MODICON AS-B805-016 input module

Name: MODICON AS-B805-016 input module
SKU: AS-B805-016

Send your required quantity, target delivery time, and destination country. Konmask will reply with availability and lead time.

Series: Schneider Modicon

SKU: AS-B805-016 Category: Other Parts

Description

Discrete I/O Control Solution — MODICON AS-B805-016 | 800 Series

Where This Product Is Used

The MODICON AS-B805-016 is a 16-point discrete input module designed for the Modicon 800 Series PLC platform. It is widely deployed across demanding industrial environments where reliable digital signal acquisition is critical:

Manufacturing & Assembly Lines — Reads limit switches, proximity sensors, and pushbutton states on conveyor and assembly systems.
Process Control Plants — Monitors valve position feedback, flow switches, and level switches in chemical, oil & gas, and water treatment facilities.
Machine Tool & CNC Automation — Captures tool-change confirmations, door interlock signals, and spindle status inputs.
Packaging & Material Handling — Interfaces with photoelectric sensors and encoder pulse inputs on high-speed packaging lines.
Building Automation & HVAC — Integrates with damper end-switches, fan status contacts, and fire/smoke detector dry contacts.
Power Generation & Utilities — Acquires breaker status, relay contact states, and protective relay trip signals in substation control panels.

Technical Specifications

Parameter	Value
Part Number	AS-B805-016
Manufacturer	MODICON (Schneider Electric)
Series	Modicon 800 / Modicon 84
Module Type	Discrete Input Module
Number of Input Points	16
Input Voltage Range	24 V DC (nominal)
Input Logic	Positive / Sink logic
Isolation	Optically isolated inputs
Backplane Interface	Modicon 800 Series I/O bus
Operating Temperature	0 °C to +60 °C
Storage Temperature	-40 °C to +85 °C
Relative Humidity	5% to 95% non-condensing
Weight	Approx. 1,000 g (module + housing)
Mounting	Modicon 800 Series I/O rack

Note: Verify all specifications against the official Modicon 800 Series hardware reference manual before system design. Specifications subject to revision by manufacturer.

Why Engineers Specify This Model

Proven Platform Longevity — The Modicon 800 Series has decades of installed base in heavy industry; AS-B805-016 modules are still actively maintained and sourced for legacy system expansions and replacements.
Optical Isolation — Each input channel is optically isolated, protecting the PLC backplane from field-side voltage transients and ground loops common in industrial environments.
High Channel Density — 16 discrete inputs in a single slot minimizes rack space consumption and reduces wiring complexity compared to lower-density alternatives.
Direct Sensor Compatibility — Accepts standard 24 V DC NPN/PNP sensor outputs without additional signal conditioning hardware.
Simplified Diagnostics — LED status indicators per channel enable rapid field troubleshooting without a programming terminal.
Drop-in Replacement — Fully backward-compatible with existing Modicon 800 Series racks, enabling zero-configuration hot-swap in qualified maintenance scenarios.

Complete System Bill of Materials

For a complete Modicon 800 Series discrete input subsystem, the following components are typically required alongside the AS-B805-016:

Modicon 800 Series I/O Rack (e.g., AS-B801-016 or compatible chassis)
Modicon CPU Module (e.g., AS-884A or equivalent 800 Series processor)
24 V DC Power Supply Module (rack-mounted, DIN-rail, or panel-mount)
Field Wiring Terminal Block / I/O Connector (16-point, compatible pitch)
Shielded Instrumentation Cable (for sensor field wiring runs >10 m)
DIN Rail or Panel Mounting Hardware
Surge Protection Devices (SPDs) for field-side wiring in exposed installations

Contact Konmask for bundle pricing on multi-module orders or complete rack assemblies.

Compliance & Industry Standards

CE Marking — Compliant with applicable EU Low Voltage and EMC Directives (verify current declaration with Schneider Electric).
UL Listed — Suitable for use in UL-listed control panel assemblies (confirm UL file number for current production).
IEC 61131-2 — Discrete input electrical characteristics conform to IEC 61131-2 Type 1/Type 3 input specifications.
RoHS — Manufactured in compliance with RoHS Directive 2011/65/EU restrictions on hazardous substances.
ATEX / IECEx — Standard module is not rated for hazardous area use; consult Schneider Electric for Ex-rated alternatives if required.

Quality Assurance & Sourcing

Konmask.com sources the MODICON AS-B805-016 through established industrial distribution channels with full traceability. Our quality process includes:

Visual & Dimensional Inspection — Each unit inspected for label integrity, connector condition, and housing damage prior to dispatch.
Authenticity Verification — Part markings, date codes, and packaging cross-checked against manufacturer references to screen for non-genuine product.
Functional Pre-check — Where test fixtures are available, modules are powered and input channel LED response verified before shipment.
Documented Chain of Custody — Sourcing records retained for traceability; available to customers upon request for regulated industries.
Warranty — 90-day replacement warranty against defects in materials and workmanship. Contact [email protected] for claims.

How to Source This Part

Add to Cart — Click the purchase button above to place an order directly. Stock is updated in real time.
Request a Quote — For orders of 3+ units or project-based procurement, email [email protected] with your required quantity and delivery timeline.
Expedited Sourcing — If the item shows as out of stock, contact us via WhatsApp or email. We maintain supplier relationships for priority sourcing of legacy Modicon parts.
Export & Cross-border Orders — We ship internationally. Provide your destination country at checkout for accurate freight and duty estimates.
Technical Pre-sales Support — Unsure if this module fits your rack configuration? Send your existing BOM or rack layout to our engineering team for compatibility confirmation before purchase.

Application-Specific FAQ

Q: Is the AS-B805-016 compatible with the Modicon 984 series PLC?
A: The AS-B805-016 is designed for the Modicon 800 Series I/O bus. Compatibility with Modicon 984 racks depends on the specific rack and adapter configuration. Contact us with your rack model for a definitive answer.

Q: Can this module accept 120 V AC field inputs?
A: No. The AS-B805-016 is rated for 24 V DC discrete inputs. For 120 V AC input applications, a different module (e.g., AS-B805-016 AC variant or equivalent) is required.

Q: What is the maximum cable length for field wiring to this module?
A: Modicon guidelines recommend keeping field wiring under 300 m for standard 24 V DC discrete inputs. For longer runs, use shielded cable and consult the hardware reference manual for derating guidelines.

Q: Do you offer programming or configuration support for this module?
A: Konmask specializes in hardware supply. For PLC programming services, we can refer you to qualified Modicon system integrators in your region.

Q: Is this a new or refurbished unit?
A: Units are sourced as new-old-stock (NOS) or factory-refurbished depending on availability. The condition is clearly stated on the product listing and confirmed in the order confirmation. Contact us if you require new-production units only.
