ProvibTech PT2060/10 Eddy Current Proximity Module | Replacement, Equivalent & Selection Guide
The ProvibTech PT2060/10 is a high-precision eddy current proximity module designed for continuous vibration and position monitoring in rotating machinery protection systems. As an authorized sourcing partner, Konmask.com supplies genuine PT2060/10 units alongside verified compatible replacements to keep your plant running without interruption.
Technical Specifications
- Manufacturer: ProvibTech
- Part Number / SKU: PT2060/10
- Series: PT2060
- Module Type: Eddy Current Proximity Module
- Output Signal: –24 VDC bias voltage; linear voltage output proportional to gap
- Measurement Range: 0–10 mm (nominal, probe-dependent)
- Frequency Response: DC to 10 kHz (–3 dB)
- Supply Voltage: –24 VDC (±10%)
- Operating Temperature: –20 °C to +85 °C
- Connector: Standard BNC / MIL-spec (verify with datasheet)
- Weight: ~1,040 g (packaged)
- Compliance: Compatible with API 670 machinery protection standards
Compatible Replacement & Equivalent Models
When the PT2060/10 is unavailable or end-of-life, the following models offer functional equivalence. Always verify pin-out, cable length, and sensitivity scale factor before substitution.
- ProvibTech PT2060/08 – Same series, 8 mm range variant; verify sensitivity factor
- Bently Nevada 3300 XL 8mm – Industry-standard eddy current system; widely interchangeable in API 670 panels
- Bently Nevada 330180-X1-X0-X1-X0 – Direct proximity transducer equivalent for gap monitoring
- Emerson CSI 6500 Proximity Module – Compatible in Emerson machinery protection racks
- EPRO PR6423/010-040 – Eddy current transducer with comparable output range
- Metrix ST5484E – Proximity/position transmitter with 4–20 mA output option
Note: Replacement suitability depends on your specific rack, cable, and probe combination. Contact support@konmask.com for a verified cross-reference.
Why Choose the Original PT2060/10
- Factory-calibrated sensitivity matched to ProvibTech PT2060 series probes and extension cables
- Guaranteed API 670 compliance for turbine and compressor protection systems
- Consistent –24 VDC bias output eliminates recalibration when replacing like-for-like
- Traceable quality documentation (COC, test report) available on request
- Long-term availability through Konmask.com authorized sourcing network
Typical Applications
- Radial shaft vibration monitoring on steam turbines, gas turbines, and centrifugal compressors
- Axial thrust position measurement on rotating machinery
- Differential expansion monitoring in power generation equipment
- Eccentricity and rotor runout measurement
- Integration with DCS / PLC-based machinery protection panels
System Compatibility
- ProvibTech Systems: PT2060 series racks, PT8000 series monitors
- Third-Party Racks: Compatible with most –24 VDC eddy current input cards (verify impedance)
- DCS Integration: Yokogawa CENTUM, Honeywell Experion, ABB 800xA, Emerson DeltaV
- PLC Integration: Siemens S7-300/400/1500, Allen-Bradley ControlLogix (via signal conditioner)
- Safety Systems: Compatible with SIL-rated safety instrumented systems when used with certified barriers
Selection Guide
Use the following criteria to confirm the PT2060/10 is the correct module for your application:
- Gap Range: Confirm your shaft-to-probe gap falls within 0–10 mm nominal range
- Probe Series: Must be used with ProvibTech PT2060-compatible probes and extension cables
- Supply Voltage: Verify –24 VDC supply is available at the rack
- Output Scaling: Confirm sensitivity (mV/mm) matches your monitor input card setting
- Environment: Check ambient temperature and hazardous area classification (ATEX/IECEx if required)
- Cable Length: Total probe + extension cable length must match driver calibration range
Not sure which model fits? Send your existing part number or rack model to support@konmask.com and our engineers will confirm compatibility.
Quality Assurance & Sourcing
- All units sourced through authorized distribution channels or direct factory supply
- Pre-shipment inspection with functional test report available
- Certificate of Conformance (COC) and country of origin documentation provided
- Anti-counterfeit verification: hologram labels, serial number traceability
- Packaging: original OEM packaging preserved where possible; ESD-safe secondary packaging
- Shelf life and storage conditions maintained per manufacturer guidelines
How to Order
- Online: Add to cart directly on this page — stock levels updated in real time
- Email RFQ: support@konmask.com — include quantity, required delivery date, and any certification requirements
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; ex-factory orders quoted on request
- MOQ: 1 piece
- Payment: T/T, PayPal, credit card, and trade assurance accepted
Replacement & Compatibility FAQ
Q: Can I replace the PT2060/10 with a Bently Nevada 3300 series module?
A: Functionally similar, but sensitivity scale factors and connector types may differ. A signal conditioner or recalibration may be required. Contact us for a detailed cross-reference.
Q: Is the PT2060/10 compatible with EPRO probes?
A: Not directly — ProvibTech and EPRO systems use different calibration curves. Mixing brands requires verified compatibility testing.
Q: Do you supply the matching PT2060 probe and extension cable?
A: Yes. We can supply the complete PT2060 system (probe + extension cable + driver module) as a matched set. Request a bundle quote.
Q: What is the warranty on the PT2060/10?
A: 12-month warranty against manufacturing defects. Extended warranty available on request.
Q: Can you provide an ATEX-certified version?
A: Please specify your hazardous area classification when ordering. We will confirm availability of certified variants.
