TELI CS3500C Control Unit | Replacement, Equivalent & Selection Guide
The TELI CS3500C is a dedicated control unit designed for precision machine vision and industrial camera systems. As a core component in TELI’s CS-series platform, it provides synchronized control, signal processing, and interface management for demanding industrial imaging applications. This guide covers technical specifications, compatible replacements, and selection criteria to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | TELI (Tokyo Electronic Industry) |
| Model Number | CS3500C |
| Product Type | Camera / Imaging Control Unit |
| Series | CS3500 Series |
| Interface | Camera Link / RS-232C / Trigger I/O |
| Power Supply | DC 12V (typical) |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Weight | Approx. 500 g |
| Compliance | CE, RoHS |
| Condition Available | New / Refurbished / Tested Used |
Note: Specifications are based on manufacturer documentation. Contact Konmask for datasheet confirmation prior to ordering.
Compatible Replacement & Equivalent Models
When the TELI CS3500C is discontinued, obsolete, or on extended lead time, the following models may serve as functional equivalents depending on system configuration:
| Model | Brand | Compatibility Notes |
|---|---|---|
| CS3500B | TELI | Prior-generation equivalent; same form factor, verify firmware |
| CS3600C | TELI | Upgraded successor; backward-compatible in most CS-series frames |
| XC-HR50 | Sony | Functional equivalent for Camera Link imaging control; verify pinout |
| CV-A10 | JAI | Cross-brand alternative for monochrome control applications |
| Genie Nano C1920 | Teledyne DALSA | GigE Vision alternative; requires interface adapter |
Important: Always verify connector pinout, trigger logic levels, and firmware compatibility before substituting. Konmask engineers can assist with cross-reference validation — contact us before ordering a replacement.
Why Choose the Original Model
- Exact form-factor fit — drop-in replacement with no mechanical modification required
- Firmware compatibility — guaranteed compatibility with existing TELI CS-series host software
- Validated signal timing — trigger delay and exposure synchronization pre-calibrated for CS3500 optics
- Reduced integration risk — eliminates re-qualification effort in regulated or safety-critical environments
- OEM traceability — original part number maintained for audit, warranty, and service records
Typical Applications
- Semiconductor wafer inspection — synchronized imaging control in lithography and metrology stations
- PCB automated optical inspection (AOI) — high-speed trigger coordination for multi-camera AOI lines
- Flat panel display (FPD) defect detection — pixel-level imaging control in TFT/OLED inspection systems
- Pharmaceutical blister pack inspection — real-time image acquisition control for GMP-compliant lines
- Automotive parts vision inspection — surface defect and dimensional verification on production lines
- Food & beverage label verification — barcode and label integrity checking at line speed
System Compatibility
The TELI CS3500C is designed to operate within the following system environments:
- Frame grabbers: Compatible with Camera Link frame grabbers from Matrox, National Instruments (NI), and Euresys
- Host software: TELI SDK, Halcon, VisionPro, LabVIEW IMAQ
- Operating systems: Windows 10/11 (64-bit), Linux (kernel 4.x+)
- Lighting controllers: Standard strobe trigger output compatible with CCS, Effilux, and Metaphase controllers
- Lens mounts: C-mount standard; F-mount adapter available
If your system uses a non-standard interface or legacy PCI frame grabber, contact Konmask for compatibility assessment.
Selection Guide
Use the following criteria to determine whether the CS3500C is the right control unit for your application:
| Requirement | CS3500C Suitable? | Recommended Alternative |
|---|---|---|
| Camera Link interface required | ✅ Yes | — |
| GigE Vision interface required | ❌ No | Teledyne DALSA Genie Nano |
| USB3 Vision interface required | ❌ No | Basler ace USB3 |
| Color imaging (Bayer/RGB) | ✅ Yes (CS3500C) | — |
| Monochrome only | ✅ Yes (CS3500 mono variant) | — |
| Outdoor / harsh environment | ⚠️ Limited | IP67-rated industrial camera |
| High frame rate (>100fps) | ⚠️ Verify model spec | CS3600C or DALSA Linea |
Quality Assurance & Sourcing
- Source verification: All TELI CS3500C units sourced by Konmask are procured through authorized distributors or certified secondary-market channels
- Incoming inspection: Each unit undergoes visual inspection, power-on test, and functional verification prior to shipment
- Condition grading: New (sealed OEM), Refurbished (tested & cleaned), or Tested Used — clearly stated on each listing
- Warranty: 90-day functional warranty on all shipped units; extended warranty available on request
- Documentation: Certificate of conformance, test report, and original datasheet provided upon request
- Anti-counterfeit: Konmask does not source from unverified grey-market channels; all units carry traceable lot documentation
How to Order
-
Confirm part number: Verify SKU
CS3500Cmatches your system BOM or equipment service manual - Specify condition: Indicate preference — New, Refurbished, or Tested Used
- Request a quote: Email support@konmask.com or call +0086 19859288691 with your quantity and delivery timeline
- Cross-reference check: If unsure about compatibility, share your system model and we will confirm before invoicing
- Lead time: In-stock units ship within 2–5 business days; sourced units typically 7–15 business days
- Payment & shipping: T/T bank transfer, PayPal, and trade assurance accepted; DHL / FedEx / SF Express available
Replacement & Compatibility FAQ
Q: Is the CS3500C still in production?
A: TELI has transitioned some CS-series models to end-of-life status. Konmask maintains stock of new and refurbished units. Contact us for current availability.
Q: Can I use the CS3600C as a direct replacement?
A: In most cases yes, but firmware and driver updates may be required. We recommend a bench test before deploying in a production line.
Q: Do you provide a datasheet or test report?
A: Yes. A functional test report and available OEM documentation are provided with every shipment upon request.
Q: What is the lead time for a refurbished unit?
A: Refurbished units in stock ship within 3–5 business days. If sourcing is required, lead time is 10–20 business days.
Q: Can Konmask help identify the correct replacement if my system is discontinued?
A: Absolutely. Share your equipment model, current control unit part number, and interface type — our engineers will recommend a validated equivalent.
Q: Do you accept returns?
A: Yes, within 30 days of receipt for units that do not match the described condition or fail functional testing. See our returns policy for details.
