Machine Automation Solution – Jetter JX6-BASIS-4 | JX6 Series Modular PLC
Where This Product Is Used
The Jetter JX6-BASIS-4 is the central CPU base unit of the JX6 modular control platform, engineered for demanding industrial environments where deterministic real-time control, compact footprint, and scalable I/O expansion are non-negotiable. Typical deployment scenarios include:
- Packaging Machinery – High-speed filling, sealing, and labeling lines requiring synchronized multi-axis motion and fast cycle times.
- Printing & Converting Equipment – Web tension control, register correction, and servo-driven cut-to-length applications.
- Assembly Automation – Multi-station pick-and-place cells, robotic cell coordination, and vision-triggered sequencing.
- Special-Purpose Machines (SPM) – OEM machine builders integrating a compact, DIN-rail-mounted controller with deterministic scan times.
- Material Handling – Conveyor routing, sortation, and palletizing systems with distributed I/O over JX6 expansion modules.
- Textile & Woodworking Machinery – Cam-profile motion, electronic gearing, and synchronized axis control.
Technical Specifications
| Part Number / SKU | JX6-BASIS-4 |
| Manufacturer | Jetter AG (Germany) |
| Series | JX6 Modular Control System |
| Form Factor | Modular CPU Base Unit, DIN-rail mount |
| Expansion Slots | 4 module slots (JX6 I/O and function modules) |
| Programming Standard | IEC 61131-3 (LD, FBD, ST, IL, SFC) |
| Communication | CANopen, RS-232/RS-485, optional Ethernet/PROFIBUS via expansion |
| Power Supply | 24 V DC |
| Operating Temperature | 0 °C to +55 °C |
| Protection Class | IP20 (panel/cabinet installation) |
| Weight | approx. 500 g |
| Country of Origin | Germany |
Why Engineers Specify This Model
- 4-Slot Scalability – Accepts up to 4 JX6 function/I/O modules, allowing engineers to tailor the exact I/O mix without over-specifying hardware.
- Deterministic Real-Time Performance – Jetter’s JetSym programming environment delivers sub-millisecond cycle times critical for motion-synchronized applications.
- Compact DIN-Rail Footprint – Optimized for space-constrained control cabinets common in OEM machine builds.
- CANopen Native – Direct integration with servo drives, I/O nodes, and HMI panels over CANopen without additional gateways.
- Long-Term Availability – JX6 platform components are maintained for extended production lifecycles, reducing obsolescence risk for machine builders.
- IEC 61131-3 Compliance – Portable, standards-based code reduces retraining costs and supports multi-vendor engineering teams.
Complete System Bill of Materials
A typical JX6-BASIS-4 control system build includes:
- JX6-BASIS-4 – CPU base unit (this item)
- JX6-PS24 – 24 V DC power supply module
- JX6-DIO – Digital I/O expansion module (16 DI / 16 DO)
- JX6-AIO – Analog I/O module (4 AI / 2 AO)
- JX6-CAN – CANopen master/slave communication module
- JX6-ETH – Ethernet TCP/IP communication module (optional)
- JetSym STX – IEC 61131-3 programming software license
- 24 V DC DIN-rail power supply (e.g., PULS, Phoenix Contact)
Contact Konmask for bundle pricing on complete JX6 system configurations.
Compliance & Industry Standards
- IEC 61131-3 – Programmable Controller Programming Languages
- EN 61000-6-2 / EN 61000-6-4 – Industrial EMC Immunity & Emissions
- CE Marking – EU Declaration of Conformity
- UL/cUL Listed (verify current certification status with Jetter AG)
- RoHS Compliant
Quality Assurance & Sourcing
Konmask.com sources the JX6-BASIS-4 exclusively through verified industrial distribution channels. Every unit undergoes:
- Visual and label authenticity inspection upon receipt
- Firmware version verification against Jetter AG release records
- Anti-static packaging and climate-controlled storage
- Full traceability documentation available on request
We do not sell grey-market, refurbished, or counterfeit components. All products ship with original manufacturer packaging.
How to Source This Part
- In-Stock Orders: Add to cart and check out directly. Orders placed before 17:00 CST ship same business day.
- Bulk / Project Quotes: Email [email protected] with your BOM for volume pricing.
- Lead-Time Items: If stock is temporarily unavailable, contact us for factory lead-time and reservation options.
- Technical Pre-Sales: Our automation engineers can assist with module selection, system sizing, and compatibility verification.
Application-Specific FAQ
Q: How many I/O points can the JX6-BASIS-4 support?
A: With 4 expansion slots populated by JX6-DIO modules, the system can support up to 128 digital I/O points locally, with additional I/O available over CANopen remote nodes.
Q: Is the JX6-BASIS-4 compatible with Jetter servo drives?
A: Yes. The JX6 platform natively supports Jetter JX6-SERVO and third-party CANopen DS402-compliant servo drives for coordinated multi-axis motion.
Q: Can I use JetSym STX for programming?
A: Yes. JetSym STX is the recommended IEC 61131-3 IDE for all JX6 series controllers, supporting ladder diagram, structured text, function block diagram, and sequential function chart.
Q: What is the maximum CANopen node count?
A: The JX6 CANopen master supports up to 127 nodes at baud rates up to 1 Mbit/s, suitable for large distributed I/O architectures.
Q: Is this product suitable for safety-rated applications (SIL/PLe)?
A: The JX6-BASIS-4 is a standard (non-safety) controller. For SIL 2 / PLd-e applications, Jetter offers dedicated safety modules. Contact us for guidance.
