Motion Control Solution – Parker C3S300V4F11 I31 T30 M00 A42 | Compax3 Series
Where This Product Is Used
The Parker Compax3 C3S300V4F11 I31 T30 M00 A42 servo drive is engineered for high-demand motion control applications across multiple industries:
- Packaging Machinery – Precision indexing, flying shear, and form-fill-seal lines requiring tight synchronization
- Semiconductor & Electronics Manufacturing – Wafer handling, pick-and-place, and gantry positioning where micron-level accuracy is mandatory
- Printing & Converting – Web tension control and register correction on high-speed presses
- Robotics & Handling – Multi-axis articulated arms and SCARA robots demanding real-time EtherCAT coordination
- Machine Tools & CNC – Spindle orientation, tool-changer actuation, and feed-axis control
- Automotive Assembly – Torque-controlled fastening, press-fit, and leak-test stations
- Medical Devices – Infusion pump drives, surgical robot joints, and diagnostic imaging positioners
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | C3S300V4F11 I31 T30 M00 A42 |
| Series | Compax3 |
| Manufacturer | Parker Hannifin |
| Continuous Output Current | 300 A (peak rating per model code) |
| Supply Voltage | 3-phase 400–480 V AC ±10%, 50/60 Hz |
| Fieldbus Interface (I31) | EtherCAT (IEC 61158 / IEC 61784) |
| Technology Option (T30) | Integrated Safety – STO (Safe Torque Off, IEC 62061 SIL 2 / EN 13849-1 PLd) |
| Motor Feedback | Resolver, EnDat 2.1/2.2, Hiperface, SinCos encoder |
| Control Modes | CSP, CSV, CST (CiA 402 DS402) |
| Digital I/O | 8 DI / 4 DO (24 V DC) |
| Analog I/O | 2 × ±10 V AI, 1 × AO |
| Protection Class | IP20 |
| Cooling | Forced air (internal fan) |
| Operating Temperature | 0 °C to +45 °C (derating above 40 °C) |
| Storage Temperature | -25 °C to +70 °C |
| Weight | ~19 kg |
| Programming Software | Parker Compax3 ServoManager / C3 IEC 61131-3 |
Why Engineers Specify This Model
- EtherCAT (I31) fieldbus – Sub-millisecond cycle times enable tight multi-axis synchronization without dedicated motion controllers
- Integrated STO (T30) – Eliminates external safety relays, reduces panel footprint, and simplifies TÜV certification
- High current rating (300 A frame) – Drives large servo motors directly without external amplifiers or boosters
- Universal feedback compatibility – Supports resolver through EnDat 2.2, reducing spare-parts complexity across mixed motor fleets
- IEC 61131-3 onboard PLC – Offloads simple sequencing from the master PLC, reducing scan-time load and wiring
- Proven Compax3 platform – Thousands of installed units globally; extensive application library and community support
Complete System Bill of Materials
For a fully operational servo axis based on this drive, engineers typically specify:
- Parker Compax3 C3S300V4F11 I31 T30 M00 A42 Servo Drive (this unit)
- Parker MPP / MPS / MPJ series servo motor (matched to torque/speed curve)
- Feedback cable – Parker pre-assembled resolver or EnDat cable (motor-specific length)
- Power cable – shielded, motor-rated, with EMC gland
- EtherCAT patch cable – Cat5e shielded, daisy-chain topology
- 24 V DC control power supply (min. 3 A per drive)
- Line filter – Parker EMC filter (required for CE compliance)
- Braking resistor – external, sized to application deceleration energy
- Parker Compax3 ServoManager software license (free download)
Compliance & Industry Standards
- CE Marking – Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- UL 508C – Power Conversion Equipment
- IEC 61800-5-1 – Adjustable speed electrical power drive systems safety
- IEC 62061 / EN ISO 13849-1 – Functional safety SIL 2 / PLd (STO function)
- IEC 61158 / IEC 61784 – EtherCAT fieldbus protocol
- CiA 402 DS402 – CANopen device profile for drives and motion control
- RoHS 2011/65/EU compliant
Quality Assurance & Sourcing
Konmask.com sources Parker Compax3 drives exclusively through authorized distribution channels and verified industrial surplus networks. Every unit undergoes:
- Visual inspection – housing, connectors, label integrity, and firmware version verification
- Functional power-on test – DC bus charge, fan operation, and display self-test
- Serial number traceability – cross-referenced against Parker production records where available
- ESD-safe packaging – anti-static bag, foam insert, and double-wall carton
- 90-day warranty against defects in materials and workmanship
How to Source This Part
Ready to order or need a formal quotation?
- Request a Quote: Email [email protected] with your required quantity and delivery timeline
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders quoted within 24 hours
- Shipping: DHL Express, FedEx International Priority, and sea freight available worldwide
- Payment: T/T wire transfer, PayPal, and credit card accepted
- Export Documentation: Commercial invoice, packing list, COO, and ECCN classification provided on request
Application-Specific FAQ
Q: Can this drive replace an older Compax3 unit with a different option code?
A: Option codes define fieldbus, safety, and feedback type. Substitution is possible only if the replacement matches the I, T, M, and A codes required by your machine’s wiring and software configuration. Contact us for a compatibility review.
Q: Is the EtherCAT master included?
A: No. The C3S300V4F11 I31 is an EtherCAT slave device. A compatible EtherCAT master (e.g., Beckhoff TwinCAT, Omron Sysmac, or Parker ACR9000) is required.
Q: What motor frame sizes does the 300 A drive support?
A: The 300 A continuous rating supports Parker MPP/MPS motors up to approximately 22 kW continuous at 400 V. Consult the Compax3 sizing tool for exact motor-drive pairing.
Q: Can STO be used as an E-stop replacement?
A: STO removes torque but does not mechanically brake the motor. For vertical or high-inertia loads, a separate holding brake is required. STO is suitable as a safety-rated stop function per IEC 62061.
Q: Do you provide the ServoManager configuration file?
A: We can provide application-specific .c3p parameter files for common machine types upon request. Custom commissioning support is available at an additional charge.
