KUKA 00-284-170 KPC4 Control Board – Industrial Robot Controller PC Board | KR C2 / KR C3 Platform
Engineering Background
The KUKA KPC4 (Part No. 00-284-170) is the core processor control board designed for KUKA’s KR C2 and KR C3 robot controller cabinets. As the central computing unit of the controller, it manages real-time motion interpolation, I/O communication, fieldbus coordination, and system diagnostics. This board is a critical replacement component for maintaining uptime in automated manufacturing cells across automotive, aerospace, and general industrial environments.
Product Positioning
Konmask.com supplies the KUKA 00-284-170 KPC4 Control Board as a verified industrial spare part, sourced through authorized channels and subject to pre-shipment functional inspection. This component is targeted at maintenance engineers, OEM integrators, and procurement teams requiring a reliable, specification-matched replacement for aging or failed KR C2/C3 controller hardware.
Complete Technical Specifications
- Manufacturer: KUKA Roboter GmbH
- Part Number: 00-284-170
- Component Designation: KPC4 (KUKA PC Board 4)
- Compatible Controller: KR C2, KR C3
- Board Type: Industrial PC Control Board (CPU/Motherboard Assembly)
- Form Factor: Proprietary KUKA controller rack-mount
- Operating System Support: Windows XP Embedded / VxWorks (controller-dependent)
- Communication Interfaces: Ethernet, DeviceNet, PROFIBUS DP (configuration-dependent)
- Power Supply: Supplied via KR C2/C3 controller internal PSU
- Weight: Approx. 580 g
- Condition: New / Refurbished (specify at inquiry)
- Warranty: 12 months (subject to terms)
Proven Application Environments
- Automotive body-in-white welding and assembly lines
- Aerospace component handling and precision assembly
- Palletizing and material handling systems
- Machine tending and CNC integration cells
- Painting and coating robot systems
- General factory automation with KUKA KR series robots
Engineering Advantages
- Drop-in Replacement: Direct OEM part number match (00-284-170) eliminates compatibility risk and re-programming overhead.
- Real-Time Performance: KPC4 architecture supports deterministic motion control with sub-millisecond cycle times critical for synchronized multi-axis operations.
- Fieldbus Flexibility: Supports major industrial protocols enabling seamless integration into existing PLC/SCADA architectures.
- Reduced Downtime: In-stock availability at Konmask.com enables rapid dispatch, minimizing production line stoppages.
- Pre-Shipment Verification: Each unit undergoes visual inspection and functional checks before dispatch.
System Architecture & Signal Flow
Within the KR C2/C3 controller cabinet, the KPC4 board serves as the central processing node. It receives operator commands from the KUKA smartPAD (teach pendant) via the KCP interface, processes motion programs stored in the controller’s memory, and outputs interpolated axis position commands to the DSE (Drive System Electronics) boards. Simultaneously, it manages I/O signal routing between the robot system and external PLCs or safety controllers via the configured fieldbus interface. The board also handles system-level diagnostics, error logging, and communication with the KCP display subsystem.
Sourcing & Quality Verification
- Source: Authorized industrial surplus and OEM-channel procurement
- Inspection Standard: Visual inspection + power-on functional test where applicable
- Traceability: Part number and serial number recorded at intake
- Packaging: ESD-safe anti-static packaging with foam cushioning
- Documentation: Certificate of conformity available upon request
Procurement Process
- Submit Inquiry: Contact us via email or phone with your robot model, controller serial number, and required quantity.
- Quotation: Receive a formal quotation with lead time and shipping options within 24 business hours.
- Order Confirmation: Confirm purchase order; payment via T/T, PayPal, or credit card.
- Dispatch: Unit packed in ESD-safe materials and shipped via DHL / FedEx / UPS with tracking.
- After-Sales Support: Technical support available post-installation for configuration queries.
Technical FAQ
Q: Is the KUKA 00-284-170 KPC4 compatible with KR C4 controllers?
A: No. The KPC4 (00-284-170) is designed specifically for KR C2 and KR C3 controller platforms. KR C4 uses a different PC architecture and is not compatible.
Q: Does the board come with the operating system pre-installed?
A: Availability of pre-loaded OS depends on the unit’s condition (new vs. refurbished). Please specify your requirement at the time of inquiry.
Q: Can I use this board without a KUKA-certified technician?
A: Installation should be performed by a qualified KUKA-trained engineer or certified integrator to ensure safety compliance and correct system initialization.
Q: What is the lead time for this part?
A: In-stock units typically ship within 1–3 business days. Lead time for sourced units is 5–15 business days depending on availability.
Q: Do you provide a warranty?
A: Yes. A 12-month warranty is provided against manufacturing defects under normal operating conditions. Terms apply.
