PROFIBUS-DP Network Solution – SST SST-PFB-PLC5 | PLC-5 Series
The SST SST-PFB-PLC5 is a high-performance PROFIBUS-DP interface module engineered for Allen-Bradley PLC-5 backplane systems. Designed for industrial engineers who demand deterministic fieldbus communication, this module bridges legacy PLC-5 controllers with modern PROFIBUS-DP field device networks — enabling precise, real-time I/O exchange across distributed automation architectures.
Where This Product Is Used
The SST-PFB-PLC5 is deployed across demanding industrial environments where PROFIBUS-DP fieldbus integration with Allen-Bradley PLC-5 platforms is required:
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyors, and press transfer systems using PROFIBUS-connected drives and sensors with PLC-5 supervisory control.
- Oil & Gas Processing: Wellhead control panels, compressor skids, and pipeline SCADA systems where PLC-5 controllers manage PROFIBUS field instruments (pressure transmitters, valve positioners).
- Water & Wastewater Treatment: Pump station automation, dosing control, and SCADA integration with legacy PLC-5 infrastructure and PROFIBUS-DP I/O islands.
- Pulp & Paper Mills: Winder drives, refiner control, and DCS migration projects retaining PLC-5 backplanes while modernizing field device communication.
- Chemical & Pharmaceutical Plants: Batch reactor control, agitator drive networks, and safety-instrumented systems requiring certified PROFIBUS-DP master/slave communication.
- Mining & Minerals Processing: Conveyor drive networks, crusher control, and hoisting systems integrating PROFIBUS field devices with existing PLC-5 control architecture.
Technical Specifications
- Part Number: SST-PFB-PLC5
- Manufacturer: SST (Woodhead / Molex)
- Form Factor: Single-slot PLC-5 backplane module
- Fieldbus Protocol: PROFIBUS-DP (EN 50170 / IEC 61158)
- PROFIBUS Role: Class 1 Master (DPM1) and/or Slave
- Data Transfer Rate: 9.6 kbps – 12 Mbps (auto-detect)
- Max Slave Nodes: Up to 125 PROFIBUS-DP slave devices
- Connector: DB-9 female (PROFIBUS standard)
- Backplane Interface: Allen-Bradley PLC-5 parallel backplane
- Configuration Tool: SST PROFIBUS Configuration Software (Windows)
- Diagnostics: LED status indicators (PROFIBUS activity, fault, power)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5% to 95% non-condensing
- Power Consumption: Supplied via PLC-5 backplane
- Weight: Approx. 500 g
- Certifications: CE, UL (refer to product documentation for current listings)
Why Engineers Specify This Model
- Proven PLC-5 Backplane Compatibility: Designed specifically for the Allen-Bradley PLC-5 parallel backplane — no external gateway hardware required, minimizing panel footprint and wiring complexity.
- Full PROFIBUS-DP Master/Slave Flexibility: Operates as a Class 1 DPM1 master or as a slave node, supporting complex multi-master network topologies.
- Auto Baud Rate Detection: Automatically negotiates network speed from 9.6 kbps to 12 Mbps, simplifying commissioning on mixed-speed PROFIBUS segments.
- Deterministic Cycle Times: Delivers consistent, low-latency I/O updates critical for motion control and process regulation applications.
- Extensive GSD File Library: Compatible with thousands of PROFIBUS-DP slave GSD files, enabling rapid integration of drives, I/O blocks, and instruments from any vendor.
- Long-Term Availability: Konmask.com maintains sourcing channels for legacy SST modules, supporting plant life-extension and MRO programs.
Complete System Bill of Materials
For a complete PROFIBUS-DP network using the SST-PFB-PLC5, engineers typically specify the following components:
- SST SST-PFB-PLC5 — PROFIBUS-DP Interface Module (this item)
- Allen-Bradley PLC-5 Processor (e.g., 1785-L40B, 1785-L80B)
- Allen-Bradley 1771 I/O Chassis & Power Supply
- PROFIBUS-DP Bus Termination Resistors (active termination at segment ends)
- PROFIBUS-DP Cable (Type A, shielded, 150Ω impedance)
- DB-9 PROFIBUS Connectors with integrated termination switch
- PROFIBUS-DP Slave Devices (drives, remote I/O, transmitters — per application)
- SST PROFIBUS Configuration Software (for GSD file management and diagnostics)
- PROFIBUS Repeater (if segment exceeds 32 nodes or 1200 m at 187.5 kbps)
Compliance & Industry Standards
- PROFIBUS-DP Standard: EN 50170 / IEC 61158 Type 3
- EMC Directive: CE marked (2014/30/EU)
- UL Listing: UL 508 (Industrial Control Equipment) — verify current listing on UL Product iQ
- RoHS Compliance: Refer to SST/Molex product documentation for RoHS status
- PROFIBUS International Certification: Interoperability tested per PI (PROFIBUS & PROFINET International) guidelines
Quality Assurance & Sourcing
Konmask.com sources the SST-PFB-PLC5 through established industrial distribution and MRO supply channels. Every unit offered is subject to the following quality controls:
- Visual Inspection: Boards inspected for physical damage, corrosion, and counterfeit indicators prior to listing.
- Functional Verification: Where applicable, modules are bench-tested for backplane communication and PROFIBUS port integrity.
- Traceability: Lot and date codes documented for MRO and warranty reference.
- Packaging: Anti-static ESD packaging with desiccant for safe international shipping.
- Warranty: 90-day replacement warranty against defects in materials and workmanship. Contact support@konmask.com for claims.
How to Source This Part
- Confirm Compatibility: Verify your PLC-5 chassis model and firmware revision against SST-PFB-PLC5 compatibility documentation.
- Request a Quote: Contact support@konmask.com or call +0086 19859288691 for volume pricing, lead time, and availability confirmation.
- Place Your Order: Add to cart and complete checkout via Konmask.com secure checkout. We accept T/T bank transfer, PayPal, and major credit cards.
- Shipping & Export: We ship globally via DHL, FedEx, and UPS. Export documentation (commercial invoice, packing list, COO) provided for international orders.
- Technical Support: Post-purchase commissioning support available via email. GSD files and configuration guides provided upon request.
Application-Specific FAQ
Q: Can the SST-PFB-PLC5 operate as both a PROFIBUS master and slave simultaneously?
A: The module supports master or slave operation. Simultaneous master/slave on a single module is not supported; separate modules are required for multi-role topologies.
Q: What is the maximum cable length for a PROFIBUS-DP segment using this module?
A: At 12 Mbps, maximum segment length is 100 m. At 187.5 kbps, up to 1000 m. Use repeaters to extend beyond single-segment limits.
Q: Is this module compatible with RSLogix 5 programming software?
A: The SST-PFB-PLC5 is configured via SST’s own PROFIBUS configuration utility, not RSLogix 5 directly. Data exchange with the PLC-5 processor is via backplane block transfer or direct I/O mapping depending on firmware.
Q: Can I use this module in a ControlLogix or CompactLogix system?
A: No. This module is designed exclusively for the Allen-Bradley PLC-5 parallel backplane. For ControlLogix, specify the SST-PFB-CLX series instead.
Q: Do you provide GSD files and configuration software?
A: Yes. Contact support@konmask.com after purchase and we will provide the relevant GSD files and SST configuration software download link.
Q: What is the lead time for this part?
A: Typically 3–7 business days for in-stock units. Contact us for current availability and expedited shipping options.
