SCS UFS-22 Braking Unit | Replacement, Equivalent & Selection Guide
The SCS UFS-22 is a dedicated braking unit designed for use in industrial drive and motion-control systems. This page provides complete technical specifications, compatible replacement models, application guidance, and sourcing information to help engineers and procurement teams make confident selection decisions.
Technical Specifications
- Manufacturer: SCS
- Model: UFS-22
- Type: Braking Unit (Dynamic Brake Resistor Controller)
- SKU: UFS-22
- Mounting: DIN rail / panel mount (confirm with datasheet)
- Operating Temperature: 0 °C to +55 °C (typical industrial grade)
- Protection Class: IP20 (standard enclosure; verify with OEM datasheet)
- Weight: ~100 g
- Compliance: CE / RoHS (verify current certification status)
Note: For full electrical ratings (voltage, current, braking resistance range, duty cycle), please refer to the official SCS UFS-22 datasheet or contact our technical team.
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as functional replacements or equivalents for the SCS UFS-22. Always verify electrical and mechanical compatibility before substitution:
- SCS UFS-20 – Lower-rated variant in the same UFS series; verify braking capacity
- SCS UFS-25 – Higher-rated variant; drop-in compatible in most installations
- Generic UFS-22 Compatible Units – Third-party braking units matching the UFS-22 form factor and electrical spec; confirm resistance range and duty cycle
- OEM-Equivalent Braking Modules – Contact Konmask for cross-reference to Siemens, ABB, or Schneider equivalents where applicable
Important: Substitution must be validated against the host drive’s braking resistor requirements. Incorrect selection may cause drive faults or equipment damage.
Why Choose the Original SCS UFS-22
- ✅ OEM-matched performance – Designed and validated for SCS drive systems
- ✅ Guaranteed compatibility – No integration risk when replacing like-for-like
- ✅ Stable supply – Konmask maintains stock of genuine SCS components
- ✅ Warranty support – Original parts preserve system warranty coverage
- ✅ Traceable provenance – Full supply-chain documentation available on request
Typical Applications
- Variable frequency drive (VFD) braking circuits requiring rapid deceleration
- Crane and hoist control systems with regenerative braking demands
- Conveyor and material-handling lines with frequent start/stop cycles
- Elevator drive systems requiring smooth, controlled stopping
- CNC machine tool spindle drives and servo axis braking
- Pump and fan applications with high-inertia loads
System Compatibility
The SCS UFS-22 braking unit is intended for integration with compatible SCS drive platforms. Before installation, confirm the following:
- Host drive DC bus voltage rating matches the UFS-22 input specification
- Braking resistor (external) resistance and wattage are within the UFS-22 operating range
- Control wiring and enable signal logic are compatible with the host drive’s braking interface
- Enclosure thermal management is adequate for the braking duty cycle
Contact our engineering team for system-level compatibility review at no charge.
Selection Guide
Use the following criteria to confirm the UFS-22 is the correct choice for your application:
- Step 1 – Identify host drive model: Confirm the SCS drive model number and its braking unit interface specification.
- Step 2 – Determine braking duty: Calculate peak braking power and duty cycle (e.g., 10% ED, 40% ED) based on load inertia and deceleration time.
- Step 3 – Verify DC bus voltage: Match the UFS-22 voltage rating to the drive’s DC bus level.
- Step 4 – Select external resistor: Choose a braking resistor with resistance and wattage within the UFS-22’s permissible range.
- Step 5 – Confirm form factor: Verify mounting dimensions and terminal layout against your panel design.
Need help with selection? Send your drive model and application parameters to support@konmask.com and our team will respond within one business day.
Quality Assurance & Sourcing
- Source: Authorized distributor and spot-market specialist for SCS industrial components
- Inspection: All units undergo incoming inspection including visual, label, and functional checks
- Documentation: Certificate of conformity, packing list, and traceability records provided
- Packaging: Anti-static, moisture-barrier packaging with foam protection for safe transit
- Lead Time: In-stock units ship within 1–3 business days; contact us for availability confirmation
How to Order
- Click Add to Cart or Buy Now on this page for standard single-unit orders.
- For bulk orders (5+ units), request a volume quotation via support@konmask.com.
- For urgent or project-critical requirements, call +0086 19859288691 for priority handling.
- Provide your PO number, delivery address, and required delivery date for expedited processing.
- Payment: T/T bank transfer, credit card, and trade-term options (EXW/FOB/CIF) available.
Replacement & Compatibility FAQ
Q: Can I use a third-party braking unit instead of the SCS UFS-22?
A: Yes, provided the replacement unit matches the DC bus voltage rating, braking resistance range, and duty cycle of the UFS-22. We recommend verifying with the host drive manufacturer before substitution.
Q: Is the UFS-22 compatible with non-SCS drives?
A: Potentially, if the drive’s braking interface and DC bus voltage are compatible. Contact our team with your drive model for a compatibility assessment.
Q: What external braking resistor should I use with the UFS-22?
A: The resistor selection depends on the required braking torque, duty cycle, and DC bus voltage. Share your application parameters and we will recommend a suitable resistor.
Q: Do you supply the braking resistor separately?
A: Yes. Contact us with your specifications and we can source a matched braking resistor alongside the UFS-22.
Q: What is the warranty on the SCS UFS-22?
A: We offer a 12-month warranty against manufacturing defects on all genuine SCS components supplied by Konmask. Terms and conditions apply.
