KUKA smartPAD Teach Pendant Robot Programming Interface – KRC2 / KRC4 Series
When a KUKA robot’s teach pendant fails on the production floor, everything stops. Operators lose the ability to jog axes, modify programs, or perform safety-critical overrides. In automotive welding cells, semiconductor handling lines, and palletizing systems, even a 30-minute downtime event can cost tens of thousands of dollars. The KUKA smartPAD is not a peripheral — it is the primary human-machine interface that keeps your robot cell operational and safe.
The KUKA smartPAD (part numbers 00-115-489, 00-139-565, and 00-168-334) is the standard teach pendant for KUKA KRC2 and KRC4 robot controllers — the most widely deployed KUKA controller platforms globally. With an ergonomic multi-touch display, integrated enabling device, and full KUKA System Software (KSS) compatibility, the smartPAD represents the benchmark for industrial robot HMI design. It is used across hundreds of thousands of KUKA robot installations in over 50 countries.
Technical Specifications
- Compatible Controllers: KUKA KRC2, KRC4, KRC4 compact, KRC4 smallsize
- Part Numbers: 00-115-489 / 00-139-565 / 00-168-334
- Display: 8.4-inch color touchscreen (multi-touch capable)
- Interface: KUKA smartPAD connector (proprietary KUKA bus)
- Enabling Device: 3-position enabling switch (integrated)
- Emergency Stop: Integrated E-Stop button (IEC 60204-1 compliant)
- Operating Mode Selector: Key-operated mode switch (T1 / T2 / AUT / EXT)
- Cable Length: Standard 10 m spiral cable
- Protection Rating: IP54
- Weight: Approx. 1.1 kg (pendant only)
- Software Compatibility: KUKA System Software (KSS) 8.x and above
- Language Support: Multi-language KSS interface
Key Features & Benefits
- Multi-Touch Display: Intuitive touchscreen interface reduces operator training time and improves programming efficiency on the shop floor.
- Hot-Plug Capability: The smartPAD can be connected and disconnected from the KRC4 controller without powering down the system, minimizing production interruption.
- Integrated Safety Devices: 3-position enabling switch and E-Stop are hardware-integrated, ensuring compliance with ISO 10218-1 robot safety standards.
- Ergonomic Design: Ambidextrous grip, balanced weight distribution, and clearly labeled function keys reduce operator fatigue during extended programming sessions.
- Full KSS Compatibility: Supports all KUKA System Software functions including motion programming, I/O monitoring, diagnostic tools, and safety configuration.
- Durable Construction: IP54-rated housing withstands industrial environments including dust, coolant mist, and mechanical vibration.
- Direct Replacement: Drop-in replacement for existing KRC2 and KRC4 installations — no controller firmware changes required in most configurations.
Industry & Equipment Applications
- Automotive Manufacturing: Spot welding, MIG/MAG welding, body-in-white assembly, and paint shop robots.
- Electronics & Semiconductor: PCB handling, component placement, and cleanroom-compatible robot cells.
- Metal Fabrication: Arc welding, laser cutting, and press tending applications.
- Food & Beverage: Palletizing, pick-and-place, and packaging line robots.
- Logistics & Warehousing: Depalletizing, sortation, and goods-to-person fulfillment systems.
- Aerospace: Drilling, riveting, and composite layup robot systems.
- General Industrial Automation: Any KRC2 or KRC4 robot cell requiring operator programming or manual intervention capability.
System Integration & Compatible Parts
The KUKA smartPAD is designed for seamless integration within the KUKA KRC4 ecosystem. Compatible and frequently co-ordered components include:
- KUKA KRC4 Controller Cabinet (various configurations)
- KUKA KRC2 Controller (legacy installations)
- KUKA smartPAD Cable Assembly (10 m / 25 m extensions)
- KUKA KPS 600 Power Supply Module
- KUKA CCU (Cabinet Control Unit) boards
- KUKA KSP (KUKA Servo Pack) drive modules
- KUKA RDC (Resolver Digital Converter) cards
Contact Konmask.com to source complete spare parts kits or system-level replacement packages for your KUKA robot cell.
Our Quality Assurance Process
At Konmask.com, every KUKA smartPAD unit undergoes a structured inspection process before shipment:
- Visual Inspection: Housing integrity, connector condition, cable sheath, and display surface checked against OEM cosmetic standards.
- Functional Verification: Touchscreen response, enabling switch operation, E-Stop circuit continuity, and mode selector function tested where applicable.
- Part Number Verification: Label and internal markings cross-referenced against KUKA OEM documentation to confirm correct part number.
- Packaging: Anti-static foam-lined packaging with moisture barrier for safe international transit.
- Documentation: Inspection report and part number certificate of conformity included with each shipment.
How to Order
- Submit an Inquiry: Use the contact form on this page or email [email protected] with your required part number (00-115-489, 00-139-565, or 00-168-334) and quantity.
- Receive a Quote: Our technical team will confirm availability, lead time, and pricing within 1 business day.
- Confirm & Pay: Approve the proforma invoice and complete payment via T/T bank transfer, PayPal, or other agreed method.
- Shipment & Tracking: Parts are dispatched via DHL, FedEx, or UPS Express with full tracking provided.
- After-Sales Support: Our engineering team is available post-delivery to assist with installation verification questions.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on industrial control system components — PLC modules, robot controllers, servo drives, and HMI devices.
- Global Sourcing Network: Access to OEM-grade and certified refurbished KUKA parts from verified supply channels worldwide.
- Technical Expertise: Our team includes engineers with hands-on experience in KUKA robot system integration and maintenance.
- Fast Response: Inquiry-to-quote turnaround within 24 hours. Emergency sourcing support available for critical downtime situations.
- Secure International Shipping: Experienced in export documentation, customs compliance, and safe packaging for fragile electronic components.
- Transparent Communication: No hidden fees. Clear lead times, honest stock status, and proactive shipment updates.
Frequently Asked Questions
Q: What is the difference between part numbers 00-115-489, 00-139-565, and 00-168-334?
A: These three part numbers represent different hardware revisions of the KUKA smartPAD teach pendant. All are compatible with KRC4 controllers running KSS 8.x. The 00-115-489 is an earlier revision, while 00-168-334 is a later production variant. Functionally, they are interchangeable in most KRC4 installations. Please confirm your controller’s KSS version with our team if you are unsure which revision is optimal for your system.
Q: Is the smartPAD compatible with KRC2 controllers?
A: The smartPAD was introduced with the KRC4 platform. KRC2 controllers use the earlier KUKA KCP2 (KUKA Control Panel 2) teach pendant. If you have a KRC2 system, please contact us to confirm the correct pendant for your specific controller variant.
Q: Can I use the smartPAD with KUKA iiwa or LBR robots?
A: The KUKA iiwa (LBR iiwa) uses a different controller architecture (KUKA Sunrise Cabinet) and is not compatible with the standard smartPAD. Please inquire separately for iiwa-compatible HMI solutions.
Q: Do you supply new or refurbished units?
A: Konmask.com supplies both new OEM units and certified refurbished units depending on availability. All units are inspected and tested before shipment. Stock status is confirmed at the time of inquiry.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. For sourced or refurbished units, lead time is typically 5–15 business days depending on origin. Emergency sourcing is available — contact us directly for urgent requirements.
Q: Do you provide a warranty?
A: Yes. All units supplied by Konmask.com carry a minimum 90-day warranty against defects in materials and workmanship. Extended warranty options are available upon request.
