Industrial Network Solution – Schneider Electric (Modicon) MA-0186-100 | Quantum Series
Where This Product Is Used
The MODICON MA-0186-100 Coaxial Cable is engineered for mission-critical industrial communication networks. It is widely deployed in the following environments:
- Modicon Quantum PLC Backplane Networks — connecting remote I/O drops via Modbus Plus (MB+) or S908 coaxial bus topology
- Oil & Gas Processing Plants — SCADA and DCS backbone cabling in hazardous-area control rooms
- Automotive Assembly Lines — high-speed, noise-immune data links between PLCs and distributed I/O racks
- Water & Wastewater Treatment Facilities — long-distance coaxial runs between pump stations and central control systems
- Power Generation & Utilities — substation automation and protection relay communication networks
- Pharmaceutical & Food Processing — GMP-compliant control networks requiring shielded, low-loss signal transmission
Technical Specifications
| Attribute | Value |
|---|---|
| Part Number (SKU) | MA-0186-100 |
| Manufacturer | Schneider Electric / Modicon |
| Series | Modicon Quantum |
| Cable Type | Coaxial (RG-58 / 50 Ω) |
| Application | Modbus Plus (MB+) / S908 Remote I/O Network |
| Connector Type | BNC (standard coaxial termination) |
| Cable Length | 100 ft (approx. 30.5 m) |
| Impedance | 50 Ω nominal |
| Operating Temperature | -20°C to +70°C |
| Weight | 1,280 g |
| Condition | New / Surplus / Refurbished (specify on inquiry) |
Why Engineers Specify This Model
- OEM-Exact Fit — factory-specified cable for Modicon Quantum remote I/O drops; eliminates compatibility guesswork
- Low Signal Attenuation — 50 Ω impedance matched to MB+ network requirements, minimizing reflections and data errors over long runs
- Robust EMI Shielding — braided shield construction rejects electrical noise from VFDs, motors, and high-voltage switchgear common in industrial environments
- Plug-and-Play Termination — pre-terminated BNC connectors reduce installation time and eliminate field-crimping errors
- Proven Longevity — Modicon Quantum architecture remains active in thousands of global installations; this cable supports both legacy maintenance and new greenfield builds
Complete System Bill of Materials
For a complete Modicon Quantum remote I/O network segment, engineers typically pair the MA-0186-100 with:
- 140CRP93200 — Quantum Remote I/O Head Adapter
- 140CRA93200 — Quantum Remote I/O Drop Adapter
- 490NAA27103 — Modbus Plus Network Adapter (tap connector)
- MA-0186-050 — 50 ft coaxial cable (shorter segment option)
- 490NRP25400 — Coaxial cable terminator (75 Ω end-of-line)
Contact support@konmask.com to source complete BOM packages.
Compliance & Industry Standards
- Compatible with IEC 61158 (Industrial Communication Networks — Fieldbus)
- Supports Modbus Plus protocol per Schneider Electric specification
- Cable construction compliant with UL 444 (Communications Cables)
- RoHS-compliant materials (confirm with batch documentation on request)
- Suitable for use in ATEX Zone 2 / Class I Div 2 installations when installed per local electrical codes
Quality Assurance & Sourcing
At Konmask.com, every MODICON MA-0186-100 unit is:
- Sourced from authorized distributors or verified surplus channels
- Inspected for physical integrity, connector condition, and shielding continuity
- Stored in ESD-safe, climate-controlled warehousing
- Shipped with original manufacturer packaging where available
- Backed by our 30-day return policy and post-sale technical support
How to Source This Part
- Add to Cart — click the purchase button above for immediate checkout
- Request a Quote — email support@konmask.com for volume pricing or BOM sourcing
- Call / WhatsApp — reach our engineering sales team at +0086 19859288691
- Lead Time — in-stock items ship within 1–3 business days; ex-stock orders quoted within 24 hours
Application-Specific FAQ
Q: Is the MA-0186-100 compatible with Modbus Plus (MB+) networks?
A: Yes. This cable is the OEM-specified coaxial cable for Modicon Quantum MB+ and S908 remote I/O networks, terminated with standard BNC connectors.
Q: Can I use this cable with non-Modicon equipment?
A: The cable is a standard 50 Ω RG-58 coaxial cable with BNC termination. It can be used in any application requiring this specification, though it is optimized for Modicon Quantum network topology.
Q: What is the maximum network segment length using this cable?
A: Modbus Plus supports up to 450 m (1,500 ft) per segment with up to 32 nodes. The MA-0186-100 (100 ft / 30.5 m) is ideal for inter-rack drops within a segment.
Q: Do you offer custom cable lengths?
A: We stock standard Modicon cable lengths. For custom requirements, contact our team for sourcing options.
Q: Is documentation or a datasheet available?
A: Yes. Request the Schneider Electric product datasheet and installation guide via support@konmask.com.
