Rotating Machinery Monitoring Solution – PROVIBTECH TM0180-A07-B00-C05-D10 | TM0180 Series
Where This Product Is Used
The PROVIBTECH TM0180-A07-B00-C05-D10 extension cable is purpose-engineered for continuous vibration monitoring in demanding industrial environments. Typical deployment scenarios include:
- Steam & Gas Turbines — Connects proximity probes to monitoring systems across high-temperature bearing housings where direct cabling is impractical.
- Centrifugal Compressors & Pumps — Routes signals from shaft proximity sensors through compressor skids with tight conduit runs.
- Electric Motors & Gearboxes — Extends sensor reach in motor control centers and gearbox enclosures where vibration transducers must be positioned precisely.
- Paper & Steel Mill Roll Lines — Withstands vibration, moisture, and chemical exposure in continuous process environments.
- Offshore & Marine Machinery — Armored construction resists mechanical damage in confined machinery spaces.
Engineers specify this cable when the standard integral cable of a proximity probe or accelerometer is insufficient to reach the monitoring rack, and a low-noise, impedance-matched extension is required to preserve signal integrity.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | TM0180-A07-B00-C05-D10 |
| Series | TM0180 |
| Manufacturer | PROVIBTECH |
| Cable Type | Armored Extension Cable |
| Cable Length | 5 m (16.4 ft) — suffix D10 = 5 m |
| Connector A (Sensor End) | Per suffix A07 — MIL-spec coaxial plug |
| Connector B (Monitor End) | Per suffix B00 — standard coaxial jack |
| Shield / Armor | Stainless steel braid armor (suffix C05) |
| Operating Temperature | -40 °C to +125 °C |
| Impedance | Matched to TM0180 series (nominally 50 Ω) |
| Weight | Approx. 70 g |
| Application | Eddy-current proximity probe / accelerometer signal extension |
Suffix decode: A07 = connector type A, B00 = connector type B, C05 = armor grade, D10 = 5 m length.
Why Engineers Specify This Model
- Signal Integrity — Impedance-matched construction minimizes reflections and noise pickup across the full sensor bandwidth.
- Armored Protection — Stainless steel braid armor (C05) resists crush, abrasion, and rodent damage in plant environments.
- Exact Suffix Compatibility — Connector configuration A07/B00 mates directly with PROVIBTECH TM0180-series probes and Bently Nevada 3300/3500-compatible monitor inputs without adapters.
- Defined Cable Length — 5 m fixed length (D10) eliminates field-cutting errors that introduce impedance discontinuities.
- Wide Temperature Range — Rated to 125 °C, suitable for hot bearing housings and turbine pedestals.
- Drop-in Replacement — Identical form, fit, and function to OEM-specified cables; no recalibration required.
Complete System Bill of Materials
For a complete eddy-current proximity measurement loop, the following components are typically required alongside this extension cable:
- Proximity Probe — e.g., PROVIBTECH TM0180 series (8 mm or 11 mm tip)
- Oscillator/Demodulator (Driver) — e.g., PROVIBTECH TM0182 or equivalent
- Extension Cable — TM0180-A07-B00-C05-D10 (this item)
- Vibration Monitor — e.g., Bently Nevada 3500/22M or PROVIBTECH TM8000 series
- Mounting Bracket & Probe Holder — application-specific
- Signal Conditioner / Barrier (if in hazardous area) — ATEX/IECEx rated
Contact Konmask to source the complete loop as a matched set.
Compliance & Industry Standards
- Designed for use in systems compliant with ISO 10816 / ISO 20816 (Mechanical vibration — evaluation of machine vibration).
- Compatible with API 670 (Machinery Protection Systems) measurement loops.
- Armor and connector materials suitable for IEC 60068 environmental test conditions.
- RoHS-compliant materials of construction.
Quality Assurance & Sourcing
Konmask sources PROVIBTECH components through verified industrial distribution channels. Each unit is:
- Inspected for connector integrity and armor continuity prior to dispatch.
- Shipped with original manufacturer labeling and traceability markings.
- Packaged to prevent connector damage during international freight.
- Supported by Konmask’s pre-sales technical team for application verification.
How to Source This Part
To place an order or request a quotation for the TM0180-A07-B00-C05-D10:
- Add to cart directly on this page, or
- Email [email protected] with your quantity and delivery location.
- For urgent requirements or bulk orders (>10 units), call +0086 19859288691 for same-day quotation.
- Lead time: typically 3–7 business days for stocked configurations; 2–4 weeks for non-standard suffix variants.
Application-Specific FAQ
Q: Is this cable compatible with Bently Nevada 3300 XL proximity systems?
A: Yes. The A07/B00 connector configuration and 50 Ω impedance match the Bently Nevada 3300 XL probe/driver loop requirements. Verify total system cable length does not exceed the driver’s specified range.
Q: Can I use this cable in a Class I Division 2 hazardous area?
A: The cable itself is not ATEX/IECEx certified as a standalone component. In hazardous areas, the complete measurement loop (probe + cable + driver) must be evaluated as a system. Contact us for guidance on intrinsically safe barrier selection.
Q: What is the maximum total cable length (probe cable + extension) for the TM0180 system?
A: PROVIBTECH specifies maximum total cable length per the driver datasheet (typically 9 m for standard configurations). The 5 m extension (D10) combined with a standard 1 m probe integral cable leaves margin within this limit.
Q: Do you stock other length variants (D05 = 2.5 m, D15 = 7.5 m)?
A: Yes. Contact Konmask with your required suffix combination for availability and pricing.
Q: Is calibration required after replacing the extension cable?
A: No recalibration is required if the replacement cable has identical suffix specifications. The system gap voltage and sensitivity remain unchanged.
