SIEMENS 6SL3224-0BE31-1UA0 Power Module | Replacement, Equivalent & Selection Guide
The SIEMENS 6SL3224-0BE31-1UA0 is a SINAMICS S120 series Power Module designed for demanding industrial drive applications. This page provides engineers and procurement teams with complete technical specifications, verified compatible replacements, and a structured selection guide to simplify sourcing decisions.
Technical Specifications
- Manufacturer: Siemens AG
- Part Number: 6SL3224-0BE31-1UA0
- Series: SINAMICS S120
- Type: Single Motor Module / Power Module (Booksize format)
- Output Current (Rated): 11 A
- Output Power: 5.5 kW (at 400 V AC)
- DC Link Voltage: 510–720 V DC
- Input Voltage: 380–480 V AC, 3-phase
- Cooling Method: Forced air cooling (internal fan)
- Protection Rating: IP20
- Communication Interface: DRIVE-CLiQ
- Form Factor: Booksize
- Weight: approx. 6.8 kg
- Ambient Temperature: 0 °C to +40 °C (derated to +55 °C)
- Standards: CE, UL, cUL
Compatible Replacement & Equivalent Models
When the original part is unavailable or discontinued, the following models may serve as functional equivalents. Always verify electrical and mechanical compatibility before substitution.
- 6SL3224-0BE31-1AA0 – Earlier revision of the same module; verify firmware compatibility
- 6SL3210-1SE21-0UA0 – SINAMICS S120 Smart Line Module (system-level replacement consideration)
- 6SL3225-0BE31-1UA0 – Chassis format equivalent for higher-power cabinet installations
- ABB ACS880-01-012A-3 – Cross-brand equivalent (11 A, 400 V, requires adapter for DRIVE-CLiQ)
- Yaskawa CIMR-AC4A0011FAA – Functional equivalent for non-SINAMICS systems
Note: Cross-brand replacements require independent engineering validation. Konmask supplies OEM Siemens parts as the primary recommendation.
Why Choose the Original Model
- Native DRIVE-CLiQ Integration: Plug-and-play with SINAMICS S120 Control Units (CU320-2, CU310-2) — no parameter remapping required
- Firmware Ecosystem: Fully supported by STARTER / SINAMICS Startdrive commissioning software
- Proven Reliability: Designed and tested to Siemens IEC/EN 61800-5-1 drive standards
- Spare Parts Availability: Long-term availability through Siemens global supply chain and authorized distributors
- Warranty & Support: Eligible for Siemens Industry Online Support and repair services
Typical Applications
- CNC machine tool spindle and feed axis drives
- Conveyor and material handling systems
- Packaging machinery with multi-axis coordination
- Textile and printing machine drives
- Pump and fan variable-speed control in process plants
- Robotics and automated assembly lines
- Crane and hoist drive systems
System Compatibility
- Compatible Control Units: SINAMICS S120 CU320-2 DP, CU320-2 PN, CU310-2 DP, CU310-2 PN
- Line Modules: Active Line Module (ALM) or Smart Line Module (SLM) required for DC bus supply
- Motor Compatibility: Siemens 1FK7, 1FT7, 1PH8 series motors; third-party motors with encoder feedback
- Encoder Interface: Via Sensor Module Cabinet-Mounted (SMC) or SME
- Fieldbus: PROFIBUS DP / PROFINET IO (via Control Unit)
- Cabinet Integration: Booksize format; compatible with Siemens standard drive cabinets and custom enclosures
Selection Guide
Use the following criteria to confirm the 6SL3224-0BE31-1UA0 is the correct module for your application:
- Step 1 – Power Requirement: Confirm motor rated power ≤ 5.5 kW at 400 V AC
- Step 2 – Current Rating: Verify continuous output current ≤ 11 A; peak current ≤ 22 A (200% overload)
- Step 3 – DC Bus Voltage: Confirm DC link supply is 510–720 V DC from a compatible Line Module
- Step 4 – Form Factor: Booksize format required; confirm cabinet rail and mounting space
- Step 5 – Control Unit: Confirm DRIVE-CLiQ port availability on your CU320-2 or CU310-2
- Step 6 – Cooling: Ensure minimum 100 mm clearance above/below for forced-air ventilation
- Step 7 – Firmware: Match firmware version with Control Unit using Siemens compatibility matrix
Not sure which module fits your system? Contact our engineering team with your motor nameplate data and control unit part number.
Quality Assurance & Sourcing
- Origin: Genuine Siemens OEM hardware; sourced from authorized distribution channels
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-shipment check
- Packaging: Original or equivalent anti-static packaging with humidity indicators
- Traceability: Batch and serial number documentation available on request
- Warranty: 12-month warranty against manufacturing defects from date of shipment
- Counterfeit Prevention: All units verified against Siemens holographic labels and SINAMICS firmware signature
How to Order
- Online: Add to cart directly on this page — stock availability shown in real time
- Email RFQ: support@konmask.com — include part number, quantity, and required delivery date
- Phone / WhatsApp: +0086 19859288691 — available Mon–Sat, 09:00–18:00 CST
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders quoted within 24 hours
- Export: DDP, DAP, EXW terms available; export documentation (CO, packing list, commercial invoice) provided
Replacement & Compatibility FAQ
Q: Can I replace 6SL3224-0BE31-1UA0 with 6SL3224-0BE31-1AA0?
A: In most cases yes — the -1AA0 is an earlier hardware revision. Verify that your Control Unit firmware supports the older module revision via the Siemens compatibility tool.
Q: Is this module compatible with SINAMICS G120?
A: No. The 6SL3224 series is exclusive to the SINAMICS S120 platform. For G120 applications, refer to the 6SL3210-1KE series Power Modules.
Q: Can I use a third-party VFD as a drop-in replacement?
A: Functionally possible for standalone motor control, but DRIVE-CLiQ communication and S120 multi-axis coordination will not be available. Engineering re-commissioning is required.
Q: What is the difference between Booksize and Chassis format?
A: Booksize modules (like this unit) are compact, rail-mounted, and share a common DC bus. Chassis modules are larger, self-contained, and suited for higher power ratings (>110 kW).
Q: Do you supply repair or exchange units?
A: Yes. Contact us for repair-exchange pricing. Typical repair turnaround is 5–10 business days.
Q: How do I verify authenticity of the unit I receive?
A: Check the Siemens holographic label, scan the QR code on the nameplate, and verify the serial number via Siemens Industry Online Support portal.
