Oscilloscope Power Supply Repair Solution — Tektronix G35SB080 | P/N 671-5612-06 | Power Supply Control Series
Where This Product Is Used
The Tektronix G35SB080 Control Board (P/N 671-5612-06) is a factory-original power supply control PCB designed for use inside Tektronix oscilloscopes and bench-top test instruments. It is most commonly required in the following application scenarios:
- Oscilloscope bench repair depots — replacing failed power regulation boards in Tektronix instruments to restore full measurement capability
- University and R&D lab maintenance — keeping critical test equipment operational without full instrument replacement
- Industrial calibration facilities — maintaining certified Tektronix oscilloscopes used in production-line verification and EMC testing
- Military & aerospace MRO — sourcing OEM-equivalent control boards for long-lifecycle instrument sustainment programs
- Electronics manufacturing (EMS/ODM) — restoring in-house test equipment to minimize production downtime
Technical Specifications
| Manufacturer | Tektronix |
| Part Number | 671-5612-06 |
| Model / Assembly | G35SB080 |
| Component Type | Power Supply Control Board (PCB Assembly) |
| Function | Power regulation and switching control for Tektronix oscilloscope mainframe |
| Weight | 430 g (as shipped) |
| Condition | Surplus / Refurbished OEM — tested prior to shipment |
| Compatibility | Tektronix instruments using G35SB080 power supply assembly |
| RoHS Status | Manufactured to Tektronix OEM standards; verify with datasheet for specific revision |
Why Engineers Specify This Model
- OEM part number match — P/N 671-5612-06 is the exact Tektronix factory reference, ensuring drop-in compatibility without re-qualification
- Avoids full instrument write-off — replacing this board at component level is significantly more cost-effective than scrapping a functional oscilloscope chassis
- Preserves calibration traceability — restoring the original power supply board maintains the instrument’s calibration history and certification chain
- Reduces lead time vs. new instrument — critical for labs with tight uptime SLAs where waiting for a new oscilloscope is not acceptable
- Trusted Tektronix heritage — Tektronix is the global benchmark for precision test & measurement; OEM boards carry the same design tolerances as the original build
Complete System Bill of Materials
When servicing a Tektronix oscilloscope power supply section, the following complementary components are typically required alongside the G35SB080 control board:
- Tektronix power supply transformer assembly (instrument-specific)
- Bulk electrolytic capacitor kit (matched to oscilloscope model BOM)
- Switching MOSFET / IGBT driver ICs (per schematic revision)
- Fuse block and EMI filter module
- Ribbon cable / board-to-board connector harness
- Thermal interface pads for heatsink re-mounting
Contact [email protected] for a full BOM sourcing consultation.
Compliance & Industry Standards
- Manufactured by Tektronix under ISO 9001-certified production processes
- Suitable for use in instruments subject to IEC 61010-1 (Safety for electrical equipment for measurement)
- Compatible with ANSI/NCSL Z540 calibration management frameworks
- Supports instrument compliance with CE, FCC Part 15, and MIL-PRF-28800 test equipment standards (instrument-level; verify per model)
Quality Assurance & Sourcing
At Konmask.com, every control board undergoes a structured intake and verification process before listing:
- Visual inspection for physical damage, corrosion, and component integrity
- Part number and revision marking cross-checked against Tektronix service documentation
- Functional power-on test where applicable
- Anti-static packaging (ESD bag + foam insert) for safe transit
- Traceable sourcing records maintained for each unit
How to Source This Part
- Confirm compatibility — verify your oscilloscope model and service manual references P/N 671-5612-06 or assembly G35SB080
- Add to cart — stock is limited; surplus OEM boards are not replenished on a fixed schedule
- Request a quote for volume — email [email protected] for multi-unit pricing or expedited shipping options
- International orders — we ship globally; contact us for customs documentation and HS code assistance
Application-Specific FAQ
Q: Which Tektronix oscilloscope models use the G35SB080 control board?
A: The G35SB080 assembly is used in Tektronix instruments that reference P/N 671-5612-06 in their service manual BOM. Please verify against your specific model’s service documentation before ordering.
Q: Is this a new, refurbished, or used part?
A: This is a surplus/refurbished OEM Tektronix board. It has been inspected and tested. Condition details are disclosed in the listing; contact us if you require a condition report.
Q: Can I return the board if it does not resolve my fault?
A: Yes — please contact [email protected] within 7 days of receipt. We will work with you to diagnose the issue and arrange a return or exchange where applicable.
Q: Do you provide installation support?
A: We can provide reference to Tektronix service documentation and general guidance. For complex repairs, we recommend engaging a certified Tektronix service center.
Q: What is the lead time for international shipments?
A: Standard international shipping is 7–15 business days. Expedited options are available — contact us for a quote.
