OPAL EA70417880100 SMC-RS232 P3G4 – RS232 Serial Communication PCB Module | RAYMI3COMM Platform
Engineering Background
The OPAL EA70417880100 is a purpose-built RS232 serial communication interface PCB module designed for integration within industrial automation and control systems. Manufactured under the OPAL RAYMI3COMM platform, this module carries multiple cross-reference part numbers — SMC-RS232 P3G4, 6001-0400-2100, 4022.437.36651, RAYMI3COMM, and 0190-46837 — ensuring compatibility across a wide range of OEM system configurations and legacy installations.
Product Positioning
Targeted at procurement engineers and MRO specialists sourcing reliable serial communication interface cards for real-time control networks, the EA70417880100 delivers stable RS232 signal handling in environments where legacy serial protocols remain the backbone of machine-to-machine communication. It is a direct replacement and upgrade path for aging communication boards in distributed control and SCADA architectures.
Complete Technical Specifications
- Manufacturer: OPAL
- Part Number: EA70417880100
- Series / Platform: SMC-RS232 / RAYMI3COMM
- Form Factor: PCB Module (P3G4 form factor)
- Interface Standard: RS232 Serial Communication
- Cross-Reference Part Numbers: SMC-RS232 P3G4 | 6001-0400-2100 | 4022.437.36651 | RAYMI3COMM | 0190-46837
- Weight: 4,100 g (as shipped)
- Shipping: Physical hardware — requires shipping
- Condition: New / Refurbished (contact for availability)
Proven Application Environments
- Industrial SCADA and DCS communication backplanes
- Legacy PLC serial interface expansion
- Machine tool controllers requiring RS232 host communication
- Process automation panels with serial HMI/PLC links
- Energy management and utility monitoring systems
- OEM equipment requiring RAYMI3COMM-compatible interface cards
Engineering Advantages
- Multi-reference compatibility: Single module covers multiple OEM part number variants, simplifying BOM consolidation
- RS232 protocol reliability: Proven serial standard for point-to-point industrial communication with noise immunity in plant environments
- P3G4 form factor: Standardized board geometry for direct slot-in replacement without mechanical modification
- RAYMI3COMM platform integration: Native compatibility with OPAL RAYMI3COMM communication architecture
- MRO-ready: Stocked for immediate dispatch to minimize production downtime
System Architecture & Signal Flow
The EA70417880100 operates as a plug-in communication interface card within the OPAL SMC-RS232 module family. It interfaces the host controller backplane to external RS232 serial devices via the P3G4 connector standard. Signal flow is full-duplex RS232, supporting standard baud rates and hardware handshaking (RTS/CTS). The RAYMI3COMM firmware layer manages protocol framing, error detection, and buffer management, ensuring deterministic data exchange in real-time control loops.
Sourcing & Quality Verification
- All units sourced through verified industrial automation supply channels
- Pre-shipment functional inspection and continuity testing performed
- Original manufacturer labeling and traceability documentation preserved
- Anti-static packaging with humidity indicator cards for PCB protection
- Batch and serial number records maintained for full traceability
Procurement Process
- Confirm part number match against your BOM or equipment manual (EA70417880100 / SMC-RS232 P3G4 / 6001-0400-2100 / 4022.437.36651 / 0190-46837)
- Contact Konmask for current stock status, lead time, and volume pricing
- Submit purchase order with delivery address and required documentation
- Receive shipment with test report and packing list
- Post-installation support available via email or phone
Technical FAQ
Q: Is EA70417880100 compatible with all RAYMI3COMM chassis?
A: The module is designed for RAYMI3COMM platform chassis. Confirm slot type and backplane revision with your system documentation before ordering.
Q: What baud rates does the SMC-RS232 P3G4 support?
A: Standard RS232 baud rates are supported (typically 1200–115200 bps). Refer to the OPAL SMC-RS232 technical manual for firmware-specific configuration.
Q: Can this module replace part number 0190-46837 directly?
A: Yes — 0190-46837 is a registered cross-reference for EA70417880100. Direct form-fit-function replacement is confirmed.
Q: Do you provide a warranty?
A: Konmask provides a standard warranty on all shipped units. Contact support@konmask.com for warranty terms applicable to your order.
Q: What is the lead time for out-of-stock units?
A: Lead times vary by sourcing channel. Contact us with your required delivery date and we will confirm availability and expedite options.
