Industrial Servo Wiring Solution – Mitsubishi MR-J3CN1 | MR-J3 Series
Where This Product Is Used
The Mitsubishi MR-J3CN1 is the OEM-specified signal connector designed exclusively for the MR-J3 series servo amplifier lineup. It is widely deployed across the following industrial environments:
- CNC Machining Centers – Precision axis control wiring between servo amplifier and controller
- Automotive Assembly Lines – High-cycle servo motion systems requiring reliable signal integrity
- Packaging Machinery – Multi-axis servo coordination in form-fill-seal and cartoning equipment
- Semiconductor Fab Equipment – Clean-room compatible servo signal termination
- Injection Molding Machines – Servo pump and clamp axis signal interface
- Robotic Welding Cells – Servo drive signal harness termination points
Wherever a Mitsubishi MR-J3 series amplifier is installed, the MR-J3CN1 is the correct mating connector for the CN1 signal port.
Technical Specifications
- Part Number: MR-J3CN1
- Compatible Series: Mitsubishi MR-J3 Servo Amplifier Series
- Connector Type: CN1 Signal Connector (50-pin)
- Interface: Command pulse / analog speed-torque / I/O signal port
- Mating Standard: OEM-specified for MR-J3-□A / MR-J3-□B amplifiers
- Weight: Approx. 1,450 g (packaged)
- Origin: Japan (Mitsubishi Electric)
- Manufacturer: Mitsubishi Electric Corporation
Why Engineers Specify This Model
- ✅ OEM Exact-Fit – Designed and specified by Mitsubishi Electric; no adaptation or modification required
- ✅ Signal Integrity – Maintains shielding continuity critical for high-speed pulse train and analog command signals
- ✅ Plug-and-Play – Mates directly to the CN1 port of all MR-J3 series amplifiers without tools
- ✅ Reduced Downtime Risk – Using the correct OEM connector eliminates wiring errors during commissioning
- ✅ Long Service Life – Rated for industrial duty cycles in vibration and temperature-variable environments
Complete System Bill of Materials
For a complete MR-J3 servo drive system, engineers typically source the following alongside the MR-J3CN1:
- MR-J3-□A or MR-J3-□B Servo Amplifier (position/speed/torque control)
- HF-KP / HF-MP / HF-SP Series Servo Motor
- MR-J3ENCBL□M-A1-L / A2-L Encoder Cable
- MR-J3BUS□M SSCNET III Optical Cable (for MR-J3-□B)
- MR-PWS1CBL□M-A1-L Power Cable
- MR-BAT Battery Unit (for absolute encoder backup)
Compliance & Industry Standards
- Manufactured under Mitsubishi Electric’s ISO 9001-certified quality management system
- Compliant with CE marking requirements for machinery directive applications
- RoHS compliant materials
- Suitable for use in UL-listed control panel assemblies when used with listed servo amplifiers
Quality Assurance & Sourcing
Konmask.com sources MR-J3CN1 connectors through verified industrial distribution channels. Each unit is:
- Inspected for physical integrity and correct part marking upon receipt
- Stored in ESD-safe, climate-controlled warehouse conditions
- Shipped with original manufacturer packaging where available
- Traceable to batch documentation upon request for MRO and OEM customers
How to Source This Part
To place an order or request a quotation for the Mitsubishi MR-J3CN1:
- 📧 Email: [email protected]
- 📞 Phone / WhatsApp: +0086 19859288691
- 🌐 Online: Add to cart directly at Konmask.com
- Lead time: Typically in-stock; expedited shipping available for urgent MRO requirements
- MOQ: 1 piece; volume pricing available for OEM and system integrator orders
Application-Specific FAQ
Q: Is the MR-J3CN1 compatible with MR-J4 series amplifiers?
A: No. The MR-J4 series uses a different CN1 connector specification. Please verify your amplifier model before ordering.
Q: Does this connector include the shell and strain relief?
A: The MR-J3CN1 is the OEM connector assembly. Please confirm the exact kit contents with our sales team for your specific application.
Q: Can I use a third-party connector instead?
A: Mitsubishi Electric specifies the MR-J3CN1 for all CN1 wiring. Third-party substitutes may compromise signal shielding and void amplifier warranty.
Q: What wire gauge is recommended for CN1 signal wiring?
A: Mitsubishi recommends shielded twisted-pair cable, AWG 24–28, for CN1 signal connections. Refer to MR-J3 Series Servo Amplifier Instruction Manual for full wiring specifications.
Q: Do you offer technical support for MR-J3 system commissioning?
A: Yes. Contact our engineering support team at [email protected] for application guidance.
