ICS TRIPLEX T3480 Guarded Analog Output – Triple Modular Redundancy Safety System
When a guarded analog output module fails in a safety-critical process environment — whether in an offshore platform emergency shutdown system, a refinery burner management loop, or a turbine overspeed protection circuit — the consequences extend far beyond a simple I/O fault. Without a functioning, certified analog output channel, the entire safety instrumented function (SIF) loses its ability to command final control elements. Field devices go blind, protective actions cannot be executed, and the plant faces either a dangerous uncontrolled state or a costly spurious trip. The ICS TRIPLEX T3480 exists precisely to eliminate this single point of failure from your safety architecture.
The T3480 is a Guarded Analog Output module engineered for ICS TRIPLEX Triple Modular Redundancy (TMR) safety systems — one of the most trusted fault-tolerant control platforms deployed across global oil & gas, power generation, and petrochemical industries. Within the T3480x series, this module occupies the analog output tier, providing voted, guarded signal conditioning that ensures output integrity even in the presence of internal hardware faults. ICS TRIPLEX TMR technology has been installed in thousands of safety-critical applications worldwide, and the T3480 is a cornerstone I/O component of that proven ecosystem.
Technical Specifications
- Part Number: T3480
- Manufacturer: ICS TRIPLEX
- Module Type: Guarded Analog Output
- Platform: ICS TRIPLEX TMR (Triple Modular Redundancy) Safety System
- Output Signal: Analog (4–20 mA standard industrial signal, per TMR platform specification)
- Architecture: Triple redundant voted output with fault guarding
- Safety Rating: Designed for use in SIL-rated Safety Instrumented Systems (SIS)
- Weight: 1,180 g
- Compliance: Conforms to IEC 61511 / IEC 61508 safety lifecycle requirements (as part of TMR platform)
Note: All specifications are based on publicly available ICS TRIPLEX documentation. Contact us to verify exact revision-level datasheet for your application.
Key Features & Benefits
- Fault-Guarded Output Architecture: The T3480 employs guarded output circuitry that detects and isolates internal faults before they can propagate to the field device, maintaining output integrity under fault conditions.
- TMR Voted Signal Path: Three independent processing lanes vote on the output command, ensuring that a single-channel failure does not result in a spurious or failed output — critical for both safety and availability.
- Hot-Swap Capable: Designed for online replacement within the TMR chassis, minimizing maintenance downtime in continuous-process environments where shutdowns are costly.
- High Diagnostic Coverage: Onboard diagnostics continuously monitor output channel health, enabling predictive maintenance and reducing proof-test intervals.
- Seamless Platform Integration: Plug-and-play compatibility within the ICS TRIPLEX TMR backplane — no re-engineering of the safety logic or I/O mapping required during module replacement.
- Long Service Life: Built to industrial-grade environmental standards for temperature, vibration, and humidity, supporting decades of reliable operation in harsh plant environments.
Industry & Equipment Applications
- Oil & Gas: Emergency Shutdown Systems (ESD), High Integrity Pressure Protection Systems (HIPPS), wellhead control panels, and pipeline safety loops.
- Petrochemical & Refining: Burner Management Systems (BMS), reactor protection, and distillation column safety interlocks.
- Power Generation: Turbine overspeed protection, boiler safety systems, and generator protection relays interfacing with analog actuators.
- LNG & Offshore Platforms: Fire & Gas (F&G) system output modules, compressor anti-surge control, and FPSO safety architectures.
- Nuclear & Utilities: Any SIL 2/3 rated safety function requiring certified, redundant analog output capability.
System Integration & Compatible Parts
The T3480 is designed to operate within the ICS TRIPLEX TMR platform ecosystem. Compatible and commonly associated components include:
- ICS TRIPLEX TMR Processor / Controller Modules (T3xxx series)
- ICS TRIPLEX Analog Input Modules (T3481, T3482 series)
- ICS TRIPLEX Digital I/O Modules (T3401, T3411 series)
- ICS TRIPLEX TMR Backplane and Chassis assemblies
- ICS TRIPLEX Power Supply Modules
- ICS TRIPLEX Communication and Gateway Modules
If you need a complete bill of materials for a TMR system upgrade or spare parts package, our engineering team can assist with cross-referencing and compatibility verification.
Our Quality Assurance Process
- Source Verification: All ICS TRIPLEX modules are sourced from authorized channels or verified surplus inventories with full traceability documentation.
- Visual & Physical Inspection: Each unit undergoes inspection for physical damage, connector integrity, label authenticity, and revision marking consistency.
- Functional Testing: Where applicable, modules are bench-tested against known-good reference systems prior to shipment.
- Secure Packaging: ESD-safe packaging with anti-static bags, foam cushioning, and moisture barrier protection for international shipping.
- Documentation: Certificate of conformance and inspection report available upon request.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page or email support@konmask.com.
- Provide your required quantity, delivery timeline, and any specific revision or firmware requirements.
- Our team will respond within 1 business day with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange secure export packaging and coordinate international logistics to your destination.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, and safety system components — not a generalist marketplace.
- Global Supply Network: Access to hard-to-find and obsolete ICS TRIPLEX parts through our verified supplier network.
- Technical Support: Our team understands TMR architecture and can assist with compatibility questions, not just order processing.
- Fast Response: Dedicated B2B inquiry handling with same-day or next-business-day quotation turnaround.
- Trusted by Engineers: Serving process safety engineers, maintenance planners, and procurement teams across Asia, the Middle East, and Europe.
Frequently Asked Questions
Q: Is the T3480 compatible with all ICS TRIPLEX TMR chassis versions?
A: The T3480 is designed for the ICS TRIPLEX TMR platform. Compatibility may vary by chassis revision and firmware version. Please provide your system details when inquiring so we can confirm compatibility.
Q: Can you supply a tested and certified unit?
A: Yes. We offer units with inspection documentation and, where available, functional test reports. Certification requirements (e.g., SIL loop validation) must be performed by the end-user’s qualified safety engineer as part of their SIS lifecycle process.
Q: What is the lead time for the T3480?
A: Lead time depends on current stock availability. Submit an RFQ and we will confirm within 1 business day. Expedited shipping options are available for urgent requirements.
Q: Do you offer a warranty?
A: Yes. We provide a standard warranty on all supplied modules. Terms are specified in the quotation. Extended warranty options may be available upon request.
Q: Can you supply multiple T3480 units for a full TMR spare parts kit?
A: Absolutely. We regularly fulfill bulk spare parts orders for plant turnarounds and safety system upgrades. Contact us with your full BOM for a consolidated quotation.
