PHOENIX DIGITAL OCX-CTN-13-R-D-ST-ACV Optical Communication Module | Replacement, Equivalent & Selection Guide
The PHOENIX DIGITAL OCX-CTN-13-R-D-ST-ACV is an industrial-grade optical communication module engineered for high-reliability fiber optic data transmission in demanding automation and process control environments. This guide covers technical specifications, compatible replacements, selection criteria, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
- Part Number: OCX-CTN-13-R-D-ST-ACV
- Manufacturer: PHOENIX DIGITAL
- Product Type: Optical Communication Module
- Connector Type: ST (Straight Tip) Fiber Optic Connector
- Wavelength: 1300 nm (single-mode / multimode, model-dependent)
- Transmission Mode: Duplex (R-D: Receive/Transmit)
- Signal Type: ACV (AC Voltage compatible signaling)
- Mounting: DIN rail / panel mount compatible
- Weight: 1,110 g
- Operating Temperature: -20°C to +70°C (typical industrial range)
- Protection Class: IP20 (typical)
- Standards Compliance: CE, UL (verify current certifications with datasheet)
Compatible Replacement & Equivalent Models
When the OCX-CTN-13-R-D-ST-ACV is discontinued, on extended lead time, or outside budget, the following models may serve as functional equivalents — always verify electrical and mechanical compatibility before substitution:
- PHOENIX DIGITAL OCX-CTN-85-R-D-ST-ACV — 850 nm variant; suitable for shorter multimode runs
- PHOENIX DIGITAL OCX-CTN-13-R-D-SC-ACV — SC connector variant; same wavelength, different connector
- Moxa IMC-101-S-SC — Industrial fiber media converter; verify protocol compatibility
- Advantech EKI-2541SI — Industrial fiber optic module; confirm pinout and signal levels
- Hirschmann OZD Profi — PROFIBUS fiber optic repeater; application-specific match required
⚠ Always consult the original datasheet and system integrator before substituting optical modules. Wavelength, connector type, and signal protocol must match exactly.
Why Choose the Original Model
- Exact Protocol Match: OCX-CTN-13-R-D-ST-ACV is factory-validated for specific PHOENIX DIGITAL system architectures — no re-engineering required.
- 1300 nm Wavelength: Optimized for longer-distance multimode and single-mode fiber runs with lower attenuation than 850 nm alternatives.
- ST Connector Standard: Widely deployed in legacy industrial fiber networks; direct plug-in replacement for existing infrastructure.
- Duplex Operation: Full-duplex R-D configuration ensures simultaneous bidirectional data flow — critical for real-time control loops.
- ACV Signal Compatibility: Designed for AC voltage environments, reducing the need for additional signal conditioning hardware.
- Proven Industrial Reliability: PHOENIX DIGITAL modules are specified in power generation, water treatment, and heavy manufacturing globally.
Typical Applications
- Power Utilities: Substation automation and protection relay communication over fiber
- Water & Wastewater: SCADA fiber backbone for remote pump station monitoring
- Oil & Gas: Hazardous-area fiber optic links between field devices and control rooms
- Manufacturing: PLC-to-PLC fiber communication in high-EMI press and welding environments
- Transportation: Railway signaling and tunnel communication fiber networks
- Building Automation: BMS fiber ring networks for large campus or high-rise installations
System Compatibility
- Compatible Protocols: PROFIBUS DP/PA, Modbus RTU over fiber, proprietary PHOENIX DIGITAL protocols
- Fiber Type: 62.5/125 µm or 50/125 µm multimode; single-mode variants available in series
- Host Systems: PHOENIX DIGITAL ILC, RFC, and AXC controller families; third-party systems with ST fiber ports
- Topology Support: Point-to-point, ring, and star fiber topologies
- Power Supply: 24 VDC (typical); confirm with product datasheet
Selection Guide
Use the following criteria to confirm the OCX-CTN-13-R-D-ST-ACV is the correct module for your application:
- ✅ Wavelength: Your fiber link requires 1300 nm operation
- ✅ Connector: Your fiber patch cables use ST connectors
- ✅ Direction: Full-duplex (R-D) communication is required
- ✅ Signal: ACV-compatible input/output signal levels
- ✅ Distance: Link budget supports 1300 nm multimode (up to ~2 km typical)
- ✅ Environment: Industrial temperature range and DIN rail mounting required
If any criterion does not match, refer to the Compatible Replacement section above or contact our technical team for a cross-reference.
Quality Assurance & Sourcing
- Authentic Parts Only: Konmask.com sources OCX-CTN-13-R-D-ST-ACV exclusively from authorized distributors and verified industrial surplus channels.
- Inspection Protocol: Every unit undergoes visual inspection, label verification, and functional pre-check before dispatch.
- Traceability: Batch records and supplier documentation available on request for regulated industries.
- Warranty: 12-month warranty against manufacturing defects; return authorization within 30 days of receipt.
- Anti-Counterfeit: We do not source from unverified grey-market channels — your system integrity is our priority.
How to Order
- Part Number: OCX-CTN-13-R-D-ST-ACV
- Manufacturer: PHOENIX DIGITAL
- Minimum Order: 1 unit
- Lead Time: Contact us for current stock availability and lead time
- Quote Request: Email support@konmask.com with quantity and delivery requirements
- Phone / WhatsApp: +0086 19859288691
- Bulk Pricing: Volume discounts available for orders of 5+ units
Replacement & Compatibility FAQ
Q: Can I replace OCX-CTN-13-R-D-ST-ACV with an 850 nm module?
A: Only if your fiber link distance is under 500 m and your fiber type supports 850 nm. The 1300 nm variant offers significantly lower attenuation for longer runs.
Q: Is the SC connector version a drop-in replacement?
A: Electrically yes, but you will need ST-to-SC fiber adapter cables or patch cord changes. Confirm with your fiber plant manager.
Q: Does this module support PROFINET?
A: The OCX-CTN series is primarily designed for PROFIBUS and serial-over-fiber protocols. For PROFINET fiber, consider PHOENIX CONTACT FL SWITCH or similar managed switch solutions.
Q: What is the maximum fiber distance for this module?
A: Typically up to 2 km on 62.5/125 µm multimode fiber at 1300 nm. Actual distance depends on fiber quality, connector losses, and data rate — consult the link budget calculation in the datasheet.
Q: Is this product RoHS compliant?
A: PHOENIX DIGITAL products in this series are generally RoHS compliant. Confirm with the current product datasheet or contact us for the declaration of conformity.
Q: Can Konmask.com provide a certificate of conformity?
A: Yes. CoC and supplier documentation are available upon request for quality-audited procurement.
