IDEC HG1F-SB22BF-W Touch Screen HMI Panel – HG1F Series
When a critical HMI panel fails on the production floor, operators lose visibility into machine states, alarms go unacknowledged, and entire lines can grind to a halt within minutes. Downtime in automated manufacturing is never just an inconvenience — it translates directly into lost output, missed delivery windows, and costly emergency maintenance calls. The IDEC HG1F-SB22BF-W eliminates that vulnerability by providing a robust, field-proven operator interface that keeps your control system visible and responsive at all times.
Within the IDEC HG1F Series, the HG1F-SB22BF-W occupies the compact-panel segment — a 2.2-inch STN monochrome touch screen designed for space-constrained control cabinets and machine-mounted enclosures where every millimeter counts. IDEC’s HG Series HMI panels are widely deployed across Asia-Pacific, North America, and Europe in packaging, food processing, and discrete manufacturing applications, making genuine replacement units and new installations equally straightforward to source and commission.
Technical Specifications
- Model: HG1F-SB22BF-W
- Brand: IDEC Corporation
- Series: HG1F Series
- Display Type: 2.2″ STN Monochrome LCD
- Touch Panel Type: Resistive analog touch screen
- Supply Voltage: 24 VDC
- Communication Ports: RS-232C / RS-485
- Protection Rating: IP65 (front panel)
- Operating Temperature: 0 °C to +50 °C
- Storage Temperature: -20 °C to +60 °C
- Weight: Approx. 280 g
- Mounting: Panel cut-out, rear mounting
- Compatible Software: IDEC WindO/I-NV4
Note: Specifications are based on IDEC published datasheets. Always verify against the official IDEC product manual before final engineering design.
Key Features & Benefits
- Compact 2.2″ form factor — fits tight panel spaces without sacrificing operator usability
- IP65 front-panel sealing — resists dust and water ingress in harsh industrial environments
- Dual serial communication (RS-232C & RS-485) — connects to a wide range of PLCs and controllers from multiple vendors
- 24 VDC operation — compatible with standard industrial control-panel power supplies
- Resistive touch technology — operable with gloves, stylus, or bare fingers
- WindO/I-NV4 software support — intuitive screen design with ladder-logic tag binding and alarm management
- Long product lifecycle — IDEC maintains parts availability for extended periods, reducing obsolescence risk
Industry & Equipment Applications
- Packaging machinery — line speed control, batch counters, fault display
- Food & beverage processing — temperature setpoint entry, CIP cycle monitoring
- Textile & printing equipment — tension control HMI, recipe management
- HVAC & building automation — chiller/AHU local operator panels
- Semiconductor & electronics assembly — compact machine-mounted operator stations
- Water treatment — pump control and alarm annunciation panels
System Integration & Compatible Parts
The HG1F-SB22BF-W communicates natively with IDEC SmartAXIS PLCs (FC6A, FT1A series) via RS-232C/RS-485 and supports third-party PLC connectivity through IDEC’s extensive driver library. Typical companion components include:
- IDEC FC6A Series MicroSmart PLCs
- IDEC FT1A SmartAXIS Touch (for larger HMI requirements)
- IDEC PS5R-series DIN-rail power supplies (24 VDC)
- Standard RS-232C/RS-485 communication cables (HG9Z-XC□□ series)
- Panel mounting gaskets and hardware (included with unit)
Our Quality Assurance Process
At Konmask.com, every IDEC HG1F-SB22BF-W unit passes through a structured verification process before shipment:
- Source verification — units are procured from authorized distributors or directly traceable supply chains
- Visual & cosmetic inspection — housing, connector pins, and label integrity checked against IDEC OEM standards
- Functional power-on test — display initialization and touch response confirmed
- Anti-static packaging — ESD-safe bags and foam-lined cartons for safe international transit
- Documentation — CE/UL declarations and datasheet copies available on request
How to Order
- Submit an inquiry via the Contact / Request a Quote button on this page
- Provide your required quantity, delivery timeline, and destination country
- Our team responds within 1 business day with availability confirmation and a formal quotation
- Upon PO acceptance, we arrange export documentation and preferred freight method
- Tracking information provided upon dispatch
For urgent requirements, email support@konmask.com or call +0086 19859288691.
Why Choose Konmask.com?
- ✅ Specialized in industrial automation components — not a generalist marketplace
- ✅ B2B-focused with volume pricing and consolidated shipment options
- ✅ Export experience across 30+ countries with full customs documentation support
- ✅ Dedicated technical pre-sales team familiar with IDEC product lines
- ✅ Responsive after-sales support for warranty claims and returns
Frequently Asked Questions
- Q: Is the HG1F-SB22BF-W compatible with non-IDEC PLCs?
- A: Yes. Via RS-232C/RS-485 and IDEC’s WindO/I-NV4 driver library, the panel supports connectivity to Mitsubishi, Omron, Siemens, and other major PLC brands. Confirm the specific driver version with our technical team before ordering.
- Q: What is the difference between HG1F-SB22BF-W and HG1F-SB22BF?
- A: The “-W” suffix typically denotes a white/light-colored bezel variant. Functionally, the units are identical. Verify the bezel color requirement against your panel design before ordering.
- Q: Can you supply the WindO/I-NV4 programming software?
- A: WindO/I-NV4 is available as a free download from IDEC’s official website. We can assist with sourcing the correct USB programming cable if required.
- Q: What is the lead time for the HG1F-SB22BF-W?
- A: Lead time depends on current stock levels. Submit an inquiry for a real-time availability check. In-stock units typically ship within 3–5 business days after PO confirmation.
- Q: Do you provide a warranty?
- A: Yes. We offer a 90-day warranty against manufacturing defects on all units. Extended warranty options are available — contact us for details.
