Multi-Axis Servo Drive Solution — Allen-Bradley 2198-P208 | Kinetix 5700
The Allen-Bradley 2198-P208 is a high-capacity DC-bus power supply engineered for demanding multi-axis motion control applications. As the backbone of the Kinetix 5700 servo drive system, it delivers a stable, shared DC bus to multiple servo drive modules — enabling synchronized, high-performance motion across complex machine architectures. Konmask.com supplies this unit with full traceability and quality verification for industrial buyers worldwide.
Where This Product Is Used
The 2198-P208 is specified by motion control engineers across a wide range of high-demand industrial environments:
- Automotive Assembly Lines — Powering multi-axis robotic welding, stamping, and body-in-white transfer systems requiring tight synchronization.
- Packaging Machinery — Driving coordinated servo axes on form-fill-seal, cartoning, and case-packing lines where throughput and repeatability are critical.
- CNC Machining Centers — Supplying shared DC bus power to X/Y/Z and spindle servo drives in high-speed milling and turning applications.
- Semiconductor & Electronics Manufacturing — Supporting precision pick-and-place, wafer handling, and inspection systems with ultra-low jitter motion profiles.
- Printing & Converting — Enabling register control across multi-station web presses and slitter-rewinder lines.
- Material Handling & Conveyors — Coordinating servo-driven sorters, diverters, and accumulation systems in distribution centers.
- Plastics & Injection Molding — Providing stable bus power for clamp, injection, and ejector servo axes on all-electric molding machines.
Technical Specifications
- Catalog Number: 2198-P208
- Series: Kinetix 5700
- Manufacturer: Allen-Bradley / Rockwell Automation
- Type: DC-Bus Power Supply (Shared Bus)
- DC Bus Output Current: 208 A
- Input Voltage: 195–528 V AC, 3-phase
- Input Frequency: 47–63 Hz
- DC Bus Output Voltage: ~650–750 V DC (nominal)
- Regenerative Capability: Yes (active front end)
- Communication: Integrated with Studio 5000 / Logix Designer via EtherNet/IP
- Mounting: Panel mount, DIN rail compatible chassis
- Enclosure Rating: IP20 (open type, panel-mount installation required)
- Weight: 7.04 kg
- Certifications: UL, CE, RCM
Why Engineers Specify This Model
- Shared DC Bus Architecture — One power supply feeds multiple 2198-series servo drive modules, reducing panel footprint and simplifying wiring compared to individual drive power stages.
- Active Front End / Regenerative — Returns braking energy to the AC supply rather than dissipating it as heat, lowering energy costs and eliminating the need for external brake resistors in most applications.
- 208 A Bus Rating — The highest-capacity standard unit in the Kinetix 5700 lineup, suitable for large multi-axis systems with simultaneous high-torque demand.
- Seamless Logix Integration — Native EtherNet/IP connectivity allows full configuration, diagnostics, and monitoring within Studio 5000 Logix Designer — no separate drive software required.
- Safe Torque Off (STO) — Integrated SIL 2 / PLd safety function eliminates the need for external contactors in safety-rated stop circuits.
- Wide Input Voltage Range — Accepts 195–528 V AC, making it suitable for both 208 V and 480 V North American systems as well as 400 V European installations.
Complete System Bill of Materials
A typical Kinetix 5700 multi-axis system built around the 2198-P208 includes the following components:
- 2198-P208 — DC-Bus Power Supply (this unit)
- 2198-Dxxx — Kinetix 5700 Single-Axis Servo Drive modules (select per axis torque/speed requirements)
- 2198-DBRxxx — Dynamic Brake Resistor (if regenerative energy exceeds supply capacity)
- 2198-CAPMOD-2240 — Capacitor Module (for ride-through and bus stabilization)
- 2198-TCON-24VDCIN — 24 V DC Control Power Input connector kit
- MPL / VPL / VPC Series — Allen-Bradley servo motors (matched to drive frame size)
- 2090-CSxM1DF-xxAAxxx — Motor power cables (SpeedTec DIN connector)
- 1756-L8x ControlLogix / 5069-L3x CompactLogix — Compatible Logix controller
- 1783-BMS / Stratix 5700 — Managed EtherNet/IP switch for motion network
Contact support@konmask.com for complete BOM pricing and availability.
Compliance & Industry Standards
- UL 508C — Power Conversion Equipment
- CE Marking — Low Voltage Directive (LVD) 2014/35/EU & EMC Directive 2014/30/EU
- IEC 61800-5-1 — Adjustable speed electrical power drive systems — safety requirements
- IEC 61800-5-2 — Functional safety (STO, SIL 2 / PLd)
- RCM (Australia/NZ)
- RoHS Compliant
Quality Assurance & Sourcing
Konmask.com sources the 2198-P208 through verified industrial distribution channels. Every unit undergoes the following before shipment:
- Visual inspection for physical damage, label integrity, and connector condition
- Firmware version verification against Rockwell Automation release notes
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Full traceability documentation available on request
We do not list units of unknown provenance. If a unit cannot be verified, it is not offered for sale.
How to Source This Part
- In Stock: Add to cart and check out directly — ships within 1–3 business days.
- Quote Required: Email support@konmask.com with your project BOM for volume pricing.
- Urgent / Emergency: Call or WhatsApp +0086 19859288691 for same-day response on critical downtime situations.
- OEM / Integrator Accounts: Contact us to establish a trade account with net terms and priority allocation.
Application-Specific FAQ
Q: Can the 2198-P208 power both single-axis and dual-axis Kinetix 5700 drive modules on the same bus?
A: Yes. The 2198-P208 is compatible with all 2198-D single-axis and 2198-S dual-axis servo drive modules. The 208 A bus rating accommodates mixed configurations — consult the Kinetix 5700 Design Guide (Pub. 2198-UM002) for bus loading calculations.
Q: Is an external line filter required?
A: The 2198-P208 has an integrated EMC filter. However, Rockwell Automation recommends an external line reactor (e.g., 2198-DBRxxx or 1321-3Rxxx) for installations with long cable runs or high harmonic distortion environments. Verify with your local EMC requirements.
Q: What is the maximum number of servo axes this power supply can support?
A: This depends on the continuous and peak current demand of each axis. The 208 A DC bus output is the limiting factor. Use the Kinetix 5700 Sizing Tool in Motion Analyzer software (Rockwell Automation) to calculate the exact axis count for your application.
Q: Is this unit compatible with 400 V European power systems?
A: Yes. The input voltage range of 195–528 V AC covers both 400 V (EU) and 480 V (NA) three-phase systems without hardware modification.
Q: Can Konmask provide a warranty or return policy?
A: Yes. All units sold by Konmask.com carry a 90-day functional warranty. Contact support@konmask.com for warranty claims or DOA replacements.
