OMRON CQM1-ID213 24VDC 16-Point DC Input Module | Replacement, Equivalent & Selection Guide
The OMRON CQM1-ID213 is a 16-point DC input module designed for the OMRON CQM1 series programmable logic controller (PLC). It accepts 24 VDC signals and is widely deployed in discrete manufacturing, machine automation, and process control applications. This page provides full technical specifications, verified compatible replacements, and a structured selection guide to help engineers and procurement teams source the right module with confidence.
Technical Specifications
- Model: CQM1-ID213
- Manufacturer: OMRON Corporation
- Series: CQM1
- Module Type: DC Input Module
- Number of Input Points: 16 points
- Input Voltage: 24 VDC
- Input Current: Approx. 7 mA per point at 24 VDC
- ON Voltage: 14.4 VDC min.
- OFF Voltage: 5 VDC max.
- Response Time: 1 ms (default); adjustable via software
- Isolation: Photocoupler isolation
- Connector Type: Screw terminal (34-pin)
- Indicators: LED per input point
- Operating Temperature: 0 °C to 55 °C
- Storage Temperature: −20 °C to 75 °C
- Humidity: 10% to 90% RH (non-condensing)
- Weight: Approx. 200 g
- Standards: CE, UL, cUL
Compatible Replacement & Equivalent Models
The following models are verified as direct or functional replacements for the CQM1-ID213. Always confirm firmware compatibility and I/O mapping before substitution in a live system.
- OMRON CQM1-ID212 – 16-point 24 VDC input, NPN sink type; functionally equivalent with minor wiring differences
- OMRON CQM1H-ID211 – CQM1H-series equivalent; compatible with CQM1H CPU units
- OMRON CS1W-ID211 – CS1-series 16-point DC input; suitable for system migration to CS1 platform
- OMRON CJ1W-ID211 – CJ1-series 16-point DC input; recommended for new designs replacing CQM1 architecture
- Third-party equivalents: Certain Mitsubishi Q-series and Siemens S7-300 SM321 modules offer comparable I/O specs but require adapter backplanes and program re-mapping
Why Choose the Original CQM1-ID213
- Guaranteed pin-for-pin compatibility with all CQM1 CPU and backplane units
- Factory-calibrated response time ensures deterministic control loop performance
- Full OMRON technical support, firmware updates, and long-term spare parts availability
- CE / UL certified — meets international safety and EMC standards out of the box
- Photocoupler isolation protects the CPU from field-side voltage transients
Typical Applications
- Discrete manufacturing: conveyor control, pick-and-place, assembly line interlocking
- Packaging machinery: sensor feedback, position detection, reject gate control
- Food & beverage: level sensing, flow detection, safety interlock monitoring
- HVAC & building automation: status monitoring of contactors, switches, and relays
- Semiconductor & electronics: wafer handling, test fixture I/O acquisition
System Compatibility
- Compatible CPUs: CQM1-CPU11-E, CQM1-CPU21-E, CQM1-CPU41-EV1, CQM1-CPU43-EV1, CQM1-CPU45-EV1
- Backplane: CQM1-BC031, CQM1-BC051, CQM1-BC081, CQM1-BC101
- Programming Software: CX-Programmer (CX-One suite)
- Communication: Compatible with OMRON Host Link, DeviceNet, and CompoBus/S via respective master units
- Not compatible with: CPM1, CPM2A, or C200H series without adapter modules
Selection Guide
Use the following criteria to confirm the CQM1-ID213 is the correct module for your application, or to identify the best alternative:
- Input voltage: If your field devices output 24 VDC → CQM1-ID213 ✓ | If 100–120 VAC → consider CQM1-IA121
- Point count: 16 points sufficient → CQM1-ID213 ✓ | Need 32 points → CQM1-ID232
- Sink/Source wiring: NPN (sink) devices → CQM1-ID213 ✓ | PNP (source) devices → CQM1-ID212
- Platform migration: Staying on CQM1 → CQM1-ID213 ✓ | Upgrading to CJ2 → CJ2M-MD211
- Response time requirement: Standard 1 ms → CQM1-ID213 ✓ | High-speed <0.1 ms → CQM1-ID112 (interrupt input)
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels with full traceability
- Each module undergoes incoming inspection: visual check, label verification, and functional power-on test
- Anti-static packaging with humidity indicator card for safe long-distance shipping
- Certificates of conformance (CoC) available upon request
- Warranty: 12 months from date of shipment against manufacturing defects
How to Order
- Part Number: CQM1-ID213
- Minimum Order Quantity: 1 unit
- Lead Time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
- Payment: T/T, PayPal, credit card, and trade assurance accepted
- Shipping: DHL / FedEx / UPS express worldwide; sea freight available for bulk orders
- To request a quote or check real-time stock, contact support@konmask.com or call +0086 19859288691
Replacement & Compatibility FAQ
- Q: Can I use CQM1-ID213 in a CQM1H system?
- A: Yes. CQM1 I/O modules are mechanically and electrically compatible with CQM1H backplanes. Verify slot allocation in CX-Programmer.
- Q: What is the difference between CQM1-ID212 and CQM1-ID213?
- A: Both are 16-point 24 VDC input modules. The ID212 uses NPN (sink) input logic; the ID213 uses NPN input with a different internal circuit revision. Check your wiring diagram before substituting.
- Q: Is the CQM1-ID213 still in production?
- A: OMRON has announced end-of-life for the CQM1 series. Konmask.com maintains stock of genuine new and refurbished units. For long-term projects, we recommend migrating to the CJ2 or NX1P2 platform.
- Q: Can I mix CQM1-ID213 with analog I/O modules on the same backplane?
- A: Yes. The CQM1 backplane supports mixed digital and analog modules. Ensure total current draw does not exceed the power supply unit (PSU) rating.
- Q: Do you provide a test report with the module?
- A: Yes. A functional test report and CoC are available upon request at no additional charge.
