Schneider Electric ATV610U07N4 Altivar 610 Variable Speed Drive | Replacement, Equivalent & Selection Guide
The Schneider Electric ATV610U07N4 is a 0.75 kW (1 HP) three-phase AC variable speed drive from the Altivar 610 series, designed for pump and fan applications requiring precise flow control, energy savings, and process reliability. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make the right choice.
Technical Specifications
- Part Number: ATV610U07N4
- Brand: Schneider Electric
- Series: Altivar 610 (ATV610)
- Motor Power: 0.75 kW / 1 HP
- Supply Voltage: 3-Phase, 380–480 V AC ±10%
- Output Current: 2.3 A (nominal)
- Output Frequency: 0.5–500 Hz
- Control Type: Sensorless Flux Vector (SVC), V/f
- Communication: Modbus RTU (built-in); optional Ethernet, PROFIBUS, DeviceNet
- Protection Rating: IP21 (standard); IP55 optional
- EMC Filter: Integrated Class C2
- Braking: Dynamic braking transistor built-in
- Display: Graphic keypad with multi-language support
- Certifications: CE, UL, cUL, RoHS
- Operating Temperature: -10°C to +50°C (derating above 40°C)
- Dimensions (H×W×D): 170 × 90 × 156 mm (approx.)
- Weight: Approx. 1.5 kg
Compatible Replacement & Equivalent Models
When the ATV610U07N4 is unavailable or under evaluation, the following models offer functional equivalence or direct replacement capability:
- Schneider ATV320U07N4B – Altivar 320 series, 0.75 kW, 3-phase 380–500 V; compact bookcase format, suitable for machine builders
- Schneider ATV312HU07N4 – Legacy Altivar 312 series, 0.75 kW, 3-phase 380–500 V; direct predecessor, same power class
- Schneider ATV212HU07N4 – Altivar 212 series, 0.75 kW, HVAC-optimized; compatible for pump/fan replacement
- ABB ACH580-01-02A7-4 – 0.75 kW, 3-phase 380–480 V; HVAC/pump drive with built-in EMC filter; cross-brand equivalent
- Siemens SINAMICS G120C 6SL3210-1KE11-8UF1 – 0.75 kW, 3-phase 380–480 V; modular design, Profibus/Profinet capable
- Danfoss FC-202P0K75T4E20H1 – AQUA Drive 0.75 kW, 3-phase 380–480 V; pump-dedicated equivalent
- Yaskawa GA700 CIMR-GA4A0002FAA – 0.75 kW, 3-phase 400 V; high-performance general-purpose equivalent
Note: Always verify wiring diagrams, control signal compatibility, and parameter migration before substituting drives in live systems.
Why Choose the Original Model
- Purpose-Built for Pumps & Fans: ATV610 embeds dedicated pump/fan algorithms including PID control, sleep/wake function, and pipe-fill mode — reducing commissioning time significantly.
- Energy Savings: Integrated energy measurement and reporting; supports IE3 motor optimization and automatic energy-saving mode.
- Plug-and-Play Communication: Native Modbus RTU with optional fieldbus cards (Ethernet/IP, PROFIBUS DP, DeviceNet) for seamless SCADA/BMS integration.
- Robust EMC Compliance: Built-in Class C2 EMC filter eliminates the need for external filtering in most industrial environments.
- Schneider Ecosystem: Full compatibility with EcoStruxure architecture, SoMove software, and Schneider HMI/PLC platforms.
- Long-Term Support: Active product lifecycle with firmware updates, global spare parts availability, and certified service network.
Typical Applications
- HVAC systems: chilled water pumps, cooling tower fans, air handling units
- Water & wastewater: booster pumps, dosing pumps, sewage lift stations
- Building automation: pressure-controlled circulation pumps
- Light industrial: conveyor drives, compressors, mixers (0.75 kW range)
- OEM machine builders requiring compact, fieldbus-ready drives
System Compatibility
- PLC Integration: Schneider Modicon M221/M241/M340; Siemens S7-1200/S7-300 via Modbus RTU or optional PROFIBUS card
- HMI: Schneider Magelis, Vijeo Designer; third-party HMIs via Modbus TCP/IP (with optional card)
- SCADA/BMS: BACnet MS/TP (via optional card), LonWorks, KNX gateway compatible
- Motor Compatibility: Standard IE1–IE4 induction motors; permanent magnet motors (SVC mode)
- Input Power: Compatible with TN, TT, and IT network configurations (with appropriate EMC settings)
Selection Guide
Use the following criteria to confirm ATV610U07N4 is the correct model for your application:
- Motor Power: 0.75 kW (1 HP) — if your motor is larger, select ATV610U15N4 (1.5 kW) or above
- Supply Voltage: 3-phase 380–480 V — for 200–240 V single-phase, consider ATV610U07M2 series
- Application Type: Pump/fan variable torque — for constant torque (conveyors, hoists), evaluate ATV630 or ATV650 series
- Enclosure: IP21 standard; specify ATV610U07N4S6 for IP55 stainless steel enclosure
- Communication: Modbus RTU built-in; add VW3A3616 (Ethernet/IP), VW3A3607 (PROFIBUS DP) as needed
- Braking: Internal braking transistor included; add external braking resistor for high-inertia loads
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels with full traceability
- Pre-shipment inspection: visual check, label verification, firmware version confirmation
- Counterfeit risk mitigation: serial number validation against Schneider Electric’s product database
- Packaging: original OEM packaging preferred; industrial anti-static packaging for surplus stock
- Warranty: 12-month warranty on all units shipped from Konmask.com
How to Order
- Part Number: ATV610U07N4
- Lead Time: In-stock items ship within 1–3 business days; ex-stock lead time varies by region
- MOQ: 1 unit
- Payment: T/T, PayPal, credit card, trade assurance
- Shipping: DHL, FedEx, UPS worldwide; sea freight available for bulk orders
- RFQ: Contact support@konmask.com for volume pricing and lead time confirmation
Replacement & Compatibility FAQ
Q: Can ATV320U07N4B directly replace ATV610U07N4?
A: Functionally yes for basic V/f control, but ATV320 lacks the dedicated pump algorithms (PID, pipe-fill, sleep/wake) of ATV610. Re-parameterization is required.
Q: Is ATV610U07N4 backward compatible with ATV312 parameters?
A: Not directly. Use Schneider’s SoMove software to export ATV312 parameters and map them to ATV610 equivalents. Key parameters differ in naming and scaling.
Q: Can I use a cross-brand replacement (ABB/Siemens) without rewiring?
A: Terminal layouts differ between brands. Expect to remap control wiring (AI, DI, relay outputs) and reconfigure communication settings. Mechanical mounting dimensions also vary.
Q: What is the difference between ATV610U07N4 and ATV610U07N4S6?
A: The S6 suffix denotes an IP55-rated stainless steel enclosure version, suitable for washdown and food & beverage environments. Electrical specifications are identical.
Q: Does ATV610U07N4 support regenerative braking?
A: No. It includes a dynamic braking transistor for resistor braking only. For regenerative braking, consider the ATV650 or ATV900 series with active front end.
