Schneider Electric 140ARI03010 RTD Input Module 8-Channel | Replacement, Equivalent & Selection Guide
The Schneider Electric 140ARI03010 is an 8-channel RTD (Resistance Temperature Detector) analog input module designed for the Modicon Quantum PLC platform. It supports 2-wire, 3-wire, and 4-wire RTD configurations, making it a versatile solution for precision temperature measurement in industrial automation and process control environments. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
- Part Number: 140ARI03010
- Manufacturer: Schneider Electric (Modicon)
- Platform: Modicon Quantum PLC
- Module Type: Analog Input – RTD
- Number of Channels: 8
- Wiring Configurations: 2-wire, 3-wire, 4-wire
- Supported Sensor Types: Pt100, Pt1000, Ni100, Ni1000, Cu10 (and other standard RTD types)
- Resolution: 16-bit
- Accuracy: ±0.1°C (typical, 4-wire configuration)
- Input Range: –200°C to +850°C (Pt100)
- Isolation: Channel-to-backplane isolation
- Power Consumption: Supplied via Quantum backplane
- Backplane Compatibility: Modicon Quantum I/O backplanes (140 XBP series)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: –40°C to +85°C
- Relative Humidity: 5% to 95% (non-condensing)
- Certifications: CE, UL, cUL
- Weight: Approx. 450 g
Compatible Replacement & Equivalent Models
When the 140ARI03010 is unavailable or end-of-life, the following models may serve as functional replacements or equivalents. Always verify firmware, backplane, and software compatibility before substitution.
- 140ARI03010C – Conformal-coated variant of the same module; direct drop-in replacement for harsh environments
- 140AII03000 – Schneider Electric 8-channel analog input (current/voltage); not RTD-specific but used in mixed I/O architectures
- BMXART0814 – Schneider Electric Modicon M340 8-channel RTD module; requires platform migration from Quantum to M340
- TSXAEM811 – Schneider Electric Premium platform RTD module; legacy cross-reference for mixed-fleet environments
- Third-party Quantum-compatible RTD modules – Select vendors offer Quantum-form-factor RTD modules; confirm register mapping and Unity Pro compatibility
Note: Konmask.com supplies both original Schneider Electric modules and verified compatible alternatives. Contact us for availability and lead time.
Why Choose the Original Model
- Native Quantum Integration: Plug-and-play with Modicon Quantum backplanes — no firmware patches or register remapping required
- Proven Accuracy: Factory-calibrated 16-bit resolution ensures ±0.1°C measurement precision in 4-wire mode
- Multi-wire Flexibility: Supports 2-, 3-, and 4-wire RTD wiring in a single module, reducing spare-parts inventory
- Long Field Track Record: Widely deployed in oil & gas, chemical, and power generation plants since the 1990s
- Unity Pro / Control Expert Support: Full diagnostic and configuration support within Schneider’s native engineering environment
- Regulatory Compliance: CE, UL, cUL certified for global deployment
Typical Applications
- Process temperature monitoring in chemical and petrochemical plants
- Boiler and heat exchanger control in power generation facilities
- HVAC and building management systems requiring multi-point RTD sensing
- Food and beverage processing with strict temperature compliance requirements
- Pharmaceutical manufacturing (GMP-compliant temperature logging)
- Water and wastewater treatment plant instrumentation
- Steel and metals processing furnace temperature control
System Compatibility
- PLC Platform: Modicon Quantum (140 series)
- Backplanes: 140XBP00200, 140XBP00400, 140XBP00600, 140XBP01000, 140XBP01600 and other Quantum I/O backplanes
- Power Supplies: 140CPS11100, 140CPS11420, 140CPS21100 (standard Quantum PSUs)
- CPUs: All Modicon Quantum CPU modules (140CPU series)
- Programming Software: Unity Pro (v2.0+), Control Expert (v14.0+)
- Communication: Modbus, Modbus Plus, Ethernet I/O via Quantum head-end architecture
- Not Compatible With: Modicon M340, M580, Premium, or Momentum platforms without hardware migration
Selection Guide
Use the criteria below to confirm the 140ARI03010 is the right module for your application, or to identify the best alternative:
- Platform: If your system is Modicon Quantum → 140ARI03010 is the native choice. For M340 → consider BMXART0814. For M580 → consider BMAART0414H.
- Channel Count: 8 channels per module. For 16-channel density, consider stacking two modules or evaluating third-party high-density alternatives.
- Wiring Type: 4-wire RTD delivers highest accuracy (±0.1°C); 3-wire is standard for most industrial RTDs; 2-wire is suitable for short cable runs only.
- Environment: Standard environments → 140ARI03010. Corrosive or high-humidity environments → 140ARI03010C (conformal coated).
- Budget vs. OEM: OEM original recommended for safety-critical loops. Verified compatible alternatives available for non-critical monitoring points — contact Konmask for options.
- Lead Time Sensitivity: Konmask.com maintains stock of both new and refurbished units. Expedited shipping available for urgent MRO requirements.
Quality Assurance & Sourcing
- Source: Authorized distribution channels and verified secondary market suppliers
- Inspection: All modules undergo visual inspection, label verification, and functional power-on testing before shipment
- Condition Options: New (factory-sealed), Refurbished (tested & warranted), and Used (as-is with inspection report)
- Warranty: 12-month warranty on new units; 6-month warranty on refurbished units
- Traceability: Serial number and batch documentation available on request
- Packaging: ESD-safe anti-static packaging; original Schneider Electric box where available
How to Order
- Step 1: Confirm your Modicon Quantum backplane model and available slot count
- Step 2: Specify required condition: New / Refurbished / Used
- Step 3: Add to cart or contact us directly for bulk pricing and lead time
- Step 4: Provide your shipping address and preferred freight method (DHL, FedEx, sea freight available)
- Step 5: Receive order confirmation with tracking number within 1 business day of payment
📧 Email: support@konmask.com
📞 Phone/WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Is the 140ARI03010C a direct replacement for the 140ARI03010?
A: Yes. The “C” suffix denotes conformal coating only. All electrical and functional specifications are identical. It is a drop-in replacement.
Q: Can I use the 140ARI03010 on a Modicon M340 or M580 system?
A: No. The 140ARI03010 is mechanically and electrically specific to the Quantum backplane. M340 and M580 use different form-factor modules (BMX and BM series respectively).
Q: What RTD sensor types are supported?
A: The module supports Pt100, Pt1000, Ni100, Ni1000, Cu10, and other standard IEC 60751-compliant RTD types. Refer to the Unity Pro/Control Expert configuration for the full sensor type list.
Q: Does Konmask.com provide a warranty on used modules?
A: Used (as-is) modules are sold with an inspection report but without warranty. Refurbished modules carry a 6-month warranty. Contact us for details.
Q: What is the typical lead time for the 140ARI03010?
A: In-stock units ship within 1–3 business days. Out-of-stock units typically have a 2–6 week lead time depending on sourcing. Contact us for real-time availability.
Q: Can I mix 2-wire and 4-wire RTDs on the same module?
A: Yes. Each channel is independently configurable for 2-, 3-, or 4-wire RTD input via software configuration in Unity Pro / Control Expert.
