Kikusui PVS300-4 DC Power Supply 0-300V 4A | Replacement, Equivalent & Selection Guide
The Kikusui PVS300-4 (also referenced as VT3-V10D, PC 300, part number 17-157996-00) is a high-performance regulated DC power supply delivering a wide output range of 0–300 V / 0–4 A. Designed for laboratory, R&D, and industrial test applications, it offers precise voltage and current control with low ripple and stable output. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams.
Technical Specifications
- Brand: Kikusui Electronics
- Model: PVS300-4
- Part Numbers: VT3-V10D / PC 300 / 17-157996-00
- Series: PVS Series
- Output Voltage: 0 – 300 V DC (continuously adjustable)
- Output Current: 0 – 4 A
- Max Output Power: 1200 W
- Regulation Mode: CV (Constant Voltage) / CC (Constant Current)
- Ripple & Noise (CV): ≤ 3 mVrms (typical)
- Load Regulation (CV): ≤ 0.01% + 2 mV
- Line Regulation (CV): ≤ 0.01% + 2 mV
- Display: Digital LED (Voltage & Current)
- Interface: GP-IB / RS-232C (model dependent)
- Input: AC 100/200 V ±10%, 50/60 Hz
- Weight: Approx. 14.5 kg
- Compliance: CE, RoHS
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or functional equivalents for the Kikusui PVS300-4. Always verify specifications against your application requirements before substitution.
- Kikusui PVS300-4B – Updated variant with enhanced interface options; direct drop-in replacement
- Kikusui PVS300-4R – Rack-mount version; same electrical specs, different form factor
- Kikusui PWR1800L – Higher power alternative (1800 W) for demanding applications
- Keysight E3649A – Dual-output alternative; lower voltage range (0–60 V), suitable for lower-voltage systems
- Chroma 62150H-600S – High-voltage programmable alternative (0–600 V) for extended range needs
- Ametek Sorensen SGA300/4 – Industrial-grade equivalent; 0–300 V / 4 A, rack-mount
- TDK-Lambda GEN300-5 – Programmable equivalent; 0–300 V / 5 A, wider current headroom
Note: Konmask.com supplies genuine Kikusui OEM units. Third-party equivalents listed above are for reference only.
Why Choose the Original Model
- Proven Reliability: Kikusui PVS Series has decades of field-proven performance in semiconductor, aerospace, and automotive test environments.
- Precise Output Control: Ultra-low ripple and tight load/line regulation ensure repeatable test results.
- Wide Voltage Range: 0–300 V in a single unit eliminates the need for multiple supplies.
- OEM Compatibility: Original part numbers (VT3-V10D, 17-157996-00) ensure seamless integration with existing Kikusui test systems and software.
- Manufacturer Support: Full Kikusui calibration, service, and warranty support available.
Typical Applications
- Component and PCB burn-in testing
- High-voltage device characterization (IGBTs, MOSFETs, capacitors)
- Motor drive and inverter development
- Aerospace and defense subsystem testing
- Automotive electronics validation (EV/HEV components)
- University and R&D laboratory power sourcing
- Semiconductor wafer-level testing
System Compatibility
- GP-IB (IEEE-488): Compatible with LabVIEW, MATLAB, and standard SCPI command sets
- RS-232C: Supported for legacy system integration
- Kikusui PVS Series Accessories: Compatible with OPT-01 (GP-IB), OPT-02 (RS-232C), and external sense leads
- Rack Systems: Fits standard 19-inch rack with optional rack-mount kit
- Software: Compatible with Kikusui PWRCHK and third-party ATE software via SCPI
Selection Guide
Use the following criteria to confirm the PVS300-4 is the right choice, or to identify a suitable alternative:
- Required Output Voltage ≤ 300 V & Current ≤ 4 A: → PVS300-4 is the optimal choice
- Need higher current (up to 8 A) at same voltage: → Consider Kikusui PVS300-8
- Need higher voltage (up to 600 V): → Consider Kikusui PVS600-2 or Chroma 62150H-600S
- Need programmable/remote control: → Confirm OPT-01 (GP-IB) or OPT-02 (RS-232C) option is included
- Rack-mount deployment: → Specify PVS300-4R or request rack-mount kit separately
- Budget-sensitive replacement: → Contact Konmask.com for refurbished/tested unit availability
Quality Assurance & Sourcing
- All units sourced through authorized distribution channels or directly from Kikusui-certified partners
- Pre-shipment functional testing: output voltage, current, CV/CC mode switching, and ripple verification
- Calibration certificates available upon request (NIST-traceable)
- Refurbished units undergo full inspection, cleaning, and 48-hour burn-in before dispatch
- Genuine OEM parts only — no counterfeit or grey-market stock
How to Order
- Step 1: Confirm your required model: PVS300-4 (standard) or specify option (GP-IB / RS-232C / rack-mount)
- Step 2: Add to cart or contact us for bulk/B2B pricing
- Step 3: Provide your shipping address and preferred freight method
- Step 4: Receive order confirmation with estimated lead time (typically 3–7 business days for in-stock units)
- Step 5: Unit ships with test report and packing list; calibration certificate available on request
For urgent requirements or custom configurations, email support@konmask.com or call +0086 19859288691.
Replacement & Compatibility FAQ
Q: Is the PVS300-4B a direct replacement for the PVS300-4?
A: Yes. The PVS300-4B is the current production successor with identical electrical specifications and improved interface options. It is a drop-in replacement in most applications.
Q: Can I use a TDK-Lambda GEN300-5 as a substitute?
A: Electrically compatible for most applications (0–300 V, 5 A vs 4 A). Verify mechanical dimensions and interface protocol compatibility before substitution.
Q: What does part number 17-157996-00 refer to?
A: This is an OEM/system integrator part number assigned to the PVS300-4 for use in specific automated test equipment (ATE) configurations. It refers to the same base unit.
Q: Is VT3-V10D the same as PVS300-4?
A: VT3-V10D is an internal option or configuration code associated with the PVS300-4 platform. Confirm with your system documentation or contact us for clarification.
Q: Do you supply calibrated units?
A: Yes. NIST-traceable calibration certificates are available upon request at an additional charge.
Q: What is the lead time for a new unit?
A: In-stock units ship within 3–7 business days. Out-of-stock or special configurations may require 2–4 weeks. Contact us for current availability.
