CNC Machine Tool Control Solution – LASER S-DNC-62-G16 | DNC System Screen
Where This Product Is Used
The LASER S-DNC-62-G16 System Screen is engineered for demanding industrial environments where reliable DNC (Direct Numerical Control) communication and operator interface are mission-critical. Typical deployment scenarios include:
- CNC Machining Centers – Serves as the primary operator interface for program selection, machine status monitoring, and real-time DNC data transfer between host computers and CNC controllers.
- Turning & Milling Lines – Integrated into multi-machine DNC networks to enable centralized program management across lathes, mills, and machining centers on the shop floor.
- Aerospace & Defense Manufacturing – Used in high-precision part production facilities requiring traceable, error-free NC program delivery to machine tools.
- Automotive Body & Powertrain Plants – Deployed in high-volume transfer line environments where uptime and fast program changeover are essential.
- Tool & Die Shops – Provides operators with a clear, rugged display for managing complex mold and die programs in DNC-networked environments.
- General Metal Fabrication – Suitable for any facility running FANUC, Siemens, Mitsubishi, or HAAS controllers that require a dedicated DNC system screen.
Technical Specifications
| Part Number | S-DNC-62-G16 |
| Brand | LASER |
| Series | DNC-62 Series |
| Product Type | System Screen / HMI Operator Panel |
| Interface | DNC (Direct Numerical Control) |
| Compatible Controllers | FANUC, Siemens, Mitsubishi, HAAS, Mazak (verify with datasheet) |
| Weight | 5,300 g (approx.) |
| Condition | New / Surplus / Refurbished (specify at inquiry) |
| Origin | Industrial OEM Grade |
Full datasheet available upon request. Contact support@konmask.com for detailed electrical and mechanical specifications.
Why Engineers Specify This Model
- Proven DNC Architecture – The S-DNC-62-G16 is purpose-built for DNC environments, eliminating the latency and compatibility issues common with generic HMI panels.
- Rugged Industrial Construction – Designed to withstand vibration, coolant mist, and temperature variation typical of machine shop floors.
- Drop-in Replacement Compatibility – Maintains dimensional and electrical compatibility with existing LASER DNC-62 series installations, minimizing retrofit engineering time.
- Operator-Centric Display – Clear screen layout reduces operator error during program selection and machine setup, directly improving first-part quality.
- Long Service Life – Industrial-grade components rated for continuous 24/7 operation in production environments.
Complete System Bill of Materials
For a complete DNC workstation or retrofit, engineers typically specify the following alongside the S-DNC-62-G16:
- DNC Host Controller / Communication Server
- RS-232 / RS-422 Serial Interface Cables (machine-specific)
- DNC Software License (LASER or compatible)
- Panel Mounting Hardware & Enclosure
- 24 VDC Power Supply (verify input voltage requirements)
- Ethernet Switch (for networked DNC topologies)
Contact support@konmask.com for a complete BOM quotation tailored to your machine tool model.
Compliance & Industry Standards
- Designed for use in industrial control panel environments per IEC 60204-1 (Safety of Machinery – Electrical Equipment)
- Compatible with DNC communication protocols aligned with EIA-RS-274 (G-code standard)
- Suitable for facilities operating under ISO 9001 quality management systems
- CE marking applicability – confirm with product datasheet for your specific regional requirements
Quality Assurance & Sourcing
At Konmask.com, every LASER S-DNC-62-G16 unit is:
- Inspected upon receipt for physical integrity and label authenticity
- Stored in ESD-safe, climate-controlled warehousing
- Shipped with original manufacturer packaging where available
- Traceable to authorized distribution or OEM surplus channels
We do not source from unverified grey-market channels. All units are available with documentation upon request.
How to Source This Part
- Add to Cart – Place your order directly on Konmask.com for in-stock units.
- Request a Quote – For volume orders (>3 units) or urgent requirements, email support@konmask.com or call +0086 19859288691.
- Confirm Compatibility – Provide your machine model and existing controller type so our engineers can verify fit before shipment.
- Lead Time – In-stock units ship within 1–3 business days. Ex-stock or special-order units: 5–15 business days depending on origin.
Application-Specific FAQ
Q: Is the S-DNC-62-G16 compatible with FANUC 0i-MD controllers?
A: The LASER DNC-62 series is designed for broad CNC compatibility. Please contact us with your specific FANUC model for a confirmed compatibility check before ordering.
Q: Can this screen replace an older LASER DNC-60 series unit?
A: In many cases yes, but mechanical mounting dimensions and connector pinouts should be verified. Our technical team can assist with cross-reference documentation.
Q: Do you offer a warranty on this product?
A: Yes. Konmask.com provides a standard 90-day functional warranty on all industrial components. Extended warranty options are available — contact us for details.
Q: Can you supply the matching DNC software for this screen?
A: We can source LASER DNC software licenses and related accessories. Please include your requirements in your inquiry.
Q: What is the lead time for international orders?
A: International shipments typically take 5–10 business days via DHL/FedEx Express. We ship to most countries worldwide.
