Variable Speed Drive Solution – LENZE E70ACPSE0604V | E70 AC Series
The LENZE E70ACPSE0604V is a compact, high-performance inverter drive from the LENZE E70 AC Series, rated at 0.6 kW / 4 A for 3-phase 400 V supply networks. Engineered for precise motor speed control in demanding industrial environments, this drive delivers reliable variable-frequency output with minimal footprint — making it the preferred choice for OEMs and system integrators across manufacturing, material handling, and process automation.
Where This Product Is Used
The E70ACPSE0604V is specified across a wide range of industrial applications where compact, accurate speed control is critical:
- Conveyor & Material Handling: Precise belt speed regulation in assembly lines, sorting systems, and logistics conveyors.
- Pump & Fan Control: Energy-efficient flow management in HVAC, water treatment, and process cooling systems.
- Packaging Machinery: Synchronised multi-axis motion in form-fill-seal, labelling, and cartoning equipment.
- Textile & Printing: Tension-controlled winding/unwinding and web-speed regulation.
- Food & Beverage Processing: Hygienic-area motor drives with smooth ramp profiles to protect product integrity.
- Machine Tools: Spindle and feed-axis speed control in CNC and semi-automatic machining centres.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | E70ACPSE0604V |
| Brand | LENZE |
| Series | E70 AC (i700 successor platform) |
| Rated Output Power | 0.6 kW |
| Rated Output Current | 4.0 A |
| Supply Voltage | 3-Phase 380–480 V AC (±10%) |
| Output Frequency Range | 0–599 Hz |
| Control Mode | V/f, Sensorless Vector (SVC) |
| Protection Class | IP20 (panel-mount) |
| Ambient Temperature | -10 °C to +40 °C (up to +55 °C derated) |
| Communication | CANopen, EtherCAT (option), PROFINET (option) |
| Braking | Internal brake chopper ready |
| Weight | 5.3 kg |
| Mounting | DIN rail / panel mount |
| Certifications | CE, UL, RoHS |
Why Engineers Specify This Model
- Compact E70 Platform: The E70 AC series offers a unified parameter structure across the entire power range, reducing engineering time for multi-drive projects.
- Plug-in Fieldbus Modules: Optional EtherCAT, PROFINET, and EtherNet/IP modules allow seamless integration into existing PLC architectures without rewiring.
- Safe Torque Off (STO) Built-in: SIL 2 / PLd safety function eliminates the need for external contactors in many safety circuits, reducing panel space and BOM cost.
- Energy Efficiency: IE2-compliant drive efficiency with automatic energy-saving mode reduces operating costs in continuous-duty applications.
- Rapid Commissioning: LENZE Smart Keypad and »EASY Starter« PC software enable parameter upload/download in minutes, supporting fast machine replication.
Complete System Bill of Materials
For a fully functional E70ACPSE0604V drive installation, consider the following complementary components:
- LENZE E70 Keypad / HMI operator panel
- LENZE E70 fieldbus communication module (EtherCAT / PROFINET)
- LENZE EMC line filter (class C2/C3) for conducted emission compliance
- LENZE braking resistor (external, application-dependent)
- Shielded motor cable (≤ 50 m recommended)
- 24 V DC control power supply (LENZE PSU or equivalent)
- DIN rail mounting hardware and cable management accessories
Compliance & Industry Standards
- CE Marking: Low Voltage Directive 2014/35/EU; EMC Directive 2014/30/EU
- Machinery Safety: EN ISO 13849-1 PLd / IEC 62061 SIL 2 (STO function)
- UL Listed: UL 508C (Power Conversion Equipment)
- RoHS: Compliant with EU Directive 2011/65/EU
- EMC: EN 61800-3 Category C2 (with optional filter)
Quality Assurance & Sourcing
At Konmask.com, every LENZE E70ACPSE0604V unit is:
- Sourced from authorised distribution channels or verified surplus stock with full traceability documentation.
- Inspected for physical integrity, label authenticity, and firmware version consistency prior to dispatch.
- Shipped in original or equivalent ESD-safe packaging with desiccant protection.
- Supported by our 12-month functional warranty and pre-sales technical consultation.
How to Source This Part
- Add to Cart directly on this page for immediate checkout.
- Request a Quote for volume orders (5+ units) — email [email protected] with your project BOM.
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders within 7–14 days.
- Export & Cross-border: We support DDP/DAP Incoterms for EU, SEA, and Middle East destinations. HS Code: 8504.40.
Application-Specific FAQ
Q: Can the E70ACPSE0604V control a single-phase motor?
A: No. This model is designed for 3-phase asynchronous (induction) motors. For single-phase motor control, consult our LENZE SMV series listings.
Q: Is STO wiring required for basic operation?
A: STO inputs must be bridged or properly wired per the safety manual before the drive will enable. Leaving STO open will prevent the drive from running.
Q: What is the maximum motor cable length?
A: LENZE recommends ≤ 50 m shielded cable without output filter; up to 100 m with a dU/dt output filter to protect motor insulation.
Q: Can I use this drive with a SIEMENS or Allen-Bradley PLC?
A: Yes. Via the optional PROFINET or EtherNet/IP fieldbus module, the E70 integrates with any major PLC brand using standard drive profiles (PROFIdrive, CIP).
Q: Is a braking resistor included?
A: No. The internal brake chopper is included, but an external braking resistor must be selected based on your deceleration duty cycle. Contact us for sizing assistance.
