Fluorescence & Imaging Solution — OLYMPUS U-TV1X U-CMAD-2 | BX/IX Series
SKU: OLY-UTV1X-UCMAD2-URLA-E62706200-E11706200-XENUS800-1953-UTLU-UCLW
This complete OLYMPUS microscope camera adapter assembly integrates the U-TV1X trinocular adapter, U-CMAD-2 C-mount camera adapter, U-RLA reflected light attachment, E62706200 and E11706200 fluorescence filter components, XENUS PLUS 800-1953 LED controller, U-TLU port tube, and U-CLW wide-field eyepiece — delivering a turnkey imaging solution for advanced life science and materials research microscopy.
Where This Product Is Used
- Fluorescence Microscopy Labs — Universities, research institutes, and pharmaceutical R&D centers using OLYMPUS BX or IX series microscopes for GFP, DAPI, TRITC, and multi-channel fluorescence imaging.
- Pathology & Histology Departments — Clinical labs requiring high-fidelity digital image capture for H&E and immunofluorescence slides.
- Materials Science & Semiconductor Inspection — Engineers inspecting wafer surfaces, thin films, and microstructures under reflected light (U-RLA) with camera documentation.
- Live Cell Imaging — Time-lapse and video microscopy setups where the XENUS PLUS 800-1953 LED controller provides stable, low-heat illumination for sensitive specimens.
- OEM & System Integrators — Building custom automated microscopy platforms requiring certified OLYMPUS optical components.
Technical Specifications
- Brand: OLYMPUS
- Series: BX / IX Modular Microscopy System
- SKU: OLY-UTV1X-UCMAD2-URLA-E62706200-E11706200-XENUS800-1953-UTLU-UCLW
- Part Numbers Included: U-TV1X · U-CMAD-2 · U-RLA · E62706200 · E11706200 · XENUS PLUS 800-1953 · U-TLU · U-CLW
- Adapter Type: 1× Trinocular Camera Adapter (U-TV1X) with C-mount output (U-CMAD-2)
- Illumination Controller: XENUS PLUS 800-1953 LED Driver
- Port Tube: U-TLU (for BX2/IX2 series)
- Eyepiece: U-CLW Wide-field Compensating Eyepiece
- Reflected Light Attachment: U-RLA
- Filter Components: E62706200, E11706200
- Weight: 2,600 g (complete assembly)
- Condition: Used / Refurbished — inspected and verified functional
Why Engineers Specify This Model
- 1× Magnification Factor (U-TV1X) — Preserves the full field of view on the camera sensor without cropping, critical for large-format CMOS/CCD sensors.
- Parfocal C-mount Interface (U-CMAD-2) — Ensures parfocality between eyepiece and camera port, eliminating refocusing when switching between visual and digital observation.
- Stable LED Illumination (XENUS PLUS 800-1953) — Flicker-free, intensity-stable output protects photosensitive samples and ensures reproducible exposure settings across sessions.
- Modular BX/IX Compatibility — All components are native OLYMPUS parts, guaranteeing optical alignment and mechanical fit without third-party adapters.
- Complete Kit Advantage — Sourcing all components as a verified, matched set eliminates compatibility risk and reduces procurement lead time.
Complete System Bill of Materials
- U-TV1X — 1× Trinocular Camera Adapter
- U-CMAD-2 — C-mount Camera Adapter
- U-RLA — Reflected Light Attachment
- E62706200 — Fluorescence Filter Component
- E11706200 — Fluorescence Filter Component
- XENUS PLUS 800-1953 — LED Illumination Controller
- U-TLU — Port Tube (BX2/IX2)
- U-CLW — Wide-field Compensating Eyepiece
Compliance & Industry Standards
- Manufactured by OLYMPUS Corporation to ISO 9001 quality standards
- Optical components comply with JIS B 7153 microscope standards
- XENUS PLUS controller meets CE and RoHS directives
- Compatible with GLP/GMP laboratory documentation requirements
Quality Assurance & Sourcing
All units listed on Konmask.com are physically inspected prior to listing. This assembly has been verified for mechanical integrity and optical alignment. High-resolution images of the actual unit are provided. We source exclusively from decommissioned research institutions, certified equipment dealers, and authorized OLYMPUS service partners.
How to Source This Part
This is a low-volume, high-specificity assembly. Stock is limited. To confirm availability, request a formal quotation, or inquire about alternative OLYMPUS imaging components, contact our team directly:
- 📧 [email protected]
- 📞 +0086 19859288691
- 🌐 Konmask.com
Application-Specific FAQ
Q: Is the U-TV1X compatible with full-frame mirrorless cameras?
A: Yes, via a C-mount to appropriate camera mount adapter (not included). The 1× factor is ideal for full-frame sensors to maximize field coverage.
Q: Which OLYMPUS microscope bodies is this kit compatible with?
A: Primarily BX51, BX53, BX61, IX71, IX81, and IX83 series. Confirm port configuration before ordering.
Q: What cameras are compatible with the U-CMAD-2 C-mount output?
A: Any C-mount scientific camera (e.g., Hamamatsu ORCA, Andor Zyla, Teledyne Photometrics) or industrial camera with C-mount interface.
Q: Is the XENUS PLUS 800-1953 compatible with third-party LED light guides?
A: It is designed for OLYMPUS-specified LED modules. Third-party compatibility should be verified against the controller’s output specifications.
Q: Can you provide a condition report or additional photos?
A: Yes. Contact us at [email protected] with your request and we will provide a detailed condition report within 1 business day.
