Gas Distribution Solution – VERIFLO 0050-36242 | 3-Valve Manifold Series
Where This Product Is Used
The VERIFLO 0050-36242 3-Valve Manifold with Gas Line Weldment is engineered for high-purity gas distribution in the most demanding process environments. Typical deployment sites include:
- Semiconductor Fabrication (Fabs) – Integrated into gas panels for CVD, ALD, etch, and diffusion processes where precise, contamination-free gas delivery is critical.
- Specialty Gas Cabinets & VMBs – Used as the primary isolation and distribution manifold within valve manifold boxes (VMBs) handling toxic, pyrophoric, or corrosive process gases.
- Photovoltaic (PV) & LED Manufacturing – Deployed in MOCVD and PECVD reactors requiring ultra-clean gas switching with minimal dead volume.
- Research & Analytical Laboratories – Installed in gas chromatography supply lines and mass spectrometry carrier gas systems.
- Industrial Gas Distribution Panels – Applied in high-pressure manifold assemblies for inert, oxidizing, and flammable gas services.
Technical Specifications
- Manufacturer: VERIFLO (Parker Hannifin)
- Primary Part Number: 0050-36242
- Cross-Reference SKUs: 944AOPLPNC3PWTS4275 | 615-00325-000 | 0200-01271
- Configuration: 3-Valve Manifold with Integrated Gas Line Weldment
- Series: 944 Series High-Purity Gas Manifold
- Body Material: 316L VIM-VAR Stainless Steel (electropolished)
- Valve Type: Diaphragm-sealed, metal-seated
- Surface Finish: Ra ≤ 15 µin (electropolished internal surfaces)
- Leak Integrity: ≤ 1×10⁻⁹ std cc/sec He (factory tested)
- Max Operating Pressure: 3,000 psig (207 bar)
- Operating Temperature: -20°C to +150°C
- Port Connections: VCR® face-seal fittings (per weldment configuration)
- Weight: 800 g (approx.)
- Actuation: Manual (standard); pneumatic actuation available
Why Engineers Specify This Model
- Zero Dead-Leg Design – The integrated weldment eliminates tube stubs and dead legs that trap contaminants, ensuring process gas purity from source to point-of-use.
- Multi-SKU Interoperability – Cross-referenced as 944AOPLPNC3PWTS4275, 615-00325-000, and 0200-01271, making it a direct drop-in replacement across multiple OEM BOM revisions.
- Electropolished Flow Paths – Internal Ra ≤ 15 µin finish minimizes particle generation and moisture adsorption, critical for sub-10nm node processes.
- Helium Leak-Tested at Factory – Every unit ships with documented leak test certification, reducing commissioning time on-site.
- Compact Weldment Assembly – Pre-assembled gas line weldment reduces field installation complexity and eliminates potential leak points from field-made tube connections.
Complete System Bill of Materials
For a complete high-purity gas panel using this manifold, engineers typically specify:
- VERIFLO 0050-36242 3-Valve Manifold w/Gas Line Weldment (this unit)
- VCR® Gaskets – 316L SS or Ni, per process gas compatibility
- Upstream Pressure Regulator – VERIFLO 400 Series or equivalent
- Downstream Pressure Transducer – 0–100 psig range
- Purge/Vent Valve Assembly – compatible 2-way diaphragm valve
- Stainless Steel Tubing – 1/4″ OD, 316L, seamless, electropolished
- Panel Mounting Brackets – 316 SS, per fab standard
- Pneumatic Actuator Kit (optional) – for automated gas switching
Compliance & Industry Standards
- SEMI F57 – Metallic Contamination Standard for Semiconductor Process Gas Equipment
- SEMI F1 – Specification for Leak Integrity of High-Purity Gas Piping Systems
- ASME B31.3 – Process Piping Code (Category M Fluid Service)
- RoHS Compliant – Restriction of Hazardous Substances Directive
- ISO 9001:2015 – Quality Management System (VERIFLO manufacturing facility)
Quality Assurance & Sourcing
All VERIFLO components sourced through Konmask.com are procured through verified industrial supply channels. Each unit undergoes the following before shipment:
- Visual inspection for surface damage, corrosion, and port integrity
- Cross-verification of part number markings against manufacturer documentation
- Packaging inspection to confirm factory-sealed, contamination-free condition
- Documentation package available upon request (CoC, test reports)
We do not source from unauthorized secondary markets. Counterfeit or refurbished parts are never listed.
How to Source This Part
- In-Stock Orders: Add to cart and complete checkout. Standard lead time: 3–7 business days (international shipping available).
- Bulk / Project Quantities: Contact our team for volume pricing and project BOM support.
- Cross-Reference Inquiry: If your BOM lists 944AOPLPNC3PWTS4275, 615-00325-000, or 0200-01271 — this is the same part. Confirm with our engineers before ordering if unsure.
- Urgent / AOG Requirements: Email support@konmask.com with your required delivery date.
Application-Specific FAQ
Q: Is this manifold compatible with corrosive gases such as HCl, HF, or Cl₂?
A: The 316L SS body with electropolished finish provides good resistance to many corrosive gases at low concentrations. For highly aggressive chemistries, consult VERIFLO’s material compatibility guide or contact our engineering team.
Q: Can this unit be used with oxygen service?
A: Yes, provided the unit is cleaned for oxygen service (O₂ clean) per ASTM G93 / CGA G-4.1. Confirm cleaning status with your procurement team before installation.
Q: What is the difference between part numbers 615-00325-000 and 0200-01271?
A: These are internal cross-reference numbers used across different OEM and fab documentation revisions. Both refer to the same VERIFLO 0050-36242 assembly. Our team can provide a formal cross-reference letter upon request.
Q: Is pneumatic actuation available for this manifold?
A: Yes. Pneumatic actuator kits are available as accessories. Contact us with your actuation pressure and signal requirements.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes. A CoC is available upon request at time of order. Please note this in your purchase order or email us after checkout.
