Industrial PLC Power Solution – Siemens 6ES7307-1BA00-0AA0 | SIMATIC S7-300 PS307 Series
Where This Product Is Used
The Siemens 6ES7307-1BA00-0AA0 is a stabilized 24V DC / 2A power supply module purpose-built for the SIMATIC S7-300 programmable logic controller platform. It is widely deployed across demanding industrial environments where stable, regulated DC power is critical to control-system uptime:
- Automotive Assembly Lines – Powers S7-300 racks controlling robotic welding cells, conveyor sequencing, and body-in-white inspection stations.
- Water & Wastewater Treatment Plants – Supplies reliable 24V DC to PLCs managing pump stations, dosing systems, and SCADA-connected RTUs in corrosive, high-humidity enclosures.
- Food & Beverage Processing – Integrated into hygienic control panels for filling, capping, and pasteurization lines where voltage fluctuation can trigger costly production stops.
- Pharmaceutical Manufacturing – Used in GMP-compliant control cabinets for batch reactors, clean-room HVAC, and validated packaging lines requiring stable, noise-free DC power.
- Oil & Gas Upstream / Midstream – Installed in remote wellhead panels and compressor station PLCs where wide AC input range (120/230V) accommodates variable generator power.
- Building Automation & HVAC – Feeds S7-300 controllers in central plant rooms managing chillers, AHUs, and BMS integration gateways.
- Machine Tool & CNC Centers – Provides clean DC rail power to S7-300 racks coordinating axis control, tool changers, and safety relay circuits.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number (MLFB) | 6ES7307-1BA00-0AA0 |
| Product Family | SIMATIC S7-300 PS307 |
| Input Voltage | 120 / 230 V AC (selectable), 50/60 Hz |
| Output Voltage | 24 V DC (stabilized) |
| Output Current | 2 A |
| Output Power | 48 W |
| Mounting | DIN rail (S7-300 profile rail) |
| Dimensions (W × H × D) | 50 × 125 × 120 mm |
| Protection Class | IP20 |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −40 °C to +70 °C |
| Relative Humidity | 10 % to 95 % (non-condensing) |
| Short-Circuit Protection | Yes (electronic, auto-restart) |
| Isolation | Safe electrical isolation per EN 60950 |
| Weight | Approx. 0.45 kg |
Why Engineers Specify This Model
- Plug-and-Play S7-300 Integration – Slots directly onto the S7-300 profile rail and connects to the backplane bus without additional wiring adapters.
- Wide AC Input Range – Dual 120/230V AC selection handles both North American and European grid standards, simplifying global machine builds.
- Regulated, Low-Ripple Output – Stabilized 24V DC output protects sensitive CPU and I/O modules from voltage transients that cause spurious faults.
- Compact 50 mm Width – Minimizes DIN rail footprint in space-constrained control cabinets; ideal for distributed rack architectures.
- Electronic Short-Circuit Protection – Auto-restart behavior eliminates manual intervention after transient overloads, reducing unplanned downtime.
- Proven Siemens Reliability – Part of the mature SIMATIC S7-300 ecosystem with decades of field validation across millions of installed nodes worldwide.
Complete System Bill of Materials
For a fully operational SIMATIC S7-300 control node, the following components are typically specified alongside the 6ES7307-1BA00-0AA0:
- CPU Module – e.g., 6ES7315-2AH14-0AB0 (CPU 315-2 DP) or 6ES7314-1AG14-0AB0 (CPU 314)
- Profile Rail – 6ES7390-1AE80-0AA0 (480 mm) or 6ES7390-1AF30-0AA0 (530 mm)
- Digital Input Module – 6ES7321-1BH02-0AA0 (SM 321, 16 × 24V DC DI)
- Digital Output Module – 6ES7322-1BH01-0AA0 (SM 322, 16 × 24V DC DO)
- Analog Input Module – 6ES7331-7KF02-0AB0 (SM 331, 8 × AI)
- Bus Connector – 6ES7390-0AA00-0AA0
- Front Connector – 6ES7392-1AJ00-0AA0 (20-pin screw type)
Compliance & Industry Standards
- CE Marking – EU Low Voltage Directive & EMC Directive compliant
- UL Listed – UL 508 (Industrial Control Equipment)
- EN 61131-2 – Programmable Controllers Power Supply Requirements
- EN 60950 / IEC 62368-1 – Safety of Information Technology Equipment (isolation)
- RoHS Compliant – Restriction of Hazardous Substances Directive 2011/65/EU
- ATEX / IECEx – Not rated for Zone 0/1; use appropriate barriers for hazardous areas
Quality Assurance & Sourcing
Every unit listed on Konmask.com undergoes a structured verification process before dispatch:
- Authenticity Check – Part markings, date codes, and holographic labels verified against Siemens factory standards.
- Functional Test – Output voltage, current regulation, and short-circuit protection tested under load prior to shipment.
- Condition Grading – Clearly stated as New (factory-sealed), Refurbished (tested & recertified), or Surplus (unused, original packaging).
- Traceability – Batch records and supplier documentation retained for audit purposes.
- Packaging – Anti-static ESD bags with foam-lined cartons; original Siemens packaging preserved where available.
How to Source This Part
- Add to Cart – Click Buy Now or Add to Cart on this page.
- Request a Quote – For orders of 5+ units or project BOM requirements, email support@konmask.com for volume pricing.
- Lead Time – In-stock units ship within 1–2 business days. Out-of-stock items: contact us for sourcing timeline.
- Export & Customs – We handle export documentation (commercial invoice, packing list, COO) for international shipments.
- Payment – T/T bank transfer, PayPal, and major credit cards accepted.
Application-Specific FAQ
Q: Can the 6ES7307-1BA00-0AA0 power both the S7-300 backplane and external 24V field devices?
A: The 2A output (48W) is sized primarily for the S7-300 rack (CPU + I/O modules). For powering external sensors and actuators simultaneously, a separate 24V field power supply is recommended to avoid overloading the PS307.
Q: Is this power supply compatible with the S7-300 ET 200M distributed I/O?
A: Yes. The ET 200M uses the same S7-300 profile rail and PS307 power supply family. The 6ES7307-1BA00-0AA0 is a valid power source for ET 200M racks with moderate I/O loads.
Q: What is the difference between 6ES7307-1BA00-0AA0 and 6ES7307-1EA00-0AA0?
A: The -1BA00 variant delivers 2A / 48W output; the -1EA00 delivers 5A / 120W. Select the -1EA00 for larger racks with high-density analog or communication modules that draw more current.
Q: Can I use this PSU in a 24V DC input application (e.g., powered from a UPS)?
A: No. The 6ES7307-1BA00-0AA0 requires AC input (120/230V). For DC-input applications, refer to the SITOP PSU series (e.g., 6EP1332-1SH52).
Q: Does Konmask.com provide a warranty on this part?
A: Yes. New units carry the standard Siemens manufacturer warranty. Refurbished units include a 90-day Konmask functional warranty. Contact us for full warranty terms.
