Genuine SIEMENS 6SL3224-0BE31-5UA0 SINAMICS S120 Power Module 15kW | SINAMICS S120 – Verified Source
The SIEMENS 6SL3224-0BE31-5UA0 is a Motor Module (Power Module) from the SINAMICS S120 booksize drive series, rated at 15 kW output power. Designed for high-performance servo and vector control applications, this module integrates seamlessly into the SINAMICS S120 multi-axis drive system. Konmask.com supplies this unit as a verified, genuine Siemens component with full traceability for B2B industrial buyers worldwide.
Technical Specifications
| Part Number | 6SL3224-0BE31-5UA0 |
| Brand | SIEMENS |
| Series | SINAMICS S120 Booksize |
| Module Type | Single Motor Module (Power Module) |
| Rated Output Power | 15 kW |
| Output Current (Continuous) | 18 A |
| Output Current (Peak) | 36 A (60 s) |
| DC Link Voltage | 600 V DC |
| Input Supply | Via DC Bus (from Line Module) |
| Control Interface | DRIVE-CLiQ |
| Cooling Method | Forced air (internal fan) |
| Protection Class | IP20 |
| Ambient Temperature | 0 °C to +40 °C (up to +55 °C derated) |
| Weight | approx. 13 kg |
| Dimensions (H×W×D) | 380 × 100 × 270 mm (approx.) |
| Certifications | CE, UL, cUL |
| Country of Origin | Germany |
| HS Code | 8504.40.9990 |
Our 4-Step Quality Verification Process
Every 6SL3224-0BE31-5UA0 unit shipped from Konmask.com passes through a rigorous 4-step verification protocol before dispatch:
- Step 1 — Source Authentication: Units are procured exclusively from authorized Siemens distributors or verified OEM surplus channels. Each unit carries a traceable batch/lot reference.
- Step 2 — Physical Inspection: Our engineers inspect housing integrity, connector condition, label authenticity (hologram, serial number format), and firmware version markings against Siemens factory standards.
- Step 3 — Functional Bench Test: Where applicable, modules undergo DC bus energization and DRIVE-CLiQ communication checks to confirm operational readiness.
- Step 4 — Packaging & Documentation: Units are packed in anti-static ESD bags with foam protection. A test report and certificate of conformity are included upon request.
Key Features & Benefits
- ✅ Genuine Siemens component — not a clone or third-party equivalent
- ✅ DRIVE-CLiQ interface for plug-and-play integration with SINAMICS S120 Control Units (CU320-2, CU310-2)
- ✅ High dynamic response — suitable for servo axes requiring fast torque response
- ✅ Booksize form factor — compact, modular, and scalable for multi-axis configurations
- ✅ Safe Torque Off (STO) integrated safety function (SIL 2 / PLe)
- ✅ Wide ambient temperature range with derating capability up to 55 °C
- ✅ CE & UL certified — compliant for global machine builder requirements
Typical Applications
- CNC machining centers and turning/milling machines
- Servo press and stamping lines
- Packaging and labeling machinery
- Textile and printing equipment
- Robotics and gantry systems
- Conveyor and material handling automation
- Plastics injection molding machines
Compatible System Components
The 6SL3224-0BE31-5UA0 is designed to operate within the SINAMICS S120 booksize ecosystem. Compatible components include:
- Line Modules: 6SL3130-6AE21-0AB1, 6SL3130-7TE21-6AA3 (Active Line Module)
- Control Units: 6SL3040-1MA01-0AA0 (CU320-2 DP), 6SL3040-1MA00-0AA0 (CU320-2 PN)
- Braking Modules: 6SL3100-1BE21-3AA0
- DRIVE-CLiQ Cables: 6FX2002-1DC00 series
- Encoder Systems: SMC20, SME20/25 encoder evaluation modules
- Capacitor Modules: 6SL3100-1CE14-0AA1
Global Sourcing & Shipping Capabilities
- Stock Location: Warehouses in China (Fujian) with global forwarding partners
- Lead Time: In-stock units ship within 1–3 business days; sourced units within 7–15 business days
- Shipping Methods: DHL Express, FedEx International Priority, sea freight (LCL/FCL) for bulk orders
- Export Documentation: Commercial invoice, packing list, certificate of origin, and customs HS code declaration provided
- Incoterms: EXW, FOB Xiamen, CIF, DAP — negotiable for volume orders
- Minimum Order: 1 unit (no MOQ for standard stock items)
Certifications & Compliance Statement
The SIEMENS 6SL3224-0BE31-5UA0 carries the following certifications as issued by Siemens AG:
- CE Marking — compliant with EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- UL / cUL Listed — recognized for North American market requirements
- RoHS Compliant — restricted hazardous substances per EU Directive 2011/65/EU
- ISO 9001 — Siemens manufacturing facilities are ISO 9001 certified
Konmask.com does not manufacture or modify this product. All certifications are original Siemens factory certifications. We act as an authorized reseller and verified surplus supplier.
How to Order
- Add to Cart — click the purchase button above to proceed directly
- Request a Quote — for bulk orders (5+ units), email support@konmask.com for volume pricing
- Provide Your Requirements — include quantity, required delivery date, and destination country
- Payment — T/T (bank transfer), PayPal, and trade assurance accepted
- Shipping Confirmation — tracking number and export documents provided within 24 hours of dispatch
Authenticity & Trust FAQ
Q: Is this a genuine Siemens product or a compatible replacement?
A: This is a 100% genuine SIEMENS 6SL3224-0BE31-5UA0. We do not sell clones, counterfeits, or third-party equivalents under this listing.
Q: Can you provide a certificate of authenticity?
A: Yes. A certificate of conformity and sourcing documentation are available upon request for all orders.
Q: What warranty do you offer?
A: We offer a 12-month warranty against manufacturing defects. Units that fail under normal operating conditions will be replaced or refunded.
Q: Do you accept returns?
A: Yes, within 30 days of receipt for unused, uninstalled units in original packaging. Please contact us before returning.
Q: Can you source other SINAMICS S120 components?
A: Absolutely. Konmask.com specializes in the full SINAMICS S120 ecosystem. Contact us with your BOM or part list for a comprehensive quote.
Q: How do I verify the serial number?
A: The serial number on the unit nameplate can be verified via Siemens Industry Online Support (support.industry.siemens.com) using the product identification tool.
