TOKYO ELECTRON E2B115-11/CPPC2 – Tel Control Panel PCB | TEL Semiconductor Equipment Platform
TOKYO ELECTRON (TEL) is one of the world’s leading semiconductor production equipment manufacturers, supplying critical process tools to fabs globally. The E2B115-11/CPPC2 is a Tel Control Panel printed circuit board assembly, cross-referenced under part numbers E281-005025-11 and E208-005025-11. This board serves as a core human-machine interface (HMI) and process control node within TEL’s equipment platforms, enabling operators to monitor, configure, and command process parameters in real time.
Procurement engineers sourcing replacement or spare PCBs for TEL equipment will find this part essential for maintaining uptime in wafer processing, etch, CVD, or diffusion tool environments. Konmask supplies verified surplus and refurbished TEL control boards with full traceability documentation.
Complete Technical Specifications
- Manufacturer: TOKYO ELECTRON (TEL)
- Part Number (Primary): E2B115-11/CPPC2
- Cross-Reference PN 1: E281-005025-11
- Cross-Reference PN 2: E208-005025-11
- Board Type: Tel Control Panel PCB (CPPC2 variant)
- Function: HMI / process control interface board
- Country of Origin: Japan
- Form Factor: Rack-mount / equipment-integrated PCB assembly
- Condition Available: Surplus / Refurbished / Tested
- Compatibility: TEL semiconductor process equipment (etch, CVD, diffusion platforms)
Proven Application Environments
- Semiconductor Wafer Fabrication (Fab): Used in TEL process tools on 200mm and 300mm wafer lines for real-time process control and operator interface.
- Dry Etch Systems: Provides control panel functionality in TEL Tactras, Telius, and related etch platforms.
- CVD / Diffusion Equipment: Integrated into TEL Alpha-8SE, Vertical Thermal Reactors (VTR), and similar thermal process tools.
- Equipment Maintenance & Depot Repair: Sourced by fab maintenance engineers and third-party equipment service providers (ESPs) as a direct replacement board.
- Spare Parts Inventory Programs: Stocked by fab procurement teams as a critical spare to minimize mean time to repair (MTTR).
Engineering Advantages
- Dual Cross-Reference: Covers both E281-005025-11 and E208-005025-11 variants, reducing sourcing ambiguity across different equipment revisions.
- OEM-Grade Design: Manufactured by TEL to original equipment specifications — no third-party substitution risk.
- Plug-and-Play Replacement: Designed for direct board swap in compatible TEL equipment chassis without firmware re-engineering.
- Tested & Verified: Konmask subjects all surplus TEL PCBs to functional power-on testing and visual inspection before shipment.
- Traceability: Each unit ships with documented part number, serial reference, and inspection record.
System Architecture & Signal Flow
The E2B115-11/CPPC2 board operates as the control panel interface node within the TEL equipment control hierarchy. Signal flow is as follows:
- Operator Input Layer: Receives keypad, touchscreen, or switch inputs from the equipment front panel.
- CPPC2 Processing Core: Interprets operator commands and translates them into process parameter signals via the equipment’s internal bus.
- Process Controller Interface: Communicates with the main process controller (MPC) or host computer via dedicated I/O connectors on the board edge.
- Status & Alarm Output: Drives indicator LEDs, alarm relays, and display outputs to provide real-time equipment status feedback to operators.
- Power Input: Receives regulated DC supply from the equipment’s internal PSU rail; board-level fusing protects downstream logic.
Sourcing & Quality Verification
- Source: Decommissioned TEL equipment from certified semiconductor fabs — not gray-market or counterfeit.
- Inspection Standard: Visual inspection per IPC-A-610 workmanship criteria; functional power-on test performed.
- Anti-Counterfeit Measures: Part markings, PCB silkscreen, and component date codes verified against known-good reference boards.
- Packaging: ESD-safe anti-static bag + foam-lined carton; humidity indicator card included.
- Warranty: 90-day replacement warranty against DOA or functional failure under normal operating conditions.
Procurement Process
- Confirm Compatibility: Verify your TEL equipment model and existing board part number against E2B115-11/CPPC2, E281-005025-11, or E208-005025-11.
- Request Quote: Contact Konmask via [email protected] or +0086 19859288691 with your equipment model and required quantity.
- Receive Inspection Report: We provide a pre-shipment inspection report and photos upon request.
- Order & Ship: Orders confirmed within 1 business day; international shipping via DHL/FedEx with full tracking.
- Installation Support: Our technical team can advise on board swap procedures and compatibility verification.
Technical FAQ
- Q: Is E281-005025-11 the same board as E208-005025-11?
- A: Both are cross-reference part numbers for the E2B115-11/CPPC2 assembly. They may reflect different revision levels or procurement catalog entries within TEL’s internal system. Functionally, they are interchangeable in compatible equipment.
- Q: Which TEL equipment models use this control panel board?
- A: This board is associated with TEL’s semiconductor process equipment platforms including etch and CVD tool families. Please provide your equipment model number to our team for a definitive compatibility confirmation.
- Q: Do you provide a test report with the board?
- A: Yes. A functional test record and visual inspection report are available upon request prior to shipment.
- Q: Can this board be repaired if it has a known fault?
- A: Konmask offers board-level repair assessment. Contact us with a fault description and we will advise on repair feasibility vs. direct replacement.
- Q: What is the lead time?
- A: In-stock units ship within 1–3 business days. For out-of-stock inquiries, we will provide a sourcing timeline within 48 hours.
