ICS Triplex T8193 – 24V DC Fan Assembly | Rack Mounting | Trusted Safety System Platform
Engineering Background: ICS Triplex (now part of Rockwell Automation’s safety systems portfolio) is a globally recognized manufacturer of Triple Modular Redundant (TMR) and High Integrity safety instrumented systems. The T8193 Fan Assembly is a purpose-engineered thermal management component designed to maintain optimal operating temperatures within ICS Triplex rack-mounted control enclosures — a critical requirement for continuous, fault-tolerant operation in process safety environments.
Product Positioning: The T8193 is a direct OEM replacement fan assembly for ICS Triplex rack systems, operating at 24V DC and supplied complete with one T8273 fan unit. It is the specified solution for engineers maintaining Trusted TMR, TMC, and legacy ICS Triplex safety system installations across oil & gas, petrochemical, power generation, and offshore platforms.
Complete Technical Specifications
- Part Number: T8193
- Manufacturer: ICS Triplex (Rockwell Automation)
- Description: 24V DC Fan Assembly, Rack Mounting
- Included Components: 1× T8273 Fan Unit
- Supply Voltage: 24V DC
- Mounting Type: Rack Mounting
- Weight: 480 g (approx.)
- Application: Thermal management for ICS Triplex TMR/TMC rack enclosures
- Compatibility: ICS Triplex Trusted Safety System racks and associated enclosures
- Condition Available: New OEM / Tested Surplus / Refurbished
Proven Application Environments
- Oil & Gas — Upstream, Midstream & Downstream Process Control
- Petrochemical & Refinery Safety Instrumented Systems (SIS)
- Offshore Platform Control Rooms & Equipment Rooms
- Power Generation — Turbine Control & Emergency Shutdown Systems
- LNG / LPG Terminal Safety Systems
- Pipeline SCADA & Compressor Station Control
- Nuclear Auxiliary Systems (where ICS Triplex platforms are qualified)
Engineering Advantages
- OEM-Specified Replacement: Direct drop-in for T8193 without system reconfiguration or re-validation.
- 24V DC Operation: Compatible with standard ICS Triplex rack power distribution — no additional power conversion required.
- Bundled T8273 Inclusion: Supplied as a complete assembly kit, reducing procurement steps and ensuring component compatibility.
- Thermal Reliability: Maintains rack internal temperatures within ICS Triplex-specified limits, protecting processor and I/O modules from thermal degradation.
- Minimal Downtime Replacement: Designed for field-replaceable maintenance without full rack shutdown in supported configurations.
- Long Service Life: Industrial-grade fan motor rated for continuous duty in demanding environments.
System Architecture & Signal Flow
The T8193 Fan Assembly integrates into the ICS Triplex rack enclosure’s thermal management subsystem. The 24V DC supply is drawn from the rack’s internal power bus. The T8273 fan unit circulates air across the backplane and module card cage, exhausting heat generated by TMR processor triads, I/O modules, and communication cards. Fan status monitoring (where supported by the rack controller) provides fault indication to the system’s diagnostic layer, enabling predictive maintenance before thermal excursion events occur.
Note: Exact airflow path and monitoring integration depend on the specific ICS Triplex rack model and firmware revision. Consult the applicable ICS Triplex hardware manual for installation torque, airflow direction, and fan fault wiring details.
Sourcing & Quality Verification
- Source Traceability: Units sourced from decommissioned plant upgrades, authorized distributors, or OEM new-old-stock channels.
- Inspection Protocol: Each unit undergoes visual inspection, dimensional verification, and functional power-on test prior to dispatch.
- Packaging: Anti-static bagged, foam-cushioned, and shipped in double-wall carton with part number label and test record.
- Documentation: Certificate of conformance and test report available upon request.
- Warranty: 12-month warranty against defects in materials and workmanship (terms apply).
Procurement Process
- Confirm part number T8193 against your ICS Triplex rack BOM or maintenance manual.
- Submit inquiry or place order via Konmask.com product page or email support@konmask.com.
- Receive quotation with lead time, condition grade, and shipping options within 1 business day.
- Order confirmation and proforma invoice issued upon agreement.
- Dispatch within 2–5 business days (expedited options available for critical shutdowns).
- Track shipment via provided AWB; technical support available throughout installation.
Technical FAQ
Q: Is the T8193 compatible with all ICS Triplex rack variants?
A: The T8193 is designed for ICS Triplex rack-mounting enclosures. Compatibility should be verified against your specific rack model number and hardware revision. Contact us with your rack part number for confirmation.
Q: What is the T8273 included in this assembly?
A: The T8273 is the individual fan unit that forms part of the T8193 assembly kit. It is the replaceable fan element within the assembly bracket.
Q: Can I replace only the T8273 fan without the full T8193 assembly?
A: Yes — the T8273 is available separately. However, if the mounting bracket or wiring harness shows wear, replacing the complete T8193 assembly is recommended for reliability.
Q: What is the lead time for urgent orders?
A: Standard lead time is 2–5 business days. For plant emergency or turnaround situations, contact us directly at +0086 19859288691 for expedited processing.
Q: Do you provide installation support?
A: Yes. Our engineering team can provide installation guidance, ICS Triplex documentation references, and remote technical support during commissioning.
