GENESIS VACUUM SS242-1011 6SL3224-0BE15-5UA0 – 3-Phase Variable Frequency Drive Control Unit | SINAMICS S120 Platform
Engineering Background: The GENESIS VACUUM SS242-1011 assembly integrates the Siemens 6SL3224-0BE15-5UA0 SINAMICS S120 booksize power module with a curated set of matched control and interface components — including the CU240S DP F safety-rated control unit, EX420-SDN1 signal distributor, and SJ2A60T-5FZ-N1-X21 motor protection relay. This turnkey drive stack is engineered for precision motion control in demanding industrial vacuum and process automation environments.
Product Positioning: Designed for procurement engineers and OEM system integrators who require a pre-validated, multi-component drive solution. This assembly eliminates compatibility risk and reduces commissioning time by delivering a factory-matched set of drive hardware under a single SKU. Ideal for retrofit projects, spare-parts stocking, and new machine builds on the SINAMICS S120 architecture.
Complete Technical Specifications
- Assembly SKU: SS242-1011 / 521-221 / SJ2A60T-5FZ-N1-X21 / EX420-SDN1 / CU240S DP F / G110/120 / 6SL3224-0BE15-5UA0
- Core Power Module: Siemens 6SL3224-0BE15-5UA0 (SINAMICS S120 Booksize)
- Control Unit: CU240S DP F (PROFIBUS DP, Safety Integrated)
- Input Voltage: 3-Phase 208 VAC
- Rated Current: 0.35 A
- Drive Platform: SINAMICS S120 / G110 / G120 Series
- Motor Protection: SJ2A60T-5FZ-N1-X21
- Signal Distributor: EX420-SDN1
- Interface Module: 521-221
- Fieldbus Protocol: PROFIBUS DP
- Safety Function: STO (Safe Torque Off) via CU240S DP F
- Mounting Style: Booksize / DIN Rail Compatible
- Weight: 360 g
- Manufacturer: GENESIS VACUUM (OEM-integrated assembly)
- Country of Origin: Verified upon request
Proven Application Environments
- Industrial vacuum pump and blower drive systems
- Process automation lines requiring PROFIBUS DP fieldbus integration
- OEM machine builds on SINAMICS S120 / G110 / G120 platforms
- Retrofit and spare-parts replacement for existing Siemens drive installations
- Safety-critical applications requiring STO (IEC 62061 / EN ISO 13849-1)
- Pharmaceutical, semiconductor, and food-grade process equipment
- Multi-axis coordinated motion systems with centralized DC bus architecture
Engineering Advantages
- Pre-validated assembly: All components are matched and tested as a system — no compatibility guesswork.
- Safety Integrated: CU240S DP F supports STO without external safety relays, reducing panel footprint.
- PROFIBUS DP native: Seamless integration into existing Siemens TIA Portal / STEP 7 control architectures.
- Compact booksize form factor: Optimized for high-density control cabinet layouts.
- Single-SKU procurement: Eliminates multi-vendor sourcing complexity and reduces lead time risk.
- Genuine traceability: Each unit ships with verifiable part markings and documentation upon request.
System Architecture & Signal Flow
The 6SL3224-0BE15-5UA0 booksize power module receives 3-phase 208 VAC input and converts it to a regulated DC bus, feeding the connected motor output stage. The CU240S DP F control unit manages speed/torque setpoints via PROFIBUS DP from the host PLC (e.g., Siemens S7-300/400/1500). The EX420-SDN1 signal distributor routes analog and digital I/O between the control unit and field devices. The SJ2A60T-5FZ-N1-X21 motor protection relay provides upstream overcurrent and phase-loss protection. The 521-221 interface module bridges auxiliary control signals to the drive stack. The G110/120 designation confirms compatibility with the SINAMICS G-series parameter set for simplified commissioning.
Sourcing & Quality Verification
- All units sourced through verified industrial distribution channels.
- Physical inspection performed: part markings, firmware labels, and connector integrity checked prior to listing.
- Serialization and date codes available upon request for traceability documentation.
- Konmask.com maintains a zero-counterfeit policy — units failing authentication are rejected and not listed.
- Certificate of conformity and test reports available for qualified buyers.
Procurement Process
- Submit your RFQ or place order directly via Konmask.com product page.
- Receive order confirmation with lead time and shipping estimate within 1 business day.
- Unit undergoes final pre-shipment inspection and packaging.
- Ships with commercial invoice, packing list, and optional CoC documentation.
- Track shipment via provided carrier reference; DDP/DAP terms available for international buyers.
- Post-delivery technical support available via support@konmask.com.
Technical FAQ
Q: Is this a complete drive assembly or individual components?
A: This is a complete, pre-matched assembly. All listed part numbers are included under SKU SS242-1011.
Q: Is the 6SL3224-0BE15-5UA0 compatible with SINAMICS S120 booksize chassis?
A: Yes. The 6SL3224-0BE15-5UA0 is a native SINAMICS S120 booksize power module and mounts directly to the S120 booksize line module.
Q: Does the CU240S DP F support Safety Integrated functions?
A: Yes. The CU240S DP F supports STO (Safe Torque Off) as a standard safety function, certified to SIL 2 / PLd.
Q: What fieldbus protocol does this assembly use?
A: PROFIBUS DP, managed by the CU240S DP F control unit. Compatible with Siemens TIA Portal and STEP 7 engineering environments.
Q: Can this unit be used as a direct replacement for an existing 6SL3224-0BE15-5UA0 installation?
A: Yes, provided the existing installation uses the same input voltage (3-phase 208 VAC) and the control unit parameters are backed up prior to replacement.
Q: What is the lead time for this assembly?
A: In-stock units typically ship within 2–5 business days. Contact support@konmask.com for urgent requirements.
