AC Servo Motion Control Solution – OMRON R88M-1M10030T-S2 | 1S Series
The OMRON R88M-1M10030T-S2 is a high-performance AC servo motor from OMRON’s 1S Series, rated at 1 kW / 3000 rpm with an absolute encoder. Designed for demanding industrial motion control applications, this motor pairs with the OMRON Sysmac platform and G5/1S servo drives to deliver precise, repeatable positioning across a wide range of automation environments.
Full SKU Bundle: R88M-1M10030T-S2 + R88A-CA1A005S (5m power cable) + 03009-MA24-1003 + Ref: 140008320 / 150008320
Where This Product Is Used
- CNC Machining Centers – Axis feed drives requiring ±1 arc-minute repeatability and high dynamic stiffness.
- Semiconductor & Electronics Assembly – Pick-and-place, die bonding, and wafer handling where micron-level positioning is critical.
- Packaging Machinery – High-speed intermittent motion for form-fill-seal, cartoning, and labeling lines.
- Robotic Arms & Collaborative Robots – Joint actuation in 6-axis industrial robots and SCARA systems.
- Printing & Converting Equipment – Register control and tension management on web-fed presses.
- Conveyor & Material Handling – Synchronised multi-axis transport systems in automotive and logistics facilities.
- Medical Device Manufacturing – Cleanroom-compatible motion for dispensing, inspection, and assembly automation.
Technical Specifications
- Model: R88M-1M10030T-S2
- Series: OMRON 1S Servo Motor
- Rated Output Power: 1.0 kW
- Rated Speed: 3000 rpm
- Encoder Type: 23-bit Absolute Encoder
- Voltage: 200–240 V AC (3-phase)
- Rated Torque: 3.18 N·m
- Peak Torque: 9.55 N·m
- Inertia: 0.88 × 10⁻⁴ kg·m²
- Protection Rating: IP67 (shaft seal included)
- Brake: Without brake (T suffix = standard shaft)
- Frame Size: 80 mm
- Weight: Approx. 2.6 kg
- Mounting: Flange mount (IEC 72-1)
- Companion Cable: R88A-CA1A005S (5 m, standard flex)
- Reference Part Numbers: 03009-MA24-1003 / 140008320 / 150008320
Why Engineers Specify This Model
- 23-bit Absolute Encoder – 8,388,608 pulses/rev eliminates homing routines after power loss, reducing machine downtime.
- IP67 Sealing – Withstands coolant splash, wash-down, and dusty factory environments without additional enclosures.
- 1S EtherCAT Integration – Native EtherCAT (CoE) via matched R88D-1SN10F drive enables sub-millisecond cycle times on Sysmac NJ/NX PLCs.
- High Overload Capacity – 300% peak torque for 3 seconds handles aggressive acceleration profiles in packaging and robotics.
- Compact 80 mm Frame – Delivers 1 kW in a space-efficient footprint, simplifying machine redesigns and retrofits.
- Global Certifications – CE, UL, cUL, and RoHS compliance streamlines export machine approvals.
Complete System Bill of Materials
- Servo Motor: R88M-1M10030T-S2 (this item)
- Servo Drive: R88D-1SN10F-ECT (1S Series, 1 kW, EtherCAT)
- Power Cable (5 m): R88A-CA1A005S (included in this listing)
- Encoder Cable (5 m): R88A-CR1A005C
- Regeneration Resistor: R88A-RR22047S (application-dependent)
- EtherCAT Controller: NJ501-1300 or NX102-1200 Sysmac PLC
- Safety Module: NX-SL3300 (for SIL2/PLd safety functions)
Compliance & Industry Standards
- CE Marking – EU Machinery Directive 2006/42/EC & Low Voltage Directive 2014/35/EU
- UL / cUL Listed – UL 1004-1 (Rotating Electrical Machines)
- RoHS 3 Compliant – EU Directive 2015/863
- IEC 60034-1 – Rotating Electrical Machines general requirements
- IP67 – IEC 60529 Ingress Protection
- ISO 9283 – Manipulating Industrial Robots (applicable in robotic integration)
Quality Assurance & Sourcing
All units supplied by Konmask.com are sourced through verified industrial distribution channels. Each R88M-1M10030T-S2 undergoes the following before dispatch:
- Visual and dimensional inspection against OMRON factory specifications
- Encoder communication verification (absolute position readback test)
- Insulation resistance check (≥ 100 MΩ at 500 V DC)
- Original manufacturer packaging and labelling confirmed
- Traceability documentation available on request
How to Source This Part
Click Add to Cart or contact our engineering sales team directly for volume pricing, lead-time confirmation, and system integration support:
- Email: [email protected]
- Phone / WhatsApp: +0086 19859288691
- Website: https://konmask.com
- Lead Time: In-stock units ship within 1–3 business days; ex-factory orders 4–8 weeks.
- Shipping: DHL Express, FedEx International Priority, sea freight (LCL/FCL) available.
- Payment: T/T, PayPal, credit card, and LC accepted.
Application-Specific FAQ
Q: Which servo drive is compatible with the R88M-1M10030T-S2?
A: The recommended drive is the R88D-1SN10F-ECT (1S Series, 1 kW, EtherCAT). For MECHATROLINK-III applications, use R88D-1SN10H.
Q: Does this motor support safety functions (STO/SS1)?
A: Yes. When paired with the R88D-1SN10F-ECT drive and NX-SL3300 safety module, STO (Safe Torque Off) and SS1 (Safe Stop 1) are supported up to SIL2/PLd.
Q: Can the R88M-1M10030T-S2 be used in a vertical axis application?
A: Yes, but a brake option (suffix -BS2) is recommended for vertical axes to prevent load drop on power loss. Contact us to source the brake variant.
Q: What is the difference between part numbers 140008320 and 150008320?
A: These are OMRON internal reference/revision codes associated with the same motor assembly. Both designations refer to the R88M-1M10030T-S2 and are interchangeable for ordering purposes.
Q: Is the R88A-CA1A005S cable included?
A: This listing includes the R88A-CA1A005S 5 m power cable as part of the bundle. Please confirm your cable length requirement when ordering.
Q: Do you provide OMRON factory test reports?
A: Factory test certificates and material traceability documents are available upon request for OEM and system integrator customers.
