NOVELLUS 02-122156-00 PCB WTS0 Field Connector | Replacement, Equivalent & Selection Guide
The NOVELLUS 02-122156-00 is a PCB WTS0 Field Connector assembly used in Novellus CVD and semiconductor process equipment. This page provides full technical specifications, verified cross-reference part numbers, application guidance, and sourcing information to help engineers and procurement teams make confident selection decisions.
Technical Specifications
- Manufacturer: NOVELLUS Systems (Lam Research)
- Primary Part Number: 02-122156-00
- Cross-Reference / Alternate Part Numbers: 02-106219-00 | 27-152970-00 | 90150757 | 1105-100935-11
- Description: PCB WTS0 Field Connector
- Assembly Type: Printed Circuit Board (PCB) Assembly
- Weight: 2,600 g (approx.)
- Condition: New / Refurbished / Tested (specify at order)
- Origin: OEM / Compatible Replacement
Compatible Replacement & Equivalent Models
The following part numbers are confirmed cross-references or functional equivalents for the NOVELLUS 02-122156-00. Always verify fit with your equipment BOM before installation.
- 02-106219-00 — Earlier revision, same connector interface
- 27-152970-00 — Sub-assembly reference used in field kits
- 90150757 — Lam Research consolidated catalog number
- 1105-100935-11 — Internal assembly tracking number
Note: Cross-reference compatibility should be confirmed against your specific tool revision and BOM. Contact our team for verification support.
Why Choose the Original Model
- Designed and validated specifically for NOVELLUS CVD process chambers
- Ensures signal integrity and connector reliability in high-uptime fab environments
- Reduces risk of field failures compared to unverified third-party substitutes
- Full traceability documentation available upon request
- Backed by Konmask.com quality inspection and sourcing standards
Typical Applications
- NOVELLUS SPEED CVD systems
- NOVELLUS Sequel / Sequel II deposition platforms
- WTS (Wafer Transfer System) field wiring harness connections
- Semiconductor fab maintenance, repair, and overhaul (MRO) programs
- Spare parts inventory for 200mm and 300mm process tools
System Compatibility
- NOVELLUS SPEED CVD — confirmed
- NOVELLUS Sequel / Sequel II — confirmed
- Lam Research integrated platforms (post-merger) — verify by BOM
- Third-party retrofits — consult engineering team before use
Selection Guide
Use the table below to determine the correct part for your application:
- Need OEM original? → Order 02-122156-00 (current revision)
- Have older tool revision? → Cross-check 02-106219-00 against your BOM
- Sourcing via Lam Research catalog? → Reference 90150757
- Field kit / sub-assembly replacement? → Use 27-152970-00
- Unsure? → Contact [email protected] with your tool serial number for a free compatibility check
Quality Assurance & Sourcing
- All units inspected and tested prior to shipment
- Sourced from authorized distributors, OEM surplus, and certified refurbishers
- Condition clearly stated on each order (New / Refurbished / As-Is)
- Certificate of Conformance (CoC) and test reports available on request
- Secure packaging to prevent ESD and transit damage
How to Order
- Add to cart directly, or contact us for bulk / urgent orders
- Specify required condition: New, Refurbished, or Tested
- Provide tool model and serial number for compatibility confirmation (optional but recommended)
- Request lead time and availability: [email protected] | +0086 19859288691
- Payment: T/T, PayPal, credit card accepted
Replacement & Compatibility FAQ
Q: Is 02-106219-00 a direct replacement for 02-122156-00?
A: In most cases yes, but confirm against your tool’s BOM revision. Contact us for verification.
Q: What is the difference between 02-122156-00 and 90150757?
A: 90150757 is the Lam Research consolidated catalog number assigned after the Novellus acquisition. Functionally equivalent for most applications.
Q: Can I use this part in a non-NOVELLUS system?
A: Only if the connector interface and electrical specifications match. We recommend consulting your system integrator.
Q: Do you offer warranty on refurbished units?
A: Yes. Refurbished units carry a 90-day functional warranty. Terms available on request.
Q: What is the lead time?
A: In-stock units ship within 1–3 business days. Out-of-stock items: 2–6 weeks depending on sourcing. Contact us for real-time availability.
