Machine Control & Discrete Output Solution – Mitsubishi FX0N-8ER | FX0N Series
Where This Product Is Used
The Mitsubishi FX0N-8ER is an 8-point relay output extension module designed to expand the I/O capacity of Mitsubishi FX0N series programmable logic controllers. It is widely deployed across demanding industrial environments where reliable discrete output switching is critical:
- Conveyor & Material Handling Systems – Controls motor starters, solenoid valves, and signal lamps along production lines.
- Packaging Machinery – Drives actuators, pneumatic cylinders, and reject mechanisms in high-cycle packaging equipment.
- Machine Tool & CNC Auxiliary Control – Manages coolant pumps, tool changers, and safety interlocks as a relay output expander.
- HVAC & Building Automation – Switches contactors and relays for fan coil units, damper actuators, and pump control panels.
- Food & Beverage Processing – Operates in wash-down-adjacent panels controlling filling, capping, and labeling stations.
- Water Treatment & Pump Stations – Provides isolated relay contacts for pump motor control and alarm annunciation.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | FX0N-8ER |
| Series | Mitsubishi FX0N |
| Module Type | Extension Output Module |
| Output Points | 8 relay outputs |
| Output Type | Relay (R) |
| Rated Load Voltage | AC 240V / DC 30V |
| Max Load Current | 2A per point |
| Response Time (OFF→ON) | ≤10 ms |
| Response Time (ON→OFF) | ≤10 ms |
| Power Consumption | 1.5W (internal) |
| Weight | Approx. 880 g |
| Compatible Base Units | FX0N-14MR, FX0N-24MR, FX0N-40MR, FX0N-60MR |
| Connection Method | Direct bus connector to FX0N main unit |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 75°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Vibration Resistance | 10–57 Hz, 0.075 mm amplitude; 57–150 Hz, 9.8 m/s² |
| Certification | CE, UL |
Why Engineers Specify This Model
- Relay Isolation – Each output point provides galvanic isolation between the PLC logic and field devices, protecting the controller from inductive load spikes.
- AC & DC Load Compatibility – Relay contacts switch both AC 240V and DC 30V loads without additional interface relays, simplifying panel wiring.
- Plug-and-Play Expansion – Connects directly to the FX0N bus without additional power supplies or configuration; recognized automatically by the host PLC.
- Compact DIN-Rail Form Factor – Minimizes panel footprint while delivering 8 additional output channels.
- Proven Mitsubishi Reliability – Part of the globally trusted MELSEC FX0N family, with extensive installed base and long-term spare parts availability.
- Low Maintenance – Relay rated for high mechanical and electrical endurance cycles, reducing unplanned downtime.
Complete System Bill of Materials
For a complete FX0N expansion system, engineers typically specify the following alongside the FX0N-8ER:
- FX0N-14MR / FX0N-24MR / FX0N-40MR / FX0N-60MR – Host PLC main unit
- FX0N-8EX – 8-point DC input extension module (if additional inputs required)
- FX0N-8EYR / FX0N-8EYT – Alternative output extension modules
- FX-20P-E – Handheld programming console
- SC-09 / USB-SC09-FX – PC-to-PLC programming cable
- GX Works2 / GX Developer – Mitsubishi programming software
- 24VDC DIN-rail power supply (e.g., Mitsubishi PS-5VDC or equivalent)
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive
- UL Listed – Recognized for use in North American industrial control panels
- IEC 61131-2 – Programmable controller hardware standard
- RoHS Compliant – Restriction of Hazardous Substances
- IP20 Enclosure Rating – Suitable for installation inside control cabinets
Quality Assurance & Sourcing
All Mitsubishi FX0N-8ER units supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and connector condition
- Functional power-on verification where applicable
- Original manufacturer packaging confirmed (where new stock)
- Batch traceability documentation available on request
We supply both new original and tested surplus stock. Condition is clearly stated on each listing. Contact us to confirm current stock condition and lead time.
How to Source This Part
To place an order or request a quotation for the Mitsubishi FX0N-8ER:
- Online: Add to cart directly on this page for standard orders.
- Bulk / Project Quotation: Email [email protected] with your required quantity and project timeline.
- Phone / WhatsApp: +0086 19859288691 – Available for urgent procurement inquiries.
- Lead Time: In-stock units ship within 1–3 business days. Out-of-stock items: contact us for sourcing timeline.
- Export & International Shipping: We ship globally. DHL, FedEx, and sea freight options available.
Application-Specific FAQ
Q: Can the FX0N-8ER be used with FX1N or FX2N series PLCs?
A: No. The FX0N-8ER is designed exclusively for the FX0N series bus architecture. For FX1N/FX2N expansion, use FX2N-8ER or FX1N-compatible extension modules.
Q: How many FX0N-8ER modules can be connected to one FX0N main unit?
A: The FX0N series supports up to 3 extension modules total (mix of input and output), subject to the maximum I/O point limit of the host unit.
Q: Is the FX0N-8ER suitable for controlling 220V AC motor contactors directly?
A: Yes. The relay contacts are rated for AC 240V / 2A, making them suitable for directly switching standard IEC motor contactors up to the rated current.
Q: Do I need to configure the module in GX Works2 before use?
A: No additional hardware configuration is required. The FX0N main unit automatically detects the extension module. Output addresses are assigned sequentially starting from the last output of the host unit.
Q: What is the difference between FX0N-8ER and FX0N-8EYR?
A: The FX0N-8ER is a combined I/O extension module (typically 4 inputs + 4 outputs in some variants) while the FX0N-8EYR is a dedicated 8-point relay output module. Verify the exact I/O configuration on your unit’s label before installation.
