Motorola FRCE CPCI-745 PMK050608E02 Single-Board | Replacement, Equivalent & Selection Guide
The Motorola FRCE CPCI-745 PMK050608E02 is a high-performance CompactPCI (CPCI) single-board computer designed for demanding industrial, defense, and embedded computing applications. This page provides full technical specifications, compatible replacement models, selection guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
- Manufacturer: Motorola (now part of EMERSON / Artesyn / Abaco Systems lineage)
- Part Number: FRCE CPCI-745 / PMK050608E02
- Form Factor: CompactPCI (CPCI) — 6U
- Board Type: Single-Board Computer (SBC)
- Bus Standard: CompactPCI (PICMG 2.0)
- Processor Architecture: PowerPC / x86 (confirm with datasheet for exact CPU)
- Operating Temperature: 0°C to +55°C (industrial grade)
- Compliance: CE, RoHS (verify with original documentation)
- Weight: Approx. 200 g
- Condition Available: New, Refurbished, Tested Used
Note: Always verify specifications against the original Motorola datasheet or contact Konmask for a detailed spec sheet.
Compatible Replacement & Equivalent Models
If the FRCE CPCI-745 PMK050608E02 is discontinued, hard to source, or cost-prohibitive, the following models may serve as functional equivalents or drop-in replacements depending on your system architecture:
- Motorola CPCI-735 — Earlier generation CPCI SBC, compatible bus interface
- Motorola CPCI-750 — Upgraded successor with enhanced processing capability
- Emerson / Artesyn CPCI-7A4 — Direct lineage replacement for Motorola CPCI series
- Abaco Systems SBC6712 — 6U CPCI SBC with PowerPC architecture, pin-compatible options
- Kontron CP6004 — 6U CompactPCI SBC, widely used as cross-brand equivalent
- Radisys EPC-3305 — x86-based CPCI SBC for mixed-architecture migration
Important: Replacement compatibility depends on your backplane, OS, and firmware. Contact support@konmask.com for a validated compatibility assessment before substitution.
Why Choose the Original Model
- Proven Reliability: The FRCE CPCI-745 has an established track record in mission-critical environments including defense, telecom, and industrial control.
- Exact Fit: No firmware re-qualification or backplane modification required when using the original part number.
- Long-Term Support: Spare parts and tested-used units remain available through specialist distributors like Konmask.
- Regulatory Compliance: Original units carry existing certifications — critical for regulated industries.
Typical Applications
- Defense and aerospace embedded computing systems
- Industrial automation and process control platforms
- Telecommunications infrastructure (ATCA/CPCI chassis)
- Test & measurement equipment
- Railway and transportation control systems
- Scientific instrumentation and data acquisition
System Compatibility
- Chassis: Standard 6U CompactPCI chassis (PICMG 2.0 compliant)
- Backplane: 32-bit / 64-bit CPCI backplane
- Operating Systems: VxWorks, LynxOS, Linux (kernel version dependent), QNX
- Peripheral I/O: Ethernet, Serial (RS-232/422), USB, PMC expansion site
- Power Supply: Standard CPCI -48V or +5V/+3.3V depending on chassis configuration
Selection Guide
Use the following criteria to determine whether the FRCE CPCI-745 PMK050608E02 or an equivalent is right for your application:
- Step 1 — Confirm Form Factor: Verify your chassis accepts 6U CompactPCI boards (PICMG 2.0).
- Step 2 — Check Processor Requirement: Confirm whether your software stack requires PowerPC or x86 architecture.
- Step 3 — Validate I/O Needs: Match required interfaces (Ethernet ports, serial, PMC site) to the board’s I/O specification.
- Step 4 — Assess OS Compatibility: Ensure your RTOS or OS is supported by the board’s BSP (Board Support Package).
- Step 5 — Evaluate Lifecycle: For long-term projects, consider availability of spare units and support from the supplier.
- Step 6 — Request a Quote: Contact Konmask with your quantity, condition preference (new/refurbished), and delivery timeline.
Quality Assurance & Sourcing
- All units sourced through Konmask undergo visual inspection, functional testing, and ESD-safe handling.
- Refurbished units are restored to factory-equivalent performance standards.
- Traceability documentation available upon request (test reports, country of origin).
- Secure anti-static packaging for international shipping.
- Warranty: 90-day replacement warranty on tested units (terms apply).
How to Order
- Add the item to your cart and proceed to checkout, or
- Email support@konmask.com with your part number, quantity, and required condition.
- For bulk orders or OEM procurement, request a formal quotation via email.
- Lead time: In-stock units ship within 1–3 business days. Special orders: 5–15 business days.
- Payment: T/T (Bank Transfer), PayPal, and major credit cards accepted.
Replacement & Compatibility FAQ
Q: Is the Motorola FRCE CPCI-745 PMK050608E02 still in production?
A: This model is from Motorola’s legacy CPCI SBC line. Production has been discontinued by the OEM. Konmask specializes in sourcing tested new-old-stock and refurbished units.
Q: Can I replace the CPCI-745 with a Kontron or Emerson board?
A: Potentially yes, if the replacement board is PICMG 2.0 compliant and your software supports the new BSP. We recommend a compatibility review before substitution — contact us for assistance.
Q: Do you provide a test report with the unit?
A: Yes. Functional test reports are available upon request for refurbished units.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. If not in stock, typical sourcing lead time is 5–15 business days.
Q: Can Konmask help identify the right replacement if this exact part is unavailable?
A: Absolutely. Send us your system details and we will recommend a validated equivalent from our inventory.
