Hydac EDS1791-N-016-000 Electronic Pressure Switch – EDS 1791 Series
Imagine a hydraulic press line running at full capacity when an undetected pressure deviation causes a cylinder to over-extend — within seconds, tooling is damaged, the line shuts down, and maintenance crews scramble for hours. Without a reliable electronic pressure switch at the monitoring point, that scenario is not hypothetical; it is an operational reality. The Hydac EDS1791-N-016-000 eliminates that risk by delivering precise, real-time pressure monitoring with electronic switching accuracy that mechanical gauges simply cannot match.
Within the EDS 1791 Series, the EDS1791-N-016-000 occupies a critical mid-range position, engineered for 0–16 bar measurement ranges that cover the majority of hydraulic and pneumatic circuit monitoring applications in mobile machinery, industrial presses, and process automation. Hydac’s EDS 1791 Series is globally recognized as a benchmark for compact electronic pressure switches, deployed across automotive manufacturing, offshore equipment, and heavy industrial machinery on every continent.
Technical Specifications
- Manufacturer: Hydac International
- Part Number / SKU: EDS1791-N-016-000
- Series: EDS 1791
- Product Type: Electronic Pressure Switch
- Measuring Range: 0 – 16 bar
- Output Type: PNP / NPN switching output (series-dependent)
- Display: LED bar graph / digital display (series standard)
- Electrical Connection: M12 plug connector
- Process Connection: G¼ male (DIN 3852)
- Protection Class: IP67
- Operating Temperature: –25 °C to +85 °C (media); –25 °C to +70 °C (ambient)
- Supply Voltage: 10 – 30 V DC
- Weight: Approx. 2,100 g (packaged)
Note: All specifications are sourced from Hydac official documentation. Verify with the datasheet before final engineering selection.
Key Features & Benefits
- Electronic Switching Precision: Eliminates hysteresis errors inherent in mechanical pressure switches, ensuring repeatable setpoint accuracy critical for safety-rated circuits.
- Compact, Robust Housing: Stainless steel wetted parts and IP67 protection make the EDS1791-N-016-000 suitable for harsh environments including wash-down zones and outdoor mobile equipment.
- Intuitive LED Display: On-device bar graph display allows field technicians to read pressure status and adjust setpoints without additional instrumentation.
- Wide Supply Voltage Range (10–30 V DC): Compatible with both 12 V mobile machine architectures and 24 V industrial control panels without additional signal conditioning.
- M12 Quick-Connect: Industry-standard M12 connector enables rapid installation and replacement, minimizing downtime during maintenance windows.
- EMC Compliant: Designed to meet CE electromagnetic compatibility requirements for integration into CE-marked machinery.
Industry & Equipment Applications
- Hydraulic Power Units (HPU): Monitoring system pressure, filter differential pressure, and accumulator charge status.
- Mobile Machinery: Excavators, cranes, agricultural equipment — monitoring hydraulic circuit health in real time.
- Industrial Presses & Injection Molding: Clamping force verification and safety interlock circuits.
- Offshore & Marine Equipment: Deck machinery, winches, and steering systems requiring IP67-rated instrumentation.
- Process Automation: Pneumatic actuator control, coolant circuit monitoring, and lubrication system supervision.
- Test Benches: Precision pressure monitoring in hydraulic and pneumatic test rigs.
System Integration & Compatible Parts
The EDS1791-N-016-000 is designed for seamless integration into Hydac system architectures and standard industrial control environments:
- Compatible Connectors: Hydac M12 cable assemblies (e.g., EAM series) for direct plug-and-play wiring.
- PLC Compatibility: Direct connection to Siemens S7, Allen-Bradley ControlLogix, Mitsubishi MELSEC, and Omron NX/NJ series digital input modules.
- Hydac System Components: Pairs with Hydac HDA pressure transmitters for redundant monitoring, and Hydac filter elements with differential pressure monitoring ports.
- Mounting Accessories: G¼ adapters, manifold blocks, and inline tee fittings available — contact us for compatible part numbers.
