request; original Honeywell packaging where available
- Warranty: 12-month warranty against manufacturing defects
- Anti-Counterfeit: All units sourced through traceable supply chains; counterfeit screening applied
- Export Compliance: ECCN classification and export documentation available for international orders
How to Order
- Step 1: Confirm your Experion PKS firmware version and C300 controller revision
- Step 2: Verify carrier model (CC-TAIX11 or CC-TAIX51) and slot availability
- Step 3: Add HONEYWELL 51405038-175 CC-PAIH01 to cart or contact us for bulk/project pricing
- Step 4: Provide PO number, delivery address, and any special documentation requirements at checkout
- Lead Time: In-stock units ship within 1–3 business days; ex-stock international orders within 5–7 business days
- Payment: T/T (Wire Transfer), PayPal, and major credit cards accepted
Replacement & Compatibility FAQ
Q: Can I use 51405038-150 instead of 51405038-175?
A: The -150 and -175 are revision variants of the same model. In most cases they are functionally interchangeable, but verify with your Honeywell system engineer that the firmware revision on your C300 supports the earlier hardware revision.
Q: Is CC-PAIH01 compatible with Experion LX?
A: No. Experion LX uses a different I/O bus architecture. CC-PAIH01 is exclusively for Experion PKS Series C systems.
Q: Can this module be used in a SIL 2 safety loop?
A: Yes, when properly configured within a Honeywell Safety Manager or SIS-compliant architecture. Consult your functional safety engineer for loop validation.
Q: Do you supply new or refurbished units?
A: Konmask supplies both new OEM stock and professionally refurbished units. Condition is clearly stated on each listing. Contact us if you require new-only supply.
Q: Can you provide a Certificate of Conformance?
A: Yes. CoC is available upon request for all orders. Please specify at time of order.
