Machine Vision & Industrial Inspection Solution – IDS UI-1540SE-M-HQ | uEye SE Series
Where This Product Is Used
The IDS UI-1540SE-M-HQ is a high-performance USB 3.0 industrial digital camera from IDS Imaging Development Systems, engineered for demanding machine vision applications across manufacturing, robotics, and quality control environments. Engineers and system integrators specify this model when they need a compact, reliable, and cost-effective imaging solution that delivers consistent results in 24/7 industrial operation.
- Automated Optical Inspection (AOI) – PCB defect detection, solder joint verification, and component placement validation on SMT lines
- Robotic Guidance & Pick-and-Place – Real-time vision feedback for collaborative robots (cobots) and industrial robot arms
- Dimensional Measurement & Gauging – In-line metrology for precision parts in automotive, aerospace, and electronics manufacturing
- Barcode & OCR Reading – High-speed 1D/2D code reading and optical character recognition on production lines
- Pharmaceutical & Food Packaging Inspection – Label verification, fill-level detection, and cap/seal integrity checks
- Semiconductor Wafer Inspection – Sub-micron defect detection in cleanroom environments
- Traffic & Logistics Monitoring – License plate recognition and parcel dimension capture in warehouse automation
Technical Specifications
| Parameter | Value |
|---|---|
| Model | UI-1540SE-M-HQ |
| Brand / Manufacturer | IDS Imaging Development Systems |
| Series | uEye SE (USB 3.0) |
| Sensor Type | CMOS Monochrome (M = Mono) |
| Resolution | 1.3 MP (1280 × 1024 px) |
| Interface | USB 3.0 (SuperSpeed) |
| Frame Rate | Up to 60 fps @ full resolution |
| Shutter Type | Global Shutter |
| Pixel Size | 5.3 µm × 5.3 µm |
| Dynamic Range | > 60 dB |
| Lens Mount | C-Mount / CS-Mount |
| Housing | Compact industrial-grade aluminum |
| Operating Temperature | 0 °C to +50 °C |
| Power Supply | USB Bus Power (5 V) |
| OS Support | Windows, Linux, macOS |
| SDK | IDS Software Suite (uEye API, DirectShow, GigE Vision compatible SDK) |
| Weight | Approx. 20 g (camera body only) |
| Part Number | UI-1540SE-M-HQ |
Why Engineers Specify This Model
- Global Shutter – Eliminates motion blur when imaging fast-moving objects on conveyor systems or high-speed assembly lines
- USB 3.0 Bus Power – Single-cable installation reduces wiring complexity and lowers system integration cost
- HQ Optics Compatibility – Optimized for high-quality C-mount lenses, enabling sharp imaging across the full sensor area
- IDS uEye SDK – Mature, well-documented API with support for OpenCV, HALCON, LabVIEW, and MATLAB integration
- Compact Form Factor – Fits into space-constrained machine frames and robotic end-effectors without compromising performance
- Long Product Lifecycle – IDS commits to extended availability, reducing redesign risk for OEM integrators
- Trigger & Strobe I/O – Hardware trigger input and strobe output for precise synchronization with PLCs and lighting controllers
Complete System Bill of Materials
For a complete machine vision station using the UI-1540SE-M-HQ, engineers typically specify the following components:
- Camera: IDS UI-1540SE-M-HQ (this unit)
- Lens: C-Mount fixed focal length (e.g., 8 mm, 12 mm, or 16 mm depending on field of view)
- Illumination: Coaxial or ring LED light with strobe controller
- Frame Grabber / Host: Industrial PC with USB 3.0 port (Intel NUC or DIN-rail IPC)
- PLC Interface: Siemens 3RF2950-0KA16 solid-state relay or Allen-Bradley 892B12PCJ2GW1S inductive sensor for trigger signal conditioning
- Pressure Monitoring: 100 PSIA transducer for pneumatic actuator feedback in pick-and-place cells
- Vision Software: IDS peak, HALCON, or OpenCV-based custom application
- Cable: USB 3.0 Type-A to Micro-B locking cable (3 m or 5 m)
Compliance & Industry Standards
- CE Marking – Electromagnetic Compatibility (EMC) Directive 2014/30/EU
- RoHS Compliant – Restriction of Hazardous Substances Directive 2011/65/EU
- USB 3.0 (USB 3.1 Gen 1) – USB Implementers Forum certified
- USB3 Vision Standard – AIA machine vision interface standard compliance
- GenICam compliant – Generic Interface for Cameras standard
- FCC Part 15 Class B – Radiated emissions compliance for North American markets
Quality Assurance & Sourcing
Konmask.com sources the IDS UI-1540SE-M-HQ exclusively from verified supply channels with full traceability. Every unit undergoes incoming inspection including:
- Visual inspection of housing, connectors, and lens mount thread integrity
- Functional power-on test via USB 3.0 enumeration verification
- Image capture validation using IDS uEye Cockpit software
- Serial number and firmware version logging for warranty tracking
All products are shipped in original or equivalent ESD-safe packaging with protective foam inserts.
How to Source This Part
To place an order or request a quotation for the IDS UI-1540SE-M-HQ:
- Online: Add to cart directly on this page and proceed to checkout
- Email RFQ: Send your BOM or purchase order to support@konmask.com
- Phone / WhatsApp: +0086 19859288691 (Monday–Friday, 09:00–18:00 CST)
- Lead Time: Typically 3–7 business days for in-stock units; 2–4 weeks for special orders
- MOQ: 1 unit (no minimum order quantity)
- Payment: T/T, PayPal, credit card, and trade assurance accepted
Application-Specific FAQ
Q: Is the UI-1540SE-M-HQ compatible with ROS (Robot Operating System)?
A: Yes. IDS provides a ROS driver package for uEye cameras, enabling direct integration with ROS-based robotic vision pipelines.
Q: Can this camera be used in a cleanroom environment?
A: The standard model is suitable for ISO Class 6 and above. For stricter cleanroom requirements, contact us for sealed housing options.
Q: What is the difference between the -M-HQ and -C-HQ variants?
A: The -M suffix denotes a Monochrome sensor, while -C denotes Color. Monochrome sensors offer higher sensitivity and are preferred for most industrial inspection tasks where color information is not required.
Q: Does this camera support hardware triggering from a Siemens PLC?
A: Yes. The camera’s GPIO trigger input is compatible with 3.3 V and 5 V TTL signals. Use a signal conditioning relay such as the Siemens 3RF2950-0KA16 to interface with 24 VDC PLC output modules.
Q: What lens focal length should I use for PCB inspection at 300 mm working distance?
A: For a 1280 × 1024 sensor with 5.3 µm pixel pitch at 300 mm WD, a 25 mm focal length lens typically yields a field of view of approximately 64 mm × 51 mm — suitable for single-board inspection. Contact our engineering team for a custom optics calculation.
