Genuine Allen-Bradley 1769-OV32T CompactLogix Solid State Output Module | 1769 Series – Verified Source
The Allen-Bradley 1769-OV32T is a mission-critical 32-point solid-state DC output module within Rockwell Automation’s CompactLogix 1769 series — a platform trusted across global manufacturing, oil & gas, water treatment, and discrete automation industries. As demand for this module remains consistently high, the market has seen a significant influx of counterfeit, refurbished-as-new, and grey-market units that carry serious risks: unexpected system faults, failed safety interlocks, and costly unplanned downtime. Sourcing from unverified channels is a risk no production environment can afford.
At Konmask, every 1769-OV32T we supply is genuine, factory-original Allen-Bradley hardware. We source exclusively through authorized distribution networks and verified OEM channels, maintaining full traceability from manufacturer to delivery. Each unit is individually inspected and documented before shipment. Our commitment to authenticity is embedded in every step of our process — from procurement to packing — ensuring you receive a verified, authentic module backed by transparent documentation.
Technical Specifications
- Part Number: 1769-OV32T
- Series: CompactLogix 1769
- Module Type: Solid State DC Output
- Number of Outputs: 32 points
- Output Voltage Range: 10–28.8V DC
- Output Current per Point: 0.5A max
- Total Module Current: 4A max (all outputs ON)
- Output Type: Sourcing (PNP)
- Backplane Current Draw (5V DC): 120 mA
- Backplane Current Draw (24V DC): 0 mA
- Isolation: 100% optical isolation between field side and logic side
- Operating Temperature: 0–60°C (32–140°F)
- Storage Temperature: -40–85°C (-40–185°F)
- Relative Humidity: 5–95% non-condensing
- Enclosure Rating: Open type (IP20)
- Certifications: UL, CE, CSA, RCM
- Dimensions (H × W × D): 118 × 35 × 87 mm
- Weight: Approx. 300 g
Specifications verified against Allen-Bradley / Rockwell Automation official documentation (Publication 1769-TD006).
Our 4-Step Quality Verification Process
- Step 1 – Source Authentication: All units are procured exclusively from authorized Allen-Bradley distributors or verified OEM surplus channels. Purchase records and distributor certificates are retained for full traceability.
- Step 2 – Physical Inspection: Each module undergoes visual inspection for label integrity, firmware revision markings, housing condition, connector pin alignment, and anti-tamper seal verification. Counterfeit indicators (mismatched fonts, incorrect label materials, off-spec housing) are checked against genuine reference units.
- Step 3 – Functional Testing: Where applicable, modules are bench-tested for output channel continuity, optical isolation integrity, and backplane communication response. Test results are logged and available upon request as a Test Report.
- Step 4 – Documentation Package: Every shipment is accompanied by a Packing List, Certificate of Conformance (COC), Country of Origin (COO) Declaration, and optional Test Report. Photos of the actual unit prior to packing are available on request.
Key Features & Benefits
- 32 Individually Isolated Solid-State Outputs: Eliminates mechanical wear and extends service life compared to relay output modules — aligned with IEC 61131-2 PLC output module standards.
- Sourcing (PNP) Output Architecture: Compatible with standard industrial field devices including solenoid valves, indicator lamps, and motor starters operating at 10–28.8V DC.
- Optical Isolation: Full galvanic isolation between field-side and logic-side circuitry protects the controller backplane from field-side transients and surge events, per IEC 61000-4-5 surge immunity requirements.
- Compact 1769 Form Factor: Direct plug-and-play compatibility with CompactLogix L1x, L2x, L3x, and L4x controller families — no additional adapters required.
- Low Heat Dissipation: Solid-state design minimizes thermal load on the control panel, supporting high-density I/O configurations in space-constrained enclosures.
- Rockwell Automation Studio 5000 / RSLogix 5000 Compatible: Full EDS file support and native integration with Rockwell’s programming environment for rapid commissioning and diagnostics.
Typical Applications
- Discrete Manufacturing: Controlling conveyor drives, pneumatic actuators, and assembly line solenoids in automotive and electronics production lines.
- Oil & Gas: Driving valve actuators and pump control outputs in wellhead automation and pipeline SCADA systems.
- Water & Wastewater Treatment: Managing pump station outputs, dosing system actuators, and UV disinfection control in municipal water facilities.
- Food & Beverage: Controlling filling line actuators, conveyor indexing, and CIP (Clean-In-Place) valve outputs in hygienic processing environments.
- Building Automation & HVAC: Driving damper actuators, fan starters, and chiller control outputs in large commercial building management systems.
- Machine Tool & Robotics: Providing high-speed, high-cycle output switching for CNC machine tool auxiliaries and robotic end-of-arm tooling control.
Compatible System Components
- 1769-L16ER-BB1B / L18ER / L24ER / L30ER / L33ER / L36ERM — CompactLogix Controllers
- 1769-PA2 / 1769-PB2 — CompactLogix Power Supplies
- 1769-ECR / 1769-ECL — End Caps (Right / Left)
- 1769-IQ32 / 1769-IQ32T — Companion 32-Point DC Input Modules
- 1769-OF4 / 1769-IF4 — Analog Output / Input Modules
- 1756-EN2T / 1756-EN3TR — EtherNet/IP Communication Modules (ControlLogix)
- 20-HIM-A6 / 20-HIM-C6S — PowerFlex HIM Operator Interfaces
Global Sourcing & Shipping Capabilities
- Primary Service Regions: Mainland China, Hong Kong SAR, Southeast Asia (Vietnam, Thailand, Malaysia, Indonesia), Middle East (UAE, Saudi Arabia), Europe (Germany, Netherlands, Poland), and North America (USA, Canada, Mexico).
- Packaging Standard: Anti-static ESD bag + foam-lined carton + moisture-barrier outer packaging. Fragile/high-value units are double-boxed with shock-absorbing inserts.
- Export Documentation: Commercial Invoice, Packing List, COO Declaration, and COC provided as standard. HS Code: 8537.10 (programmable controllers / I/O modules).
- Logistics Partners: DHL Express, FedEx International Priority, UPS Worldwide, and sea freight consolidation for bulk orders. Typical transit: 3–7 business days (air); 15–25 days (sea).
- Lead Time: In-stock units ship within 1–2 business days of order confirmation. Pre-order units: 5–15 business days depending on sourcing channel.
Certifications & Compliance Statement
- UL Listed — UL 508 (Industrial Control Equipment)
- CE Marked — EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- CSA Certified — CSA C22.2 No. 142 (Process Control Equipment)
- RCM Mark — Australian/New Zealand EMC compliance
- RoHS Compliant — Directive 2011/65/EU (Restriction of Hazardous Substances)
Konmask Quality Commitment: All products supplied by Konmask.com are sourced from verified channels and subject to our documented inspection process. We provide full traceability documentation upon request and stand behind the authenticity of every unit we ship. If any product is found to be non-genuine, we will provide a full replacement or refund — no questions asked.
