Triconex 8312 Power Supply Module – Redundant DC Power Supply | Tricon TMR Safety PLC Platform
Engineering Background: The Triconex 8312 is a dedicated power supply module engineered for the Tricon Triple Modular Redundant (TMR) Safety PLC platform — one of the most widely deployed safety instrumented systems (SIS) in the global process industry. Designed to IEC 61508 SIL 3 requirements, the Tricon architecture relies on fault-tolerant, continuously monitored power distribution to sustain 2-out-of-3 voting logic without interruption.
Product Positioning: The 8312 module serves as the primary DC power distribution unit within the Tricon chassis, supplying regulated, isolated power to I/O modules, communication cards, and the main processor. Its hot-swap capability and built-in diagnostics make it the preferred choice for engineers maintaining high-availability SIS installations in oil & gas, petrochemical, nuclear, and power generation facilities.
Complete Technical Specifications
- Part Number / SKU: 8312
- Manufacturer: Triconex (Schneider Electric)
- Platform: Tricon TMR Safety PLC
- Module Type: DC Power Supply Module
- Input Voltage: 24 VDC nominal (18–32 VDC operating range)
- Output: Regulated, isolated DC power rails for chassis backplane
- Redundancy: Supports N+1 redundant power supply configuration
- Hot-Swap: Yes — field-replaceable under power without system shutdown
- Diagnostics: Continuous self-test; fault status via chassis LED and system controller
- Safety Integrity Level: SIL 3 (IEC 61508)
- Form Factor: Single-slot Tricon chassis module
- Weight: 4,000 g (approx.)
- Operating Temperature: 0°C to +60°C
- Humidity: 5–95% RH, non-condensing
- Certifications: TÜV, FM, CSA, CE (per Triconex platform certification)
- Country of Origin: USA
Proven Application Environments
- Oil & Gas — upstream wellhead control, midstream pipeline ESD, downstream refinery SIS
- Petrochemical & Chemical — reactor protection systems, burner management systems (BMS)
- Power Generation — turbine protection, boiler safety shutdown
- Nuclear — auxiliary safety system power distribution (where Tricon is qualified)
- Offshore Platforms — FPSO and fixed platform fire & gas / ESD systems
- LNG Terminals — liquefaction train safety and emergency shutdown
Engineering Advantages
- Zero-Downtime Replacement: Hot-swap design allows module exchange during live operation, eliminating planned shutdowns for power supply maintenance.
- Continuous Diagnostics: Onboard self-test circuitry detects output degradation before failure, enabling predictive maintenance aligned with IEC 61511 lifecycle requirements.
- Redundant Architecture Support: Designed to operate in parallel with a second 8312 unit, ensuring uninterrupted power even during single-module failure events.
- Platform Compatibility: Direct drop-in replacement for existing Tricon chassis installations — no firmware changes or reconfiguration required.
- Isolated Output Rails: Galvanic isolation between input and output prevents ground loops and protects sensitive I/O circuitry from power transients.
System Architecture & Signal Flow
Within the Tricon TMR chassis, the 8312 module receives 24 VDC from the plant UPS or battery-backed DC bus. It conditions and distributes regulated power across the chassis backplane to all installed modules — including the Main Processor Module (MPM), I/O modules, and communication cards. In a redundant configuration, two 8312 units operate in load-sharing mode; if one unit faults, the second assumes full load instantaneously, maintaining SIL 3 availability targets. The chassis controller continuously polls each power supply’s health register and annunciates faults via the Triconex TriStation 1131 engineering workstation.
Sourcing & Quality Verification
- Source: Decommissioned from certified SIS installations or authorized distributor surplus stock
- Inspection: Each unit undergoes visual inspection, connector integrity check, and functional power-on verification prior to shipment
- Traceability: Serial number and firmware revision documented; available upon request
- Packaging: ESD-safe anti-static bag, foam-lined carton, moisture barrier — compliant with IPC/JEDEC J-STD-033
- Warranty: 12-month replacement warranty against manufacturing defects
Procurement Process
- Submit your RFQ via support@konmask.com or place order directly on this page.
- Receive proforma invoice with lead time confirmation within 24 business hours.
- Payment via T/T bank transfer, PayPal, or credit card (Visa/Mastercard).
- Unit ships within 1–3 business days via DHL Express, FedEx, or UPS with full tracking.
- Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
Technical FAQ
Q: Is the Triconex 8312 compatible with all Tricon chassis generations?
A: The 8312 is designed for the Tricon v9/v10 chassis family. Please confirm your chassis model number before ordering to ensure backplane compatibility.
Q: Can the 8312 be replaced while the Tricon system is online?
A: Yes. The hot-swap design allows field replacement under power when a second redundant power supply is installed and operational.
Q: What is the expected service life?
A: Triconex rates power supply modules for a minimum 10-year service life under normal operating conditions. Refurbished units are tested to confirm output within original specification.
Q: Do you provide a test report?
A: Yes. A functional test report is available upon request for each unit shipped.
Q: What is the lead time for out-of-stock units?
A: Typical lead time for sourced units is 2–4 weeks. Contact us for current availability.
