WAVETRONICS WT307C – Frequency-Stabilized He-Ne Laser Module | WT300 Series
Precision-grade stabilized helium-neon laser engineered for demanding metrology, interferometry, and OEM photonics applications. The WT307C carries dual cross-reference part numbers 0010-00138 and ENG1003, confirming full interchangeability across WAVETRONICS service documentation and third-party procurement databases.
Engineering Background: He-Ne lasers operating at 632.8 nm remain the gold standard for displacement measurement, holography, and wavelength calibration due to their exceptional coherence length and narrow linewidth. The WT307C adds an active frequency-stabilization loop that suppresses mode drift caused by thermal and mechanical perturbations, delivering output stability an order of magnitude beyond unstabilized tubes.
Product Positioning: Targeted at OEM instrument builders, university metrology labs, and industrial inspection system integrators who require a drop-in, calibration-traceable laser source with documented long-term frequency reproducibility.
Complete Technical Specifications
- Manufacturer: WAVETRONICS
- Model / Part Number: WT307C
- Cross-Reference P/N: 0010-00138 | ENG1003
- Laser Medium: Helium-Neon (He-Ne)
- Output Wavelength: 632.8 nm (visible red)
- Stabilization Type: Active frequency stabilization (thermal / piezo feedback)
- Frequency Stability: ±1 MHz typical (long-term)
- Output Power: Consult datasheet / application engineering
- Polarization: Linear, >500:1 extinction ratio (typical He-Ne configuration)
- Coherence Length: >100 m (stabilized mode)
- Beam Quality: TEM₀₀, M² ≈ 1.0
- Operating Voltage: Per WAVETRONICS power supply specification
- Weight: 4,100 g (as shipped)
- Series / Platform: WT300
- Condition: Surplus / Refurbished — tested functional
Proven Application Environments
- Laser interferometry (displacement, surface flatness, straightness)
- Wavelength calibration references and optical frequency standards
- Holographic recording and holographic interferometry
- Laser Doppler velocimetry (LDV) and particle image velocimetry (PIV)
- Optical coherence tomography (OCT) research platforms
- Semiconductor wafer inspection and lithography alignment
- University and national-lab metrology benches
- OEM integration into coordinate measuring machines (CMM)
Engineering Advantages
- Active Stabilization Loop: Closed-loop feedback eliminates mode-hop drift, ensuring reproducible frequency output session-to-session.
- Dual P/N Traceability: 0010-00138 and ENG1003 cross-references simplify MRO procurement and BOM reconciliation.
- TEM₀₀ Beam Profile: Gaussian output couples efficiently into single-mode fiber and optical instruments without spatial filtering.
- Long Coherence Length: Enables path-length-unbalanced interferometer configurations without fringe visibility loss.
- Proven He-Ne Reliability: Gas-discharge tube technology offers multi-thousand-hour MTBF with no mode-hop aging characteristic of diode lasers.
System Architecture & Signal Flow
The WT307C integrates a sealed He-Ne plasma tube within a thermally managed housing. An internal photodetector samples a fraction of the output beam; the error signal drives a piezoelectric actuator on the cavity mirror to lock the lasing frequency to the center of the Doppler-broadened gain profile. The stabilized beam exits through an AR-coated output window. A separate power supply input (not included) provides the high-voltage discharge excitation and low-voltage servo electronics supply.
[HV Power Supply] ──► [He-Ne Plasma Tube] ──► [Output Beam @ 632.8 nm]
│
[Internal Photodetector]
│
[Servo / PZT Controller]
│
[Cavity Mirror Actuator] ◄──┘ (closed-loop)
Sourcing & Quality Verification
- Unit sourced from decommissioned OEM instrument — full functional test performed prior to listing.
- Part numbers 0010-00138 and ENG1003 verified against WAVETRONICS service documentation.
- Konmask.com specializes in surplus precision photonics and industrial automation components; all units are inspected before dispatch.
- Photographs on file; additional images available on request.
- Certificate of conformance (CoC) available for qualified volume orders.
Procurement Process
- Step 1 — Inquiry: Contact support@konmask.com or call +0086 19859288691 with your application requirements and required quantity.
- Step 2 — Quotation: Receive formal quotation with lead time, shipping options (DHL / FedEx / sea freight), and payment terms within 24 hours.
- Step 3 — Order Confirmation: Submit PO or online checkout; proforma invoice issued for wire transfer or credit card payment.
- Step 4 — Dispatch & Tracking: Unit packed in anti-static, shock-absorbing packaging; tracking number provided within 1 business day of payment clearance.
- Step 5 — After-Sales Support: 30-day DOA warranty; technical support available via email for integration questions.
Technical FAQ
Q: Is the WT307C a direct replacement for 0010-00138?
A: Yes. WT307C, 0010-00138, and ENG1003 are all WAVETRONICS internal designations for the same stabilized He-Ne laser assembly.
Q: What power supply is required?
A: He-Ne lasers require a dedicated high-voltage ballast supply (typically 1,000–2,000 V ignition, 1,500–2,000 V sustain at 5–10 mA). Contact us for compatible WAVETRONICS PSU options.
Q: Can the output be fiber-coupled?
A: Yes. The TEM₀₀ beam couples efficiently into single-mode fiber (630 nm SM) using a standard aspheric coupler. Coupling efficiency >60% is routinely achieved.
Q: What is the warm-up time to reach specified frequency stability?
A: Typically 15–30 minutes from cold start for the thermal servo to reach steady state. Allow 60 minutes for highest-accuracy metrology applications.
Q: Do you offer calibration certificates?
A: Functional test reports are standard. NIST-traceable calibration certificates can be arranged through our partner calibration laboratory — please enquire at time of order.
