Process Visualization & HMI Solution – SIEMENS 6AV7870-0HE21-1AA0 | SIMATIC Panel PC 870
Where This Product Is Used
The SIEMENS 6AV7870-0HE21-1AA0 SIMATIC Panel PC 870 is deployed across demanding industrial environments where reliable human-machine interface (HMI) performance is non-negotiable. Typical application scenarios include:
- Discrete Manufacturing: Machine tool control, assembly line supervision, and robotic cell monitoring where operators require real-time process visualization.
- Process Industries: Chemical plants, pharmaceutical batch control, and food & beverage processing lines requiring hygienic, panel-mount HMI stations.
- Energy & Utilities: Substation automation, water treatment SCADA terminals, and power distribution control rooms.
- Automotive Production: Body-in-white welding lines, paint shop control, and end-of-line test stations integrated with SIMATIC S7 PLCs.
- Building Automation: Central HVAC control panels, BMS operator workstations, and facility management terminals.
- Oil & Gas: Wellhead control panels, pipeline SCADA nodes, and compressor station HMI cabinets.
Technical Specifications
| Part Number | 6AV7870-0HE21-1AA0 |
| Product Family | SIMATIC Panel PC 870 |
| Manufacturer | Siemens AG |
| Form Factor | Panel-mount Industrial PC / HMI |
| Display | 15″ TFT Color Touch Screen |
| Resolution | 1024 × 768 (XGA) |
| Touch Technology | Resistive touchscreen |
| Operating System | Windows XP Embedded / Windows CE (variant-dependent) |
| Processor | Intel Celeron / Pentium M (series-standard) |
| Protection Rating | IP65 (front panel) |
| Mounting | Panel cut-out, portrait/landscape |
| Supply Voltage | 24 V DC |
| Weight | ~17 kg |
| Interfaces | USB, Ethernet (RJ45), COM ports, VGA |
| Certifications | CE, UL, cULus |
Note: Confirm exact sub-variant specifications against the Siemens product datasheet prior to engineering design-in.
Why Engineers Specify This Model
- Seamless SIMATIC Integration: Native compatibility with SIMATIC S7-300/400/1200/1500 PLCs via PROFIBUS, PROFINET, and MPI — eliminating gateway complexity.
- WinCC Runtime Ready: Pre-validated for Siemens WinCC flexible and WinCC V7 SCADA software, reducing commissioning time.
- Industrial-Grade Durability: IP65 front panel protection, wide operating temperature range, and vibration-resistant design for harsh shop-floor environments.
- Standardized Platform: Part of the SIMATIC Panel PC 870 family, enabling spare-parts commonality and simplified maintenance across multi-site installations.
- Long-Term Availability: Siemens industrial products follow extended lifecycle policies, supporting 10+ year plant operational horizons.
- Compact Panel-Mount Design: Optimized for control cabinet integration with minimal footprint, reducing enclosure size and installation cost.
Complete System Bill of Materials
For a complete SIMATIC Panel PC 870 HMI station, engineers typically specify the following complementary components:
- 6AV7870-0HE21-1AA0 – SIMATIC Panel PC 870 (this unit)
- 6ES7 315-2EH14-0AB0 – SIMATIC S7-300 CPU (example controller)
- 6GK7 343-1EX30-0XE0 – CP 343-1 Ethernet communication processor
- 6AV2 123-2GB03-0AX0 – SIMATIC HMI KTP700 (secondary operator panel)
- 6EP1 334-3BA10 – SITOP PSU100S 24V/10A power supply
- 6XV1 840-2AH10 – PROFIBUS cable (per meter)
- Panel-mount hardware kit (M4 stainless fasteners, EMC gasket)
Contact Konmask for complete BOM pricing and availability.
Compliance & Industry Standards
- CE Marking – EU Machinery Directive & EMC Directive compliant
- UL / cULus Listed – North American electrical safety certification
- IP65 – IEC 60529 ingress protection (front panel)
- IEC 61131-2 – Programmable controller equipment standard
- RoHS Compliant – Restriction of Hazardous Substances Directive
- ATEX / IECEx – Consult Siemens for hazardous area variants
Quality Assurance & Sourcing
Konmask.com sources the 6AV7870-0HE21-1AA0 exclusively through verified industrial distribution channels. Every unit undergoes the following quality process before shipment:
- ✔ Visual inspection and label verification against Siemens OEM packaging standards
- ✔ Serial number traceability check
- ✔ Functional power-on test where applicable
- ✔ Anti-static packaging with humidity indicator cards
- ✔ Export documentation and country-of-origin certification available on request
We do not source from unauthorized brokers or grey-market channels. All inventory is backed by Konmask’s quality guarantee.
How to Source This Part
- Request a Quote: Email support@konmask.com with your required quantity and delivery timeline.
- Phone / WhatsApp: Call or message +0086 19859288691 for urgent requirements.
- Add to Cart: For stocked units, place your order directly on this page.
- Lead Time: Typically 3–15 business days depending on stock status and destination.
- Shipping: DHL Express, FedEx International, and sea freight options available. Export documentation provided for all international orders.
Application-Specific FAQ
Q: Is the 6AV7870-0HE21-1AA0 compatible with TIA Portal?
A: The Panel PC 870 series predates TIA Portal’s native panel integration. It is best used with WinCC flexible or WinCC V7. For TIA Portal projects, consider migrating to the SIMATIC IPC477E or newer Unified Comfort Panel range.
Q: Can this unit run third-party SCADA software?
A: Yes. As a Windows-based industrial PC, it supports third-party SCADA platforms (Wonderware, iFIX, Citect) provided the OS version and hardware resources meet the software requirements.
Q: What is the difference between 6AV7870-0HE21-1AA0 and other 6AV7870 variants?
A: The order number suffix encodes the display size, processor, memory, and OS configuration. The -0HE21-1AA0 suffix specifies a particular hardware configuration within the Panel PC 870 family. Contact Konmask for cross-reference assistance.
Q: Is a replacement available if this model is discontinued?
A: Siemens has transitioned newer projects to the SIMATIC IPC477E and IPC677E families. Konmask can assist with migration planning and sourcing of both legacy and current-generation units.
Q: Do you provide warranty on this product?
A: Yes. Konmask provides a 12-month warranty against manufacturing defects on all verified units. Extended warranty options are available on request.
