Parker 150-A135NBDB – SCR DC Motor Speed Controller | 150 Series Drive Platform
Engineering Background
The Parker 150 Series represents Parker Hannifin’s proven SCR (Silicon Controlled Rectifier) DC drive platform, engineered for demanding industrial speed and torque control applications. The 150-A135NBDB variant is a fully regenerative, four-quadrant capable controller designed to deliver precise armature voltage regulation across a wide range of DC motor configurations. Parker’s 150 Series has accumulated decades of field deployment in process industries, material handling, and OEM machine tool applications worldwide.
Product Positioning
The 150-A135NBDB is positioned as a high-reliability MRO and OEM replacement drive for facilities operating Parker legacy DC motor systems. It is the preferred specification for procurement engineers who require drop-in compatibility with existing 150 Series infrastructure without reengineering motor cabling, field supply circuits, or operator interface panels. Konmask.com maintains verified inventory sourced directly from authorized Parker distribution channels, ensuring full traceability and genuine part authenticity.
Complete Technical Specifications
- Part Number: 150-A135NBDB
- Series: Parker 150 Series SCR DC Drive
- Drive Type: SCR (Silicon Controlled Rectifier), fully regenerative
- Control Mode: Armature voltage feedback / IR compensation / tachometer feedback (field selectable)
- Input Voltage: 115/230 VAC, single-phase or three-phase (model-dependent configuration)
- Output: Adjustable DC armature voltage for shunt-wound or permanent magnet DC motors
- Speed Regulation: ±1% with tachometer feedback; ±2% with armature voltage feedback
- Speed Range: 50:1 minimum (tach feedback); 20:1 (armature feedback)
- Field Supply: Integrated regulated DC field supply output
- Enclosure: Open chassis (IP00) — designed for panel or enclosure mounting
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Storage Temperature: -25°C to 65°C
- Humidity: 95% RH non-condensing
- Altitude: Up to 1000 m without derating
- Certifications: UL Listed, CE Marked (verify with current Parker documentation)
- Mounting: DIN rail or panel mount
- Weight: Refer to Parker 150 Series product datasheet for exact unit weight
Proven Application Environments
- Machine Tools: Lathe spindle drives, milling machine feed axes, grinding wheel speed control
- Material Handling: Conveyor line speed regulation, hoist and crane duty cycles
- Printing & Converting: Unwind/rewind tension control, web speed synchronization
- Packaging Machinery: Indexing drives, form-fill-seal line speed control
- Pump & Fan Control: Process pump speed regulation in chemical and water treatment plants
- Textile Industry: Winding and drawing machine speed control
- MRO Replacement: Direct replacement for aging 150 Series drives in legacy Parker DC motor systems
Engineering Advantages
- Four-Quadrant Operation: Full regenerative braking capability reduces mechanical brake wear and improves cycle efficiency
- Dual Feedback Modes: Field-selectable armature voltage or tachometer feedback allows adaptation to existing motor instrumentation without rewiring
- Integrated Field Supply: Eliminates the need for a separate field excitation power supply, reducing panel footprint and BOM cost
- Adjustable Accel/Decel Ramps: Independent acceleration and deceleration time adjustments protect mechanical drivetrain components
- Current Limit Protection: Adjustable current limit prevents motor overload during stall or jam conditions
- IR Compensation: Automatic IR drop compensation maintains speed regulation under varying load conditions without tachometer
- Compact Open-Frame Design: Optimized for integration into OEM machine enclosures with minimal panel space requirements
System Architecture & Signal Flow
The 150-A135NBDB operates on a closed-loop SCR phase-angle firing architecture. AC line voltage is rectified through a bridge SCR network; firing angle is modulated by the control board in response to the speed error signal derived from either armature voltage sensing or an external tachometer generator. The field supply circuit provides a regulated DC output to maintain constant motor field excitation independent of armature loading. Speed reference input accepts a 0–10 VDC analog signal from an external potentiometer, PLC analog output, or process controller. Fault logic monitors for overcurrent, overvoltage, and loss-of-feedback conditions, triggering a controlled shutdown and fault relay output for integration with machine safety circuits.
Sourcing & Quality Verification
- Origin: Sourced from Parker Hannifin authorized distribution network
- Traceability: Each unit ships with manufacturer lot code and date code documentation upon request
- Inspection: Pre-shipment functional verification available for critical MRO orders — contact sales for details
- Packaging: Original OEM packaging or equivalent ESD-safe protective packaging
- Warranty: 12-month Konmask.com supply warranty against manufacturing defects; subject to application review
- Counterfeit Risk Mitigation: Konmask.com does not source from gray-market or unverified secondary channels — all stock is traceable to authorized Parker distribution
Procurement Process
- Step 1 — Confirm Part Number: Verify 150-A135NBDB against your existing drive nameplate or Parker BOM documentation
- Step 2 — Request Quote: Contact support@konmask.com with quantity, required delivery date, and destination port/Incoterm preference
- Step 3 — Review Datasheet: Request the Parker 150 Series technical datasheet and wiring diagram for engineering sign-off
- Step 4 — Place Order: Purchase order accepted via email, online checkout, or B2B portal — Net 30 terms available for qualified accounts
- Step 5 — Shipment & Documentation: Commercial invoice, packing list, and certificate of origin provided for all international shipments; HS Code 8537.10 applicable
Technical FAQ
Q: Is the 150-A135NBDB compatible with permanent magnet DC motors?
A: Yes. The 150 Series supports both shunt-wound and permanent magnet DC motors. For PM motors, the field supply output is not used; disable or leave unconnected per Parker wiring instructions.
Q: Can this drive accept a 4–20 mA speed reference signal?
A: The standard 150-A135NBDB accepts a 0–10 VDC reference. A signal converter (e.g., 4–20 mA to 0–10 VDC) is required for current loop reference sources. Consult Parker application notes or contact Konmask technical support.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For large quantity orders or units requiring pre-shipment testing, lead time is 5–10 business days. Contact us for real-time stock confirmation.
Q: Is a replacement or repair service available?
A: Konmask.com supplies new and surplus-new units. For repair services on failed drives, we can refer you to Parker-authorized repair centers. Contact support for referral details.
Q: What documentation is available for customs clearance?
A: Full export documentation is provided including commercial invoice, packing list, certificate of origin, and HS Code declaration (8537.10). ECCN classification available upon request for export compliance review.
