LUST LSG-096-3-30-560/1RB5JZ – AC Servo Drive Motor | LUST Drive Systems
Engineering Background: LUST Antriebstechnik GmbH (now part of the Bonfiglioli Group) is a German precision drive technology manufacturer with decades of expertise in servo and motion control systems. The LSG series represents their high-performance AC servo motor line, engineered for demanding industrial automation environments where positioning accuracy, dynamic response, and thermal stability are non-negotiable.
Product Positioning: The LSG-096-3-30-560/1RB5JZ is a compact, high-torque AC servo motor designed for integration with LUST servo drives and compatible third-party controllers. It is widely deployed in CNC machining centers, packaging lines, robotics, and precision motion stages where reliable closed-loop performance is required.
Complete Technical Specifications
- Manufacturer: LUST Antriebstechnik GmbH (Germany)
- Part Number / SKU: LSG-096-3-30-560/1RB5JZ
- Series: LSG (LUST Servo Motor Series)
- Motor Type: AC Synchronous Servo Motor
- Frame Size: 096 (96 mm flange)
- Pole Pairs: 3
- Rated Speed: 3000 RPM (nominal)
- Rated Voltage: 560 V
- Feedback / Encoder: 1RB5JZ resolver / encoder variant (as per suffix)
- Protection Class: IP65 (standard for LSG-096 series)
- Insulation Class: F (155°C)
- Country of Origin: Germany
- Weight: ~220 g (module/component weight)
- Compliance: CE marked; RoHS compliant
Note: Full datasheet available upon request. Specifications subject to revision per manufacturer updates.
Proven Application Environments
- CNC machining centers and multi-axis milling machines
- High-speed packaging and labeling lines
- Industrial robotics and articulated arm actuators
- Precision pick-and-place and assembly automation
- Textile machinery and winding/unwinding systems
- Semiconductor and electronics manufacturing equipment
- Printing and converting machinery
Engineering Advantages
- High Dynamic Response: Low rotor inertia enables rapid acceleration/deceleration cycles with minimal settling time.
- Thermal Stability: Class F insulation and optimized winding geometry sustain rated torque under continuous duty cycles.
- Compact 96 mm Frame: Space-efficient design for integration into tight machine envelopes without sacrificing torque density.
- Resolver Feedback Precision: The 1RB5JZ encoder/resolver suffix ensures absolute or incremental position feedback compatible with LUST CDA/CDB drive platforms.
- German Engineering Pedigree: Manufactured to DIN/EN standards with rigorous QC protocols at LUST’s German production facility.
System Architecture & Signal Flow
The LSG-096-3-30-560/1RB5JZ operates within a closed-loop servo architecture:
- Controller (PLC/CNC): Issues position/velocity/torque commands via fieldbus (PROFIBUS, CANopen, or analog ±10 V reference).
- LUST Servo Drive (CDA/CDB Series): Receives command signals, executes real-time current control loop, and outputs 3-phase PWM power to the motor.
- LSG-096-3-30-560/1RB5JZ Motor: Converts electrical energy to mechanical torque; resolver/encoder feeds back actual position to the drive.
- Feedback Loop: Position/velocity data returns to the drive at high sampling rates, enabling sub-millisecond correction cycles.
- Safety: STO (Safe Torque Off) function supported via drive integration per IEC 62061 / EN ISO 13849.
Sourcing & Quality Verification
- All units sourced from authorized distributors or verified OEM surplus channels.
- Each unit undergoes incoming inspection: visual check, connector integrity, encoder/resolver continuity test, and winding resistance verification.
- Original manufacturer labels, serial numbers, and date codes are preserved and documented.
- Certificate of conformity and test reports available upon request for critical procurement.
- Packaging: anti-static foam, moisture barrier bag, and rigid outer carton for safe international transit.
Procurement Process
- Inquiry: Submit your part number and required quantity via the order form or email [email protected].
- Quote: Receive a formal quotation with lead time, unit price, and shipping options within 1 business day.
- Order Confirmation: Purchase order accepted; proforma invoice issued for payment processing.
- Quality Check: Unit inspected and documented before dispatch.
- Shipping: Dispatched via DHL Express, FedEx, or UPS with full tracking. Export documentation (commercial invoice, packing list, COO) provided.
- After-Sales: Technical support available post-delivery for installation and commissioning queries.
Technical FAQ
Q: Is the LSG-096-3-30-560/1RB5JZ compatible with third-party servo drives?
A: The motor’s 3-phase AC synchronous design is electrically compatible with many servo drives, but the resolver/encoder interface (1RB5JZ suffix) must be matched to the drive’s feedback input. Consult your drive’s motor compatibility list or contact us for application support.
Q: What does the suffix “1RB5JZ” indicate?
A: The suffix encodes the feedback device variant, shaft/flange options, and brake configuration specific to this build. Full decoding is available in the LUST LSG series motor catalog — contact us for the datasheet.
Q: Can you supply the matching LUST servo drive?
A: Yes. Konmask stocks a range of LUST CDA and CDB series drives. Provide your application requirements and we will recommend the correct drive-motor pairing.
Q: What is the lead time?
A: In-stock units ship within 1–3 business days. For sourced units, typical lead time is 5–15 business days depending on availability.
Q: Do you provide a warranty?
A: Yes. All units carry a 90-day functional warranty against defects in materials and workmanship under normal operating conditions.
